Gateway FPD1960 SERVICE MANUAL 19” LCD MONITOR FPD1960 THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY. EVERY REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE CANNOT GUARANTEE THE ACCURACY OF THIS INFORMATION AFTER THE DATE OF PUBLICATION AND DISCLAIMS RELIABILITY FOR...
Gateway FPD1960 2. LCD MONITOR DESCRIPTION The LCD MONITOR will contain a main board, a power board and two keypad boards which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage.
Gateway FPD1960 3. OPERATING INSTRUCTIONS 3.1 GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located in the side of the monitor. By changing these settings, the picture can be adjusted to your personal preferences.
Gateway FPD1960 POWER Power On / Off Power On / Off 3.3 ADJUSTING THE PICTURE Adjustment steps: 1. Press the MENU-button to activate the OSD window. 2. Press < or > to select the desired function. 3. Press the MENU-button to select the function that you want to adjust.
Page 8
Gateway FPD1960 Gamma adjustment Moves the display image left and right. Moves the display image up and down. Adjust picture Clock to reduce Vertical-Line noise. Adjust Picture Phase reduce Horizontal-Line noise.
Page 9
Gateway FPD1960 Customizes the color levels. Change the language of the OSD. Change Brightness modes between Day Mode and Nite Mode. Displays screen resolution , the current input mode, and the OSD version. Resets the monitor to its factory settings.
Gateway FPD1960 4. INPUT/OUTPUT SPECIFICATION 4.1 INPUT SIGANAL CONNECTOR 1. D-SUB connector PIN NO. DESCRIPTION PI N NO. DESCRIPTION Red Video No Pin! Green Video Ground Blue Video Ground Ground DDC-Serial Data DDC-Return H-Sync Red Ground V-Sync Green Return DDC-Serial Clock...
Gateway FPD1960 5. BLOCK DIAGRAM 5.1 MONITOR EXPLODED VIEW Part Name Part Number Part Name Part Number LEFT PLATE 23G3155-915-9A BASE 34G6324-L-B BEZEL 34G6325APC-B BASE PLATE 15G6276-1 HOLD BRACKET-L 15G6295-1 RUBBER FOOT PANEL 750GLH90E13-21 HINGE 37G6045-3 METAL COVER 15G6274-1 NECK BRACKET...
Page 16
Gateway FPD1960 1) MCU initializes. 2) Is the EPROM blank? 3) Program the EPROM by default values. 4) Get the PWM value of brightness from EPROM. 5) Is the power key pressed? 6) Clear all global flags. 7) Are the AUTO and SELECT keys pressed? 8) Enter factory mode.
Gateway FPD1960 8. MAINTAINABILITY 8.1 EQUIPMENTS AND TOOLS REQUIREMENT Voltmeter. Oscilloscope. Pattern Generator. DDC Tool with an IBM Compatible Computer. Alignment Tool. LCD Color Analyzer. Service Manual. User Manual.
Gateway FPD1960 8.2 TROUBLE SHOOTING 8.2.1 Main Board No power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the Adapter/Inverter section Measure U602 PIN2=1.8V U601 PIN2=3.3V...
Page 30
Gateway FPD1960 No picture (LED orange) No picture Measure U602 PIN2=1.8V U601 PIN2=3.3V Replace U601, U602 X301 oscillate waveform is normal Replace X301 Whether the reset of the Scalar IC is useful? Check U302, C333, C329, ZD301 Check HS/VS from...
Page 31
Gateway FPD1960 White screen White screen Measure Q603 base X301 oscillate waveform is normal is low level? Replace X301 Check Q603, Q602 Check reset circuit of broken or CN501 solder? U401 is normal Check Correspondent Check Correspondent component. component. Replace PANEL...
Gateway FPD1960 8.2.2 Power/Inverter Board No power Check CN902 pin5, 6 = 12V Check AC line volt 110V or 220V Check AC input Check the voltage of C905(+) Check bridge rectified circuit and F901 circut Check start voltage for the pin3 of IC901...
Page 33
Gateway FPD1960 W / LED, No Backlight Check VDDA, ENA VDDA=4.75~5.25V;ENA>3V Check On/Off loop Circuit Connect TIMER (Pin3) to GND Check ENA(pin10), OVPT(pin7), CT(pin13), DRV1(pin1), DRV2(pin15) of IC801 Check half bridge power conversion Change IC801 circuit and Transformer output circuit...
Gateway FPD1960 8.2.3 Keypad Board OSD is unstable or not working Is Key Pad Board connecting normally? Connect Key Pad Board Replace Button Switch Is Button Switch normally? Is Key Pad Board normally? Replace Key Pad Board Check Main Board...
6500 color temp. parameter is x = 313±30, y = 329 ±30, Y =180 cd/m 3. Into factory mode of Gateway FPD1960 Turn on power, press the MENU button, pull out the power cord, and then plug the power cord. Then the factory OSD will be at the left top of the panel.
