2X8 HDMI 1.3 Extender / Splitter over
Single CAT5/6
Model #: HDM-C5SP-8SRSR
© 2009 Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. ("Avenview") products. Avenview makes no representations or warranties with
respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any
time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in
Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products
www.avenview.com
1
Advertisement
Table of Contents
Related Manuals for Avenview HDM-C5SP-8SRSR
Summary of Contents for Avenview HDM-C5SP-8SRSR
- Page 1 No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products...
-
Page 2: Table Of Contents
Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly prohibited. -
Page 3: Section 1: Getting Started
Removal, installation, and set-up service charges. Safety Instructions The Avenview HDM-C5SP-8SR HDMI 1.3 Extender / Splitter over CAT5 Cascading Distribution Amplifier have been tested for conformance to safety regulations and requirements, and have been certified for international use. However, like all electronic equipment’s, the HDM-C5SP-8SR should be used with care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 4: Regulatory Notices Federal Communications Commission (Fcc)
Introduction The Avenview HDM-C5SP-8SR HDMI 1.3 over Single CAT5 Cascading Distribution Amplifier provides the most flexible solution by which the high definition video and high quality audio can be transmitted to different locations over a long distance. The devices are cascadable, allowing you to extend HDMI compliant displays almost anywhere. - Page 5 www.avenview.com...
- Page 6 www.avenview.com...
-
Page 7: Package Contents
Use the DC power adapter with correct specifications. If inappropriate power supply is used then it may cause a fire. Do not twist or pull by force ends of the optical cable. It can cause malfunction. www.avenview.com... -
Page 8: Panel Description
5. HDMI Output over RJ45 6. HDMI Output (1 – 7) 7. Power Jack 1.7.2 Front Panel 1. LED indicator for HDMI output format Push button for HDMI output format switch LED indicator for input selection Push button for input selection www.avenview.com... -
Page 9: Dip Switch
In order to adapt the CAT5 cable, HDM-C5SP-8SR offers 8-level equalization control on the received HDMI signal level. 0-to-7 = strongest-to-weakest signal level for respective transmission length [long to short]. It is recommended to switch from 7 to 0 to find the optimal visual experience. www.avenview.com... -
Page 10: Hdmi Output Format Selection
TMDS Data1 Shield Pin 15 Pin 6 TMDS Data1– Pin 16 Pin 7 TMDS Data0+ Pin 17 DDC/CEC Ground Pin 8 TMDS Data0 Shield Pin 18 +5V Power Pin 9 TMDS Data0– Pin 19 Hot Plug Detect Pin 10 TMDS Clock+ www.avenview.com... -
Page 11: Installation
Installation To setup Avenview HDM-C5SP-8SR follow these steps for connecting to a device: 1. Connect Cat-5e cable if using any Cat-5e HDMI video transmitter as cascading source 2. Connect HDMI input to HDMI compliant sources (such as a Blu-ray Disc player) 3. - Page 12 Type of category cable Wiring Shielding CAT5 CAT5e CAT6 Unshielded (UTP) Solid Shielded (STP) Unshielded (UTP) Stranded Shielded (STP) Termination Please use EIA/TIA-568-B termination (T568B) at any time www.avenview.com...
-
Page 13: Section 2: Specifications
Dimensions (L x W x H) 17” x 6.2” x 1.8” Power Supply 5V 4A DC Power Consumption 13 Watt (max) Environmental Operating Temperature 32˚ ~ 104˚F (0˚ to 40˚C) Storage Temperature -4˚ ~ 140˚F (-20˚ ~ 60˚C) Relative Humidity 20~90% RH (no condensation) www.avenview.com... - Page 14 Disclaimer While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of...
