Jobsite AB50-X2 Installation & User Manual

Stereo amplifier / automated switcher for powering television sound through distributed audio speakers.
Hide thumbs

Advertisement

INSTALLATION & USER GUIDE
For Powering Television
Sound Through Distributed
Audio Speakers
AB50-X2
STEREO AMPLIFIER / AUTOMATED SWITCHER

Advertisement

   Also See for Jobsite JobSite AB50-X2

   Related Manuals for Jobsite JobSite AB50-X2

   Summary of Contents for Jobsite JobSite AB50-X2

  • Page 1

    INSTALLATION & USER GUIDE For Powering Television Sound Through Distributed Audio Speakers AB50-X2 STEREO AMPLIFIER / AUTOMATED SWITCHER...

  • Page 2: Table Of Contents

    AB50-X2 STEREO AMPLIFIER / AUTOMATED SWITCHER TABLE OF CONTENTS Features...1 Product Overview...2 Package Contents ...4 Preparing for Installation...4 Installation...4 Troubleshooting ...6 Specifications ...7 Warranty...7...

  • Page 3: Features

    FEATURES Compact stereo amplifier with 50 watts per channel Automatically switches between either one or two pairs of speakers Stable into low impedance loads (4 ohms) CE, CSA E65 UL6500 approved Installation friendly design: 12V DC control output Output gain control...

  • Page 4: Product Overview

    PRODUCT OVERVIEW a) AC IN – Removable three-prong IEC compatible power cord. b) Current Sensing AC Outlet – AB50-X2 will activate and switch inputs when it senses a current draw from a connected device. c) Voltage Trigger IN – 3.5mm mini-phone jack. AB50-X2 will activate and switch inputs when 3-30 volts AC or DC is present.

  • Page 5

    Figure 1 AB50-X2 INPUT DUAL INPUT 2 CHANNEL AMPLIFIER SPEAKER A SPEAKER B LEVEL TRIGGERS 3-30V AC/DC 12VDC/ INPUT OUTPUT Figure 2...

  • Page 6: Package Contents

    PACKAGE CONTENTS AB50-X2 x 1 Removable AC power cord x 1 Snap and lock removable speaker connectors x 4 Self adhesive rubber feet x 4 PREPARING FOR INSTALLATION The local TV cables, Multizone Receiver cables and Speaker cables must reach the proposed location of the AB50-X2.

  • Page 7

    6. Insert each wire into the appropriate hole and snap down the locking tabs. 7. Insert the smooth side of the connector plug into the smooth side of the AB50-X2 socket. 8. Connect the variable line level output of the TV to the RCA terminals labeled INPUT.

  • Page 8: Troubleshooting

    INSTALLATION DIAGRAM TROUBLESHOOTING AB50-X2 will not power up Check to see that the AB50-X2 is plugged into an unswitched outlet. Check to see that the POWER/ACTIVE LED is lit. AB50-X2 will not activate (Current Sense Mode) AB50-X2 Make sure that the TV is plugged into the sensed To Current Sensing Outlet outlet on the AB50-X2.

  • Page 9: Specifications

    8" wide x 2-1/4" high (including feet) x 7-1/2" deep Warranty: 2 years limited LIMITED WARRANTY JobSite Systems (“JOBSITE”), a Niles Audio Corporation company, warrants its passive products (those not requiring AC or battery power) to the original purchaser to be free of manufacturing defects in material and workmanship for a period of ten years from date of purchase.

  • Page 10

    JOBSITE warrants its active products (those requiring AC or battery power) to the original purchaser to be free of manufacturing defects in material and workmanship for a period of two years from date of purchase. This Warranty is subject to the following additional conditions and limitations.

  • Page 11

    This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. For the name of the nearest authorized JOBSITE wholesale distributor, contact: JobSite Systems 12331 S.W. 130 Street, Miami, Florida 33186 WWW.JOBSITESYSTEMS.COM...

  • Page 12

    WWW.JOBSITESYSTEMS.COM © 2004 JobSite Systems. All rights reserved. JobSite, Pure Custom and Niles are registered trademarks of Niles Audio Corporation and the JobSite Logo is a trademark of Niles Audio Corporation. All other trademarks are the property of their respective owners. Some JobSite products (or components thereof) are manufactured under one or more U.S.
