Accurist Helpline
OWNERS NAME
020 7447 3945
Automatic / Quartz Analogue (
Including Multi Dial)
ADDRESS
Watch setting Instructions
Further information or instructions can be obtained
Including 6P20 / 6P21 / 6P27/77
from the Accurist Helpline during office hours Monday to Friday.
Advertisement
Table of Contents
Related Manuals for Accurist 6P20
Summary of Contents for Accurist 6P20
- Page 1 OWNERS NAME 020 7447 3945 Automatic / Quartz Analogue ( Including Multi Dial) ADDRESS Watch setting Instructions Further information or instructions can be obtained Including 6P20 / 6P21 / 6P27/77 from the Accurist Helpline during office hours Monday to Friday.
-
Page 2: Registration 3
Registration £10.00 / €12.50 To register your Accurist watch, please go to www.accurist.co.uk/registration to For all other countries enter some basic information so you can keep abreast of the latest special offers and product developments for Accurist Watches. 1. Return the watch with payment to your nearest International service agent... -
Page 3: Table Of Contents
Contents Registration How to use these instructions Quartz Analogue Operating Instructions Quartz Analogue with date Operating Instructions 6P29 / 6P20 / 6P21 Operating Instructions 6P27 / 77 Operating Instructions Care of your watch Ceramic special Care Instructions WEEE Directive Bracelet Adjustment... -
Page 4: How To Use These Instructions
How to use these instructions This booklet contains setting instructions for the Accurist Quartz Analogue series of watches. Each section describes a particular calibre (also called watch movement) which offers a unique set of functions and features. As such, it is necessary to identify the correct calibre of your watch before proceeding to the appropriate section (see diagram opposite). -
Page 6: Quartz Analogue Operating Instructions
Quartz Analogue Operating Instructions Position A Position B... - Page 7 Please note: The second hand will not start moving until the crown has been returned to Position A. To set the time: 1. Gently pull out crown to Position B. 2. Turn crown either way to correct time. 3. Push in crown to Position A. To set your watch accurately visit www.britishrealtime.com...
- Page 8 Quartz analogue with date operating instructions Miyota Watch Movement Operating Instructions Minute hand 24 hour hand Normal 1st Position 2nd Position 24 hour hand Crown Position Date Date position may be located at different position depends on model.
- Page 9 Setting the time: 1. Pull the crown out to the 2nd position. 2. Turn the crown to set hour and minute hands. 3. When the crown is pushed back to the normal position, second hand begins to run. Setting the date: 1.
-
Page 10: Quartz Analogue With Date Operating Instructions
Quartz analogue with date operating instructions continued... Quartz Analogue Operating Instructions continued... For Calendar Models FRI 12 Position A Position B Position C... - Page 11 To set the calendar/date: 1. Gently pull out crown to Position B. 2. Turn crown anti-clockwise to adjust date, clockwise to adjust the day. 3. Push in crown to Position A. Note: The Day will start to change at 11.25 p.m. and complete its change by 12 0’...
-
Page 12: 6P29 / 6P20 / 6P21 Operating Instructions
6P29 / 6P20 / 6P21 Operating Instructions Date Date position C position C position A position A position B position B 24 hour display Age of the moon... - Page 13 To set the time/day 1. Gently pull out crown to Position C. 2. Turn crown either way to set the time. 3. Push in crown to Position A. To set your watch accurately visit www.britishrealtime.com To set the day of the week 1.
- Page 14 To set the date 1. Gently pull out crown to Position B. 2. Turn crown anti-clockwise to adjust date. 3. Push in crown to Position A. To set the moon age: Note: More accurate settings can be made during a new moon (when the centre of the moon aligns to ‘0’...
- Page 15 To read the moon age: Note: The age of the moon is determined by the period between each new moon. This period is approximately 29.5 days. The moon dial can be used as a guide to moon phase and tides. New Moon First quarter moon Full moon...
- Page 17 Setting the day: 1. Pull the crown to the 2nd position to stop the second hand at 0 (12 o’clock). 2. Turn the hour/minute hands in a clockwise direction to set a day In order to set the day, you must advance the hour hand by 24 hours per day. Note: Do not set the day by turning the crown in counterclockwise direction.
- Page 18 Note: Make sure you have correctly set AM/PM before setting the time. When the day changes over, it is a.m.. (Day changes over between 0:00a.m. and 5:30a.m. or little later) Check am./p.m. by the 24hour hand. Setting the Date (By quick operation) Pull the crown out to the 1st position.
-
Page 19: Care Of Your Watch
Care of your watch Avoid temperature extremes 1. Avoid leaving your watch in direct sunlight or in extremely warm conditions for long periods of time: this will cause malfunctioning and shorten the life of the battery. 2. Do not leave your watch for long periods of time in extremely cold places; this may cause your watch to gain or lose time. - Page 20 33 19 Avoid strong shocks 1. This watch will withstand the bumps and jars normally incurred during sports activities. 2. Avoid dropping your watch on the ground or otherwise imparting severe shock to it. Avoid strong magnetic fields 1. Keep your watch away from strong magnets 2.
- Page 21 2. Avoid materials such as gasoline, benzene, paint thinner, alcohol, spray cosmetics, nail polish, nail polish remover, adhesives or paint. Periodic inspection 1. A regular 4 to 5 years service by an authorised Accurist technician will ensure trouble free operation. 2. Refer to the After Sales Service section for details.
