Instruction Manual TWL54/108C Wireless Adapter
Table of Contents
1
Advertisement
Table of Contents
Related Manuals for Tenda TWL54/108C
Summary of Contents for Tenda TWL54/108C
-
Page 1: Table Of Contents
Instruction Manual TWL54/108C Wireless Adapter Table of Contents Chapter 1 Brief Introduction················································· 2 1.1 Features····························································· 2 1.2 Applications ························································ 3 1.3 Product Kit ·························································· 4 Chapter 2 Installation Guide ················································ 5 Chapter 3 Configuration ···················································· 10 3.1 Current Status ·················································· 10 3.2 Profiles Management ·······································... -
Page 2: Chapter 1 Brief Introduction
CardBus adapter that fits into standard 32-bit CardBus slot. It is an enhanced high-performance supporting high-speed wireless networking at home, or at office. TWL54/108C CardBus wireless adapter is able to communicate with any 802.11b and 802.11g compliant products. 1.1 Features ... -
Page 3: Applications
Wireless connection, without any cost of cabling; 1.2 Applications TWL54/108C CardBus wireless adapter offers a fast, reliable, cost-effective solution for wireless client access to the network in applications like these: Remote access to corporate network information E-mail, file transfer and terminal emulation. - Page 4 Instruction Manual TWL54/108C Wireless Adapter be damaged or missing, please contact your local dealer. TWL54/108C CardBus wireless adapter TWL54/108C CardBus wireless adapter driver and utilities CD TWL54/108C CardBus wireless adapter Instruction Manual...
-
Page 5: Chapter 2 Installation Guide
OS, please kindly refers to this manual with the system prompts accordingly); Step1 Shut off your computer, insert TWL54/108C wireless adapter into an available CardBus slot, Restart your computer, the Windows will auto-detect the CardBus wireless adapter and a Found New Hardware Wizard window will show up;... - Page 6 Instruction Manual TWL54/108C Wireless Adapter double click the icon. Your CD ROM driver＞TWL54C&108C folder, Step 3 Choose the installation language (Here we choose English), Click Next. Step 4 Click Next at the prompt window Fig 2-2 Step 5 Choose I Accept for the terms of the software license agreement, then click Next.
- Page 7 Instruction Manual TWL54/108C Wireless Adapter Step 6 Choose Install Customer utilities and driver and click Next. Fig 2-4 S tep 7 Click Yes at the prompt window. Fig 2-5 Step 8 Click Browse to choose destination directory for the driver and configuration software, Click Next .
- Page 8 Instruction Manual TWL54/108C Wireless Adapter Step 9 Click Next. Fig 2-7 S tep 10 Click OK at the prompt window. Fig 2-8 S tep 11 Click Yes at the Digital signature not found window. Fig 2-9...
- Page 9 Instruction Manual TWL54/108C Wireless Adapter Step 12 Choose Yes, I want to restart my computer now, Click Finish, System will reboot. Fig 2-10 Check the installation: Right click My Computer from Desktop, select Properties, go to the Hardware tab and click the Device Manager button to see if any exclamation mark appears next to the AR5005GS Wireless Network Adapter.
-
Page 10: Chapter 3 Configuration
Start->programs->Atheros->Atheros customer utilities or simply double click Atheros customer utilities at the desktop. 3.1 Current Status This is to display the working status of TWL54/108C CardBus wireless adapter: Link Status, Wireless Mode, Network Type, Server-based Authentication, Signal Strength, IP, Current Channel, type of encryption, etc. -
Page 11: Profiles Management
Instruction Manual TWL54/108C Wireless Adapter 3.2 Profile Management Profile The Profile field allows you to set values for all parameters by selecting a previously defined profile. To create the profile, go to the Profile field, type a profile name and set the corresponding parameters. If one of the profiles is no longer used, you may remove it by clicking the Delete button. - Page 12 Instruction Manual TWL54/108C Wireless Adapter Fig 3-4 Security Security settings of connection. You should know the encryption and the key of the AP to connect, e.g.: if the encryption type of the AP to connect is WEP of 64-bit hexadecimal, default key is 1 and the key is 1231231230, you should choose Shared key (Static WEP) and then Configure according to the figure below and click OK.
- Page 13 Wireless Modes: 54Mbps,11Mbps, Super G, eXtended Range (XR), QoS (Super G not applicable for TWL54C) ; Network Type: There are 2 network types for the TWL54/108C CardBus wireless adapter to operate. If you need to access company network or Internet via Access Point, select "Infrastructure". If standard "802.11 Ad-Hoc"...
-
Page 14: Diagnoses
Instruction Manual TWL54/108C Wireless Adapter Fig 3-8 Note: Channel can only be configured under Ad hoc network type; Modify: To modify a selected Profile; Delete: To delete an existing Profile; Activate: To activate the connection of the Profile; Input: To input a saved Profile;... - Page 15 Instruction Manual TWL54/108C Wireless Adapter This part includes info about data receiving and transmission Adapter Information displays detailed info of the wireless adaptor Advanced Statistics displays the detailed info of this part. Fig 3-10 Fig 3-11 Fig 3-12...
-
Page 16: Chapter 4 Specifications
Instruction Manual TWL54/108C Wireless Adapter Chapter 4 Specifications Standard and protocols IEEE 802.11g, IEEE 802.11b CSMA/CA supported Data security 64/128/bit WEP, WPA-PSK encryption Frequency Range 2.4～2.4835GHz 108/54Mbps, 48Mbps, 36Mbps, 24Mbps , Transmission Rate 18Mbps, 12Mbps, 9Mbps, 6Mbps, 11Mbps, 5.5Mbps, 2Mbps, 1Mbps...
