Controls

136
364
135
295
Fig. 1
8.1 System Pressure gauge
61 Reset button
135 Master switch
136 Central heating temperature control
170 Service valves in CH flow and return
171 Hot water
172 Gas isolation valve (open)
173 Cold water inlet
295 Identification sticker
310 Hot water temperature control
317 Display
363 Indicator lamp for "burner on"
364
Indicator lamp for "off/on"
365 "Chimney sweep" button
366 Service button
367 "ECO" button
400 Text Display
6 720 610 604 GB (03.06)
61 317 366 367
365
170
171
363 310 400
ECO
172 173
Controls
170
6 720 610 598 - 01.2O
8.1
11
