READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT.
This manual provides important information on proper operation & maintenance. Every effort has been
made to ensure the accuracy of this manual. These instructions are not meant to cover every possible
condition and situation that may occur. We reserve the right to change this product at any time without
prior notice.
IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE, DO
NOT OPERATE THIS PRODUCT!
HAVE QUESTIONS OR PROBLEMS? DO NOT RETURN THIS PRODUCT TO THE
RETAILER - CONTACT CUSTOMER SERVICE.
If you experience a problem or need parts for this product, visit our website http://www.buffalotools.com
or call our customer help line at 1-888-287-6981, Monday-Friday, 8 AM - 4 PM Central Time. A copy of the sales
receipt is required.
FOR CONSUMER USE ONLY – NOT FOR PROFESSIONAL USE.
KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE WARRANTY FOR FUTURE
REFERENCE.
AWELD160 ARC Welder Assembly & Operating Instructions
AWELD160
ARC Welder w/Thermal Overload
Assembly & Operating Instructions
1
Advertisement
Table of Contents
Related Manuals for Buffalo Tools AWELD160
Summary of Contents for Buffalo Tools AWELD160
- Page 1 1-888-287-6981, Monday-Friday, 8 AM - 4 PM Central Time. A copy of the sales receipt is required. FOR CONSUMER USE ONLY – NOT FOR PROFESSIONAL USE. KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE WARRANTY FOR FUTURE REFERENCE. AWELD160 ARC Welder Assembly & Operating Instructions...
-
Page 2: Recognize Safety Symbols, Words And Labels
AC setting: 10 minutes shutdown; 3 minutes back on Cables Ground: 4 AWG, single insulation, 6’..Torch: 4 AWG, single insulation, 6’ Accessories Handle / Wire Brush /Face Shield Weight 39.6 lbs WARNING! Always wear eye, hearing, and breathing protection! AWELD160 ARC Welder Assembly & Operating Instructions... -
Page 3: Specifications
Wash hands after handling the cord. Touching the cords could expose you to lead, which is known in the State of California to cause cancer, birth defects and other reproductive harm. Keep children, and other distractions at a distance while operating power tools. AWELD160 ARC Welder Assembly & Operating Instructions... - Page 4 If using the power tool in an outside area with an extension cord, make sure the cord is rated for outdoor use. AWELD160 ARC Welder Assembly & Operating Instructions...
- Page 5 Keep construction debris out of vents and power button by blowing with compressed air. If compressed air is unavailable, use a soft bristle shop brush. Use only mild soap and a slightly damp cloth to clean the tool. AWELD160 ARC Welder Assembly & Operating Instructions...
-
Page 6: Specific Safety Rules And/Or Symbols
Size of Drill Bits, Grinding Wheels, etc. No Load Speed No-load Rotational Speed …/min Revolutions per Minute Revolutions, Surface Speed, Strokes, etc. per Minute 1,2,3… Ring Selector Settings Speed, Torque or Position Settings AWELD160 ARC Welder Assembly & Operating Instructions... -
Page 7: Package Contents
4. Know proper arc welding practices. Read and understand the manufacturer's instructions, as well as your employer's safety practices for arc welding. 5. Connect only to a code approved power source. Connect only to a grounding power source conforming to the National Electrical Code and Local Codes. AWELD160 ARC Welder Assembly & Operating Instructions... -
Page 8: Operation
The duty cycle defines the number of minutes, within a 10 minute period, during which a given Welder can safely produce a particular welding current. For example, this Welder has a 10% duty cycle at 160 Amps. AWELD160 ARC Welder Assembly & Operating Instructions... -
Page 9: Troubleshooting
If you must use an extension cord, be sure that the gauge is large enough to carry the amount of current necessary for your power tool. If not, your tool may experience a loss of power, excessive voltage drop or overheating. For example, the smaller the gauge number, the heavier the cord. AWELD160 ARC Welder Assembly & Operating Instructions... - Page 10 (AWELD160 201009) AWELD160 ARC Welder Assembly & Operating Instructions...
