SN4554 Getting Started Guide
1. Using the included black Ethernet cable, connect the RJ-45 Ethernet WAN port on your SN4554 (labeled
ETH), to an Ethernet hub or switch on the same network as your PC.
For details on the Ethernet port pinout and cables, refer to
D, "Port pin-outs"

Connecting the SN4554 to the power supply

1. Insert the barrel-type connector end of the AC power supply into the 5V DC, 1.0A port (see
page 15).
2. Verify that the AC power cord included with your router is compatible with local standards. If it is not,
refer to chapter 5,
patible power cord.
3. Connect the male end of the AC power supply power cord to an appropriate AC power outlet.
Installing the SN4554
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
DHCP
Server
PC
Figure 6. Connecting the SN4554 to the network via a hub or switch
on page 48.
The external router power supply automatically adjusts to accept
an input voltage from 100 to 240 VAC (50/60 Hz).
Verify that the proper voltage is present before plugging the
power cord into the receptacle. Failure to do so could result in
equipment damage.
"Contacting Patton for assistance"
3 • SN4554 installation
SN4554
ETH
port
Ethernet Hub
or Switch
Appendix C, "Cabling" on page 45 and
on page 34 to find out how to replace it with a com-
Appendix
figure 2 on
