Testing the Interface Numbering
This chapter describes the results of a test that was performed in order to
establish the numbering of the interfaces
pliance models after one or two new six-port network interface cards had been
installed there.
4.1

Interface Numbering on the WW500

An additional network interface card with six ports on it, representing the model
mentioned above, was inserted in the free slot provided for this purpose.
Before installing the additional card, the two network interfaces on this appli-
ance were numbered as follows:
Onboard
interface 1
Onboard
interface 2
After installing the additional card, the interface numbering was:
Onboard
interface 1
Onboard
interface 2
Additional
card
eth0
eth1
eth6
eth7
eth5 eth4 eth3 eth2
Chapter 4
eth0, eth1,
etc. on the various ap-
eth1 eth0
4–1
