Configuring and using the TORPEDO C.A.B.
Footswitch
A
B
Please refer to the SETUP mode section to assign special functions to A and B, the different func-
tions are listed below:
Designation
Function
None
Null function.
Change the current preset for the previous one. For example, if you are currently using
Preset -
the preset 10, this will load preset 09.
Preset +
Change the current preset for the next one.
Bypass
Bypass all processing, including OUT Level.
PA Bypass
Bypass the Power Amp simulation.
Cab Bypass
Bypass the cabinet-miking simulation.
Bypass the EQ. Activating the EQ while playing can be interesting to add a frequency
EQ Bypass
boost, for example.
Mute
Mute the Output
4 Three modes: PERFORM, EDIT & SETUP
You will find three different MODES in the TORPEDO C.A.B., giving you access to different parame-
ters:
1. Navigate through the 100 presets in PERFORM mode
2. Edit a preset in EDIT mode
3. Set up the global parameters of the machine in SETUP mode
To see and modify the various parameters, use the appropriate encoders whose function depends
on the current mode.

5 PERFORM mode

The PERFORM mode is the default mode you will see when first using the TORPEDO C.A.B.. The
following information will be displayed on the screen:
In this mode you can navigate the presets and set the Output volume of the machine. You will be
in this mode when playing without editing or modifying any parameter. This way you can have quick
access to the volume in case you have to quickly lower or increase the volume in any situation.
We recommend first looking for a preset that is close to the sound you have in mind, then tweak
the selected preset in EDIT mode.
20
Short click
PRESET -
PRESET +
• First line: preset name and number (between
01 and 00 corresponding to preset 100.
• Second line: Cabinet name (or IR name) and
Output volume (OUT LEVEL between -95dB
and +12dB).
Two Notes Audio Engineering
Long click
BYPASS
MUTE
TORPEDO C.A.B.
