Power Amp - Two Notes TORPEDO C.A.B. User Manual

Configuring and using the TORPEDO C.A.B.
Module

Power Amp

Miking
EQ
120Hz (Guitar) or 50Hz (Bass)
Level
6.1 Power Amp
When using the TORPEDO C.A.B. with any kind of guitar/bass preamplifier, or even an electric
piano or a synthesizer, you need the color brought by the final stage of a traditional amplifier: the
power amplifier. Plug your device into the Input of the TORPEDO C.A.B. and enjoy the typical sound
of the Two Notes electrically accurate virtual tube power amplifier:
• Power Amp On: Activate the power amplifier simulation by turning this parameter "On" .
• Model: Choose the amplifier topology (Push Pull or Single Ended) and the tube type (6L6, EL34,
EL84 or KT88).
• Volume: Set up the Output volume of your virtual power amplifier.
• Presence: This setting affects the tube stage frequency (loudness).
• Depth: this setting affects the tube-stage frequency (bandwidth).
• Pentode/Triode: Select how the tube is used, either in triode or in pentode mode. Pentode
mode has more headroom and volume than triode.
22
Parameter
Value
On or Off
Model
8 models, from SE 6L6 to PP KT88
Volume
0 to 30dB
Presence
If Model PP: 0 to 100%
Depth
0 to 100%
Type
Triode or Pentode
On or Off
Cab/mic, User 0 to User 3 (in User bank, the options Mic, Dis-
Bank
tance, Center and Position are not available). 32 memory
slots for Cab/mic, 128 per User bank
Cab or File
Cabinet name or IR file name
Mic
Microphone name
Distance
0 to 100% (i.e. 0 to 10 feet)
0 to 100% (i.e. 0 to cabinet side, length depending on the
Center
real cabinet geometry)
Position
Back or Front
On or Off
Mode
Guitar or Bass
-20dB to +20dB
360Hz/120Hz
-20dB to +20dB
800Hz/360Hz
-20dB to +20dB
2KHz/800Hz
-20dB to +20dB
6KHz/4KHz
-20dB to +20dB
-95 to 0dB
Two Notes Audio Engineering TORPEDO C.A.B.
