After inserting a new card in the upper of the two free slots, the interface num-
bering was as follows:
Additional
card
Onboard inter-
eth9 eth8
faces 1 + 2
New card in
eth2 eth3 eth4 eth5 eth6 eth7
upper slot
Adding Two Network Interface Cards
Before installing the two new cards, the four network interfaces on this appli-
ance were numbered in the following way:
Additional
card
Onboard inter-
eth3 eth2
faces 1 + 2
After inserting the two new cards in the free slots, the interface numbering was
as follows:
Additional
card
Onboard inter-
eth15 eth14
faces 1 + 2
New card in
eth8 eth9 eth10 eth11 eth12 eth13
upper slot
New card in
eth0 eth1 eth2 eth3 eth4 eth5
lower slot
Testing the Interface Numbering
eth0 eth1
eth0 eth1
eth6 eth7
