Audio In

microphone you will need to boost the levels with a pre-amp first.
The Input Level knob is recessed so that it does not get in the way. Just push on the knob
and it will pop out for adjustment. When finished, just push it back in.

Fine Tune

The Fine Tune knob provides precision adjustment of the oscillator pitch.
The 12 o'clock position corresponds to the default tuning (i.e. A=440Hz)
when you play the second rightmost A of the keyboard and the default
Octave is selected. The full range of the Fine Tuning knob is from about -2
semitones to +2 semitones. The Fine-tune knob is recessed to prevent it
from being bumped. Just press the knob and it will pop out, allowing for
easy adjustment.

Audio Outputs

Connect the Line Out jack to an audio mixer, a computer's sound card, or
directly to an audio amplifier using a ¼" mono cable. You can connect a
pair of ear buds or headphones to Phones output. The Master Volume
knob on the front panel controls the output level of both these jacks.

CV / GATE I/O

The MicroBrute also connects with other analog devices (analog synthesizer, analog
step sequencer, etc.) through a CV/GATE interface where CV means Control Voltage.
The Gate In 1/8" jack allows other analog devices to trigger the MicroBrute envelopes.
The main MicroBrute functions (i.e., filter cutoff, and oscillator pitch) are controlled by
the Cutoff and Pitch jacks in the Mod Matrix.
Arturia Microbrute User's Manual
The Input Level potentiometer adjusts the amount of an external
audio source (guitar, synth, drum machine, etc.) that can be
plugged into the MicroBrute signal chain via the rear panel Audio
Input jack. This makes it possible to process an external audio signal
with the filter and amplifier; also note that this signal can trigger the
envelopes. NOTE: this is a line level input. To use this with a guitar or