- Page 22 IMPORTANT 1. Keep the batteries out of reach of infants and small children. Should accidental ingestion occur consult a doctor immediately. 2. Do not attempt to replace the battery yourself as this invalidates your guarantee. Keep you watch clean Wipe off any moisture that adheres to the case, glass or band with a soft, clean cloth.
-
Page 23: Ceramic Special Care Instructions
Ceramic special Care Instructions Every care has been taken in the manufacture of this ceramic watch but due to the nature of the material used extra care should be taken. The ceramic although scratchproof is not shatterproof therefore care must be taken to avoid dropping or knocking the watch against a hard surface. - Page 24 lly, your watch is not affected by magnetic fields from household s such as television sets and stereo equipment. Ceramic special Care Instructions continued... Important • Ceramics will not wear over time • Ceramics are scratch-resistant • Ceramic is a naturally porous material •...
-
Page 25: Weee Directive
WEEE Directive The crossed-out wheeled bin indicates that used electrical and electronic equipment should not be mixed with general domestic waste. There is a separate collection point for these products. The objectives of the Community’s environment policy are, in particular, to preserve, protect and improve the quality of the environment, protect human health and utilise natural resources prudently and rationally. - Page 26 EU states may return their used electrical and electronic equipment to designated collection points free of charge. Equally return your product to an Accurist stockist or Accurist headquarters, who will see to the products disposal. Please contact your authority for further details.
- Page 27 Disposal information for business users EU Countries Please contact your Accurist dealer who will inform you about the ‘take back’ of products. Non EU Countries If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal.
-
Page 28: Bracelet Adjustment
Bracelet Adjustment The bracelet requires a small adjustment and the model has a Z-type clasp. 1. Depress the end of the spring bar on the centre clasp with a pin. 2. Relocate the spring bar in an alternative hole. - Page 29 The bracelet requires a significant adjustment or the model does not have a Z-type clasp. 1. Use the enclosed wrist gauge to measure and mark the size of your wrist. 2. Return the completed wrist gauge with your watch. 3. Follow the instructions in the After Sales Service section to return your watch for adjustment.
-
Page 30: International Service Agents
International Service Agents International Service Headquarters Accurist Watches Limited, Asher House, Blackburn Road, West Hampstead, London, NW6 1AW Tel: +44 (0)20 7447 3945, Fax: +44 (0)20 7447 3946 Netherlands Sabre Nederland B.V., Ellermanstraat 23, 1099 BX Amsterdam, The Netherlands Tel: 0031 20 692 8888, Fax: 0031 20 665 2184... - Page 31 watch is not affected by magnetic fields from household television sets and stereo equipment. International Service Agents continued... Cyprus Timeworx Ltd, 45 Andrea Demetriou St, Nicosia 2024, Cyprus Tel: 00357 22441328, Fax: 00357 22441329 Parsec Enterprises Inc, 7501 N.Harker Drive, Peoria , IL, 61615 Tel 1 800 359 2508...
- Page 32 Resistance to water Resistance to water Resistance to water INDICATIONS ON DIAL OR CASEBACK INDICATIONS ON DIAL OR CASEBACK INDICATIONS ON DIAL OR CASEBACK LIGHT SPRAY, LIGHT SPRAY LIGHT SPRAY, DIAL CASEBACK PERSPIRATION, SWIMMING DIAL CASEBACK PERSPIRATIO DIAL CASEBACK PERSPIRATION, LIGHT RAIN SWIMMING ETC...
-
Page 33: Resistance To Water
ces such as television sets and stereo equipment. Resistance to water Resistance to water continued... INDICATIONS ON DIAL OR CASEBACK INDICATIONS ON DIAL OR CASEBACK LIGHT SPRAY, LIGHT SPRAY, DIAL CASEBACK PERSPIRATION, SKIN DIVING: SWIMMING SCUBA DIAL CASEBACK PERSPIRATION, LIGHT RAIN DIVING WITHOUT ETC... - Page 34 from strong magnets s not affected by magnetic fields from household ion sets and stereo equipment. Resistance to water continued... IMPORTANT - NEVER PULL OUT THE CROWN WHEN THE WATCH IS WET. • Tighten screwlock crown completely. • Water resistance is not a permenant property. We strongly recommend you return your watch for resealing every 4 - 5 years and/or when changing batteries.
-
Page 35: Accurist Guarantee
The terms of this guarantee provide rights that are in addition to your statutory rights and do not in any way limit or otherwise affect those statutory rights. Your Accurist watch is guaranteed for 3 years from the date of original retail purchase against any malfunction of the watch movement due to defective materials or workmanship. - Page 36 We will, at our option, repair or replace your watch with a model of similar appearance or value. After the expiry of this guarantee the Accurist Service Centre and International Service Agents are at your complete disposal. We will be pleased to quote for routine maintenance, oiling or repair of your watch by our factory trained staff of experts.
-
Page 37: After Sales Service
After Sales Service Each Accurist watch comes with a lifetime commitment to quality after sales service. Our award winning customer service team are dedicated to providing expert servicing from bracelet adjustments to full overhaul. We pride ourselves in identifying our customer's requirements and reacting to their individual needs.
