  • Page 1 Hardware Description and Installation Manual...

  • Page 2: Regulatory Information

    Regulatory Information Before connecting the ipLDK-60 to the telephone network, you may be required to notify your local serving telephone company of your intention to use "customer provided equipment". You may further be required to provide any or all of...

  • Page 3: Revision History

    Hardware Description and Installation Manual Issue 1 JAN, 2007 Revision History ISSUE DATE CONTENTS OF CHANGES REMARK ISSUE 1.0 2007.01 Initial Release...

  • Page 4: Table Of Contents

    Hardware Description and Installation Manual Issue 1 JAN, 2007 Table of Contents 1 INTRODUCTION....................1 1.1 Important Safety Instructions ..................1 1.1.1 Safety Requirements ......................1 1.2 Precaution ........................2 1.2.1 Caution ..........................2 1.2.2 Disposal of Old Appliance ....................2 1.3 Manual Usage ........................3 1.4 The list of abbreviations....................4...

  • Page 5: Terminal Connection And Wiring Method

    Hardware Description and Installation Manual Issue 1 JAN, 2007 4.4 Installation of the CO Line & Extension Board ............29 4.4.1 CHB308 (3 CO Line and 8 Hybrid Interface Board) ............29 4.4.2 CSB316 (3 CO and 16 SLT Interface Board)..............41 4.4.3 SLIB8 (8 SLT Interface Board) ..................

  • Page 6: Introduction

    Hardware Description and Installation Manual Issue 1 INTRODUCTION JAN, 2007 1.1 Important Safety Instructions 1.1.1 Safety Requirements § When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and other personal injury, including the following: §...

  • Page 7: Precaution

    § Never attempt to insert wires, pins, etc. into the system. If the system does not operate properly, the equipment should be repaired by an authorized LG-Nortel service center. § Do not use benzene, paint thinner, or an abrasive powder to clean the KSU. Wipe it with a soft cloth only.

  • Page 8: Manual Usage

    Provides general information on the ipLDK-60 System, including the system specifications and capacity. Section 3. KSU Installation Describes detailed instructions for planning the installation site and procedures to install the ipLDK-60 System. Section 4. Board Installation Describes detailed instructions for installing components of the ipLDK-60 Board.

  • Page 9: The List Of Abbreviations

    Hardware Description and Installation Manual Issue 1 INTRODUCTION JAN, 2007 1.4 The list of abbreviations AAFU: Auto Attendant Function Unit AC: Alternating Current ACD: Automatic Call Distributor ADPCM: Adaptive Differential Pulse Code Modulation AIS : Alarm Indication Signal ARM7TDMI: a 16-bit/32-bit RISC CPU designed by ARM...
  • Page 10 Hardware Description and Installation Manual Issue 1 INTRODUCTION JAN, 2007 SMS: Short Message Service TD: Transmitted Data TDM: Time Division Multiplexing TE: Terminal Equipment TEGND: Terminal Equipment Ground TX: Transmitting signal UCD: User Call Distribution UL: Underwriters Laboratories UTP: Unshielded Twisted Pair...

  • Page 11: System Overview

    - Distinctive voice mail (ADPCM 32 Kbps) - Basic CID (CO & SLT) Function - 8 Poly internal MOH (13 Music sources) 2.1.1 System Connection Diagram The following Figure shows the components that make up the ipLDK-60 System: FIGURE 2.1.1 SYSTEM CONNECTION DIAGRAM...

  • Page 12: System Components

    Hardware Description and Installation Manual Issue 1 SYSTEM OVERVIEW JAN, 2007 2.2 System Components BASIC KSU ITEM OPTION BOARD DESCRIPTION Key Service Unit Power Supply Unit Main Board Main Board Unit (3CO, 1DKT and 7 Hybrid) CO and CO Line and DKT/SLT interface boards...
  • Page 13 Hardware Description and Installation Manual Issue 1 SYSTEM OVERVIEW JAN, 2007 EXPANSION KSU ITEM OPTION BOARD DESCRIPTION Key Service Unit Power Supply Unit Main Board EMBU Expansion Main Board Unit (3 CO and 8 Hybrid) CO and CO Line and DKT/SLT interface Boards...

