A s s e m b l y
G u i d e
T9250
T9450
AND
FOLDING TREADMILLS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T9250 and is the answer not in the manual?

Questions and answers

Related Manuals for Vision Fitness T9250

Summary of Contents for Vision Fitness T9250

  • Page 1 A s s e m b l y G u i d e T9250 T9450 FOLDING TREADMILLS...
  • Page 2 A s s e m b l y G u i d e T9250 AND T9450 FOLDING TREADMILLS To avoid possible damage to this Folding Treadmill, please follow these assembly steps in the correct order. Before proceeding though, find your new Folding Treadmill’s 2 serial numbers, located on the underside of the main frame and on the bottom of the...
  • Page 3 TOOLS, HARDWARE, & PARTS INCLUDED 8mm Allen Wrench 5mm Allen Wrench Screwdriver PARTS BOX Water Bottle, Qty: 1 Safety Magnet Key, Qty: 1 Color-coded Hardware Bags...
  • Page 4 HARDWARE INCLUDED ORANGE BAG PINK BAG M8 x 20L Bolts M8 x 20L Bolts Quantity: 8 Quantity: 4 BLUE BAG Flathead pointed screw Quantity: 2 Flathead screw Quantity: 4 M8 x 135L Bolts Quantity: 4...
  • Page 5 ORANGE BAG STEP • Slide on the right and left console mast covers from the bottom of the console masts • Using the wire tie as a guide, slide the data cables (One small and one large) up from the bottom of the right console mast.
  • Page 6 PINK BAG STEP • Plug the large data cable into the large connector on the console. Plug STEP the small data cable into the small connector on the console. • Push the extra data cable into the console mast. Be sure not to pinch the data cables.
  • Page 7 MODEL CONFIGURATION & AUTO-CALIBRATION STEP Once the Treadmill is plugged in, you need to configure the Treadmill and perform auto-calibration for maximum performance. PREMIER and DELUXE CONSOLE: DO NOT STAND ON THE BELT WHEN PERFORMING THE AUTO-CALIBRATION Once the treadmill is plugged in, you will need to configure and run auto-calibration. With the safety key in place, turn the treadmill on.
  • Page 8 500 South CP Avenue • P.O. Box 280 • Lake Mills, WI 53551 toll free 800.335.4348 • phone 920.648.4090 • fax 920.648.3373 www.visionfitness.com ©2005 Vision Fitness. All Rights Reserved. 9.05 AG18.31PRD REV6...
