Summary of Contents for Tenda TWL542U
-
Page 2: Table Of Contents
Instruction Manual USB Wireless Adapter Table of Contents Chapter 1 Brief Introduction ······························································ 2 1.1 Features ··········································································· 2 1.2 Applications ······································································ 3 1.3 Product Kit········································································ 4 Chapter 2 Installation Guide ······························································ 5 Chapter 3 Usage of Configuration Utility ········································ 8 3.1 Network Status··································································... -
Page 3: Chapter 1 Brief Introduction
Instruction Manual USB Wireless Adapter Chapter 1 Brief Introduction Thanks for choosing TWL542U wireless adapter. It is a standard USB adapter that Compliant to USB1.1/2.0. It is an enhanced high-performance supporting high-speed wireless adapter at home, or at office. TWL542U wireless adapter is able to communicate with any 802.11b and 802.11g compliant products, supporting all Windows OS,... -
Page 4: Applications
LED indication: LED on steady means ready and blinks when connected; 1.2 Applications TWL542U wireless adapter offers a fast, reliable, cost-effective solution for wireless client access to the network in applications like these: 1. Remote access to corporate network information E-mail, file transfer and terminal emulation. -
Page 5: Product Kit
7. High security connection The secure wireless network can be installed quickly and provide flexibility. 1.3 Product Kit TWL542U wireless adapter comes with the following items. Please go through each item below. If any of listed items appears to be damaged or missing, please contact your local dealer. -
Page 6: Chapter 2 Installation Guide
2000 as an example, for the installation under other OS, please kindly refers to this manual with the system prompts accordingly); Step1 Insert TWL542U wireless adapter into a USB port of your computer, the Windows will auto-detect the USB wireless adapter and a Found New Hardware Wizard window will show up. - Page 7 Click Cancel and install the driver from the Installation CD, Step 2 Insert the CD into your CD ROM, Double click MY COMPUTER ＞Your CD ROM driver＞TWL542U folder, double click the icon. Step 3 Click Next at the prompt window Fig 2-2 Step4 Click Browse…...
- Page 8 Instruction Manual USB Wireless Adapter Fig 2-3 Step5 Loading Win2000 setup utility displays and then prompt the following dialog box, click Finish Fig 2-4 Then you can find the wireless connection icon as below at system tray.
-
Page 9: Chapter 3 Usage Of Configuration Utility
Instruction Manual USB Wireless Adapter Fig 2-5 Chapter 3 Usage of Configuration Utility All the functions of the wireless adapter are configurable and manageable with this utility. Click Start>Programs> Wireless LAN Utility> SiSCFG 3.1 Network Status... - Page 10 Instruction Manual USB Wireless Adapter Fig 3-1 Network Mode: Peer-to-Peer (Ad-hoc) Network allows access to a basic service group, i.e. peer-to-peer mode and AP access in not needed; Access Point (Infrastructure) Network allows access to an extended service group, i.e. access to AP. Network Authentication There 4 authentication types: Open System, Share, Auto and W PA-PSK;...
- Page 11 Instruction Manual USB Wireless Adapter Input the TKIP/AES key of the AP to log when the AP offers TKIP/AES encryption, click Connect to scan the AP to log SSID: SSID is the name of the AP to connect, you can also scan and find the available network TxRate: Transmission rate up to 54Mbps, Auto is recommended setting...
-
Page 12: Site Scan
Instruction Manual USB Wireless Adapter 3.2 Site Scan Display the name of the applicable network. Fig 3-2 3.3 Statistics Display the link state, connection signal strength and quality, date received and transmitted, etc. - Page 13 Instruction Manual USB Wireless Adapter Fig 3-3 3.4 Encryption You can encrypt the adapter with a key or disable the data...
-
Page 14: Encryption
Instruction Manual USB Wireless Adapter encryption. Fig 3-4 3.5 Info Displays the physical characters of the adapter, including the date,... - Page 15 Instruction Manual USB Wireless Adapter version of the driver, MAC address, IP address, etc. Click Advance to configure the power management; Fig 3-5...
-
Page 16: Profile
Instruction Manual USB Wireless Adapter 3.6 Profile Fig 3-6 The Profile field allows you to set values for all parameters by selecting a previously defined profile. To create the profile, go to the Profile field, type a profile name and set the corresponding parameters. If one of the profiles is no longer used, you may remove it by clicking the Delete button. - Page 17 Instruction Manual USB Wireless Adapter New: Create a new Profile and make the network settings. The general tab contains basic settings of a profile. Fig 3-7 Delete: To delete a selected existing Profile. Edit: To modify a selected Profile Add a profile: To save a configured profile Apply: To select a profile from the profile names and apply...
-
Page 18: Chapter 4 Specifications
Instruction Manual USB Wireless Adapter Chapter 4 ：Specifications Standard supported IEEE 802.11g, IEEE 802.11b Hardware Interface USB 1.1/2.0 Data security 64/128/bit WEP, WPA-PSK encryption Frequency Range 2.4～2.4835GHz 54Mbps, 48Mbps, 36Mbps, 24Mbps , 18Mbps, Transmit Rate 12Mbps, 9Mbps, 6Mbps, 11Mbps, 5.5Mbps, 2Mbps, 1Mbps Data modulation CCK and OFDM...