  • Page 14: Specifications

    Hardware Description and Installation Manual Issue 1 SYSTEM OVERVIEW JAN, 2007 2.3 Specifications 2.3.1 General Specifications ITEM DESCRIPTION SPECIFICATION ARM7 TDMI core(32bit, 50MHz) Switching Device Custom Mixed-Signal ASIC Device Memory Back-up Duration 7years AC Voltage Input 100~240 +/- 10% Volt AC @47-63Hz...

  • Page 15: System Capacity

    Hardware Description and Installation Manual Issue 1 SYSTEM OVERVIEW JAN, 2007 2.3.2 System Capacity DESCRIPTION CAPACITY/BOARD TOTAL Time Slots CO Line Ports 3/MBU, 3/EMBU, 3/CHB308, 3/CSB316, Max. 36 8/VOIB, 30/PRHB8 Max Direct Station (DKT, SLT, 8/MBU, 8/EMBU, 8/CHB308, 16/CSB316, Max.

  • Page 16: Ksu Installation

    Anti-static precautions should be taken during installation. 3.1.2 Installation precautions The ipLDK-60 System is designed for wall mounting or a free –standing rack. Avoid installing in the following places: § In direct sunlight and hot, cold, or humid places. Temperature range = 0 to 40 §...

  • Page 17: Ksu Installation

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 3.2 KSU Installation 3.2.1 Unpacking Open the box and verify that the items shown in Figure 3.2.1 are included: Key Service Unit Mounting template Power cord CD manual...

  • Page 18: Ksu Exterior And Dimension

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 3.2.2 KSU Exterior and Dimension Figure 3.2.2 shows the exterior and dimensions of the KSU. FIGURE 3.2.2 KSU EXTERIOR AND DIMENSION...

  • Page 19: Opening And Closing The

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 3.2.3 Opening and Closing the Front Cover 3.2.3.1 Opening the Front Cover 1. Open the Cord cover and turn the screws counter-clockwise to loosen as shown in Figure 3.2.3.1.
  • Page 20 2. Then put the front cover down on the KSU in the direction of the arrow, as shown. 3. Turn the screws clockwise to tighten and close the Cord Cover as in the Figure. FIGURE 3.2.3.2 CLOSING THE FRONT COVER NOTE—Prior to operation, the front cover of the ipLDK-60 must be closed and the screws tightened.

  • Page 21: Power Supply Unit Installation

    Before installation, assure that the AC plug is not connected to an AC outlet. The PSU is located at the left in the KSU and is pre-installed in the ipLDK-60 KSU. The PSU provides three DC voltage power sources to MBU through the 7-pin connector, CN7.

  • Page 22: Frame Ground Connection

    1m (3.28ft). We dose not provide the ground wire. § Proper grounding is very important to protect the ipLDK-60 from external noise and to reduce the risk of electrocution in the event of lightning strike. §...

  • Page 23: External Backup Battery Installation

    JAN, 2007 3.2.6 External Backup Battery Installation In case of power failure, the external backup batteries automatically maintain uninterrupted power for the ipLDK-60 System. The external batteries must provide 24V DC; this is generally accomplished by connecting two 12V batteries in a series arrangement as shown: FIGURE 3.2.6 EXTERNAL BACKUP BATTERY INSTALLATION...

  • Page 24: Ksu Mounting

    BOARD INSTALLATION JAN, 2007 § Recommended battery capacity is 24V/20AH MF; the ipLDK-60 System should be able to operate more than 3 hours with batteries that are in good condition. § Carefully check the battery polarity with cable colors (Red and Blue) when connecting the battery to the System.

  • Page 25: Board Installation

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 Figure 3.2.7.1A Mounting Template 4.1 Installation of the Boards Prior to installing the Boards, the following should be considered: CAUTION § Power must be turned OFF. § To protect the System from static electricity, do not touch the boards. To discharge static, touch a grounded object, or wear a grounding strap.
  • Page 26 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 FIGURE 4.1 BOARD INSTALLATION...

