Main Display Screens

The Control Panel is programmed and operated using the color
touch-screen display. The display will show various buttons,
indicators, and text to guide the installer and user.

Home Screen

The Home Screen is the top level screen. It shows the system status
with icons to indicate system conditions. It also displays the time
and date. System information scrolls along the top of the display.
The Home Screen displays the SECURITY and HOME SERVICES
buttons. When the system is operating, pressing the button on
the Control Panel will display the Home Screen.
Figure 20. The Home Screen

Security Screen

The Security Screen shows the system status and offers three
buttons for ARM, MENU, and STATUS. It also displays the time
and date. If messages, alarm, or trouble alerts are pending, the
Security Screen will display buttons indicating the number of
Trouble Alert
pending messages or issues.
Alarm Memory

Arming Screen

The Arming Screen is used to arm the security portion of the
Message
system. It displays the system status and arming buttons for STAY
and AWAY.
Two option check box buttons for ENTRY DELAY and SILENT EXIT are
Figure 21. The Security Screen
displayed. To arm the system without an entry delay, un-check the
ENTRY DELAY check box. To arm silently without sounding the Exit
Delay beeps, check the SILENT EXIT check box. Stay Mode arming
always has a silent exit.

Menu Screen

The Menu Screen shows the system status and offers buttons for
ARM and TOOLBOX. If any of the 24-hour emergency options are
enabled, an EMERGENCY button is displayed. Two option check box
buttons for CHIME and VOICE are displayed.
Installer setup is accessed using the TOOLBOX button.
The CHIME button enables/disables chimes for the entire system
Figure 22. The Arming Screen
(chimes can be independently enabled or disabled for each sensor
number from the Toolbox).
The VOICE button enables/disables voice announcements for
the entire system (voice announcements can be independently
enabled or disabled for each sensor number from the Toolbox).
Voice announcements always sound during alarm conditions.

Status Screen

The Status Screen lists system status and any alerts. The date and
time of alerts are listed in the displayed log.
One option button for SILENCE is displayed; it temporarily stops
Figure 23. The Menu Screen
the voice announcement of the system status during the status
display.
Figure 24. The Status Screen