  • Page 27: Main Board Unit (Mbu)

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.2 Main Board Unit (MBU) The Main Board Unit (MBU) controls communication between the peripheral interfaces, supervises all resources in the system, controls the gain adjustment of the PCM signal, generates the System tones, and manages System call processing.
  • Page 28 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 The MBU is installed in the KSU and provides various kinds of connectors RJ11 modular jacks for the connection of peripheral boards and miscellaneous functions (refer to Figure and Table).
  • Page 29 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.2.1 Modular Jack (MJ1 – MJ3) Pin Assignment 4.2.1.1 MBU MJ1 (CO) MBU MJ1–1,2,3 Connector PIN Number Signal Name RJ11 CO-T, CO-R 4.2.1.2 MBU MJ2 (Extension) MBU MJ2-1 (DKT ONLY)
  • Page 30 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.2.1.3 CN13 Pin Assignment (Relay Contact) CN13 CONNECTOR SIGNAL NAME 4 PIN Relay 1-pin1 Relay 1-pin2 Relay 2-pin1 Relay 2-pin2 4.2.1.4 MJ3 Pin Assignment (LAN) Connector Pin Number...

  • Page 31: Expansion Main Board Unit (Embu)

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.3 Expansion Main Board Unit (EMBU) The EMBU (shown Figure 4.3A) provides the following: § DKT and SLT Interface Circuits § Ring Generation circuit § External Relay contacts for LBC or General purpose §...
  • Page 32 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 The EMBU is installed in the KSU and provides various kinds of connectors and RJ11 modular jacks for the connection of peripheral boards and miscellaneous functions (refer to Figure 4.3B and Table).
  • Page 33 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.3.1 Modular Jack (MJ1 – MJ3) Pin Assignment 4.3.1.1 EMBU MJ1(CO) EMBU MJ1 – 1,2,3 CONNECTOR PIN NUMBER SIGNAL NAME RJ11 CO-T, CO-R EMBU MJ2 – 1,2,3,4,5,6,7,8 (EXTENSION)

  • Page 34: Installation Of The Co Line & Extension Board

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.4 Installation of the CO Line & Extension Board CONNECTOR BOARD LINE DESCRIPTION CABLE REMARK TYPE 3 CO Line and 8 DKT : 4 wire CHB308 3 CO and 8SLT or 8 DKT...
  • Page 35 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 FIGURE 3.2.7.1B KSU WALL MOUNTING...
  • Page 36 4.4.1.1 Rack Mounting To attach the ipLDK-60 System to the rack: 6. Attach the rack bracket to the bottom of the ipLDK-60 System as shown in Figure 3.2.7.2 and attach it to the System securely by tightening the screws clockwise.
  • Page 37 To use the ipLDK-60 System on a flat surface, do the following procedure: 8. To attach the rubber feet to the bottom of the ipLDK-60 System as shown in Figure 3.2.7.3, first remove the backing paper from the sticker on the rubber feet.

  • Page 38: Expansion Ksu Installation

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 FIGURE 3.2.7.3 DESKTOP MOUNTING 4.5 Expansion KSU Installation 4.5.1 Unpacking Open the box and verify that the items shown in Figure 3.3.1 are included: Mounting template Key Service Unit...
  • Page 39 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 Figure 3.3.1 Carton Contents...

  • Page 40: Connecting Expansion Ksu To Basic Ksu

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.5.2 Connecting Expansion KSU to Basic KSU 10. To connect, perform the following Steps: 11. Remove the cover plate of each KSU. 12. Use the link cable to connect the Basic KSU to the Expansion KSU.
  • Page 41 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 FIGURE 3.3.2 EXPANSION KSU TO BASIC KSU CONNECTION NOTE— § When AC Power was failed, the last SLT port on EMBU will be connected to CO1 automatically. §...

  • Page 42: Expansion Ksu Mounting

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.5.4 Expansion KSU Mounting NOTE— Do not make any connections between the BKSU and EKSU using link cable until they both have been properly installed to the Wall Mounting or Rack Mounting as applicable.
  • Page 43 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 FIGURE 3.3.3.1B EXPANSION KSU WALL MOUNTING NOTE—Be careful no t to drop the KSU.
  • Page 44 18. It is recommended to install the Expansion system very close in proximity to the Basic System. 19. Attach the rack bracket to the bottom of the ipLDK-60 system as shown in Figure 3.3.3.2A, and attach it to the System securely by tightening the screws clockwise.
  • Page 45 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 FIGURE 3.3.3.2B KSU RACK MOUNTING 4.5.4.3 Modular Jack (MJ1-MJ2) Pin Assignment CHB308 MJ1 – 1,2,3...

  • Page 46: Csb316 (3 Co And 16 Slt Interface Board)

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 CONNECTOR PIN NUMBER SIGNAL NAME RJ11 CO-T, CO-R CHB308 MJ2 – 1,2,3,4,5,6,7,8 (EXTENSION) CONNECTOR PIN NUMBER SIGNAL NAME RJ11 DKT-T SLT-T, SLT-R DKT-R 4.5.4.4 Add-On Board CMU50PR(Call Metering-50 Hz & Polarity Reversal Detection unit) The CMU50PR provides 3 channels Call Metering detection for 50Hz and provides 3 channels of Polarity Reversal Detection for call metering.
  • Page 47 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 FIGURE 4.4.2.1 CSB316 4.5.5.1 Modular Jack Pin Assignment CSB316 MJ1 – 1,2,3 CONNECTOR PIN NUMBER SIGNAL NAME RJ11 CO-T, CO-R CSB316 MJ2 – 1,2,3,4,5,6,7,8 CONNECTOR PIN NUMBER SIGNAL NAME...
  • Page 48 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 FIGURE 4.4.2.2 TERMINAL BLOCK TERMINAL SLT CONNECTOR PIN NUMBER SIGNAL NAME RJ11 TIP, RING 4.5.5.2 Add-On Board CMU50PR (Call Metering-50Hz and Polarity Detection Unit) The CMU50PR provides 3 Call Metering Detection for 50Hz and provides 3 channels of Polarity Reversal detection for call metering.

  • Page 49: Slib8 (8 Slt Interface Board)

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.5.6 SLIB8 (8 SLT Interface Board) The SLIB8 can be installed on the CHB308/CSB316/SLIB8(CN2) connector of the MBU or EMBU, and provides 8 possible SLT interfaces. It can generate FSK signals for outgoing Caller ID; DTMF signals for outgoing Caller ID.

  • Page 50: Voib (Voice Over Internet Protocol Board (4Ch))

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.5.7 VOIB (Voice over Internet protocol Board (4ch)) The VOIB can be installed on MBU and provided four VoIP channels. The length of the Ethernet cable should be less than 10 meters.
  • Page 51 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 LED indications Functions Remark Channel1 Seize indication LED (ON: Busy, OFF: Idle) Channel2 Seize indication LED (ON: Busy, OFF: Idle) Channel3 Seize indication LED (ON: Busy, OFF: Idle)

  • Page 52: Prhb8 (Pri And 8 Hybrid Interface Board)

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.5.8 PRHB8 (PRI and 8 Hybrid Interface Board) The PRI and 8 Hybrid interface Board(PRHB8) is based on the existing interface described in ITU-T Recommendations G.704, G.703 and G.823.
  • Page 53 Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 PRI PORT Connector Pin Number SIGNAL NAME RJ45 RX-T RX-R TX-T TX-R TX-R TX-R 7, 8 RJ11 PORT CONNECTOR PIN NUMBER SIGNAL NAME RJ11 DKT-T SLT-T SLT-R DKT-R...

  • Page 54: Other Board Installations

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.6 Other Board Installations 4.6.1 Voice Mail Interface Unit (VMIU)/ Auto Attendant Function Unit (AAFU) The Voice Mail Interface Unit (VMIU) can be installed on the VMIU/AAFU connector (CN5) of the MBU, and provides the capability for System announcements, ACD/UCD announcements, and User Greetings.

  • Page 55: Modem Function Unit (Modu)

    Hardware Description and Installation Manual Issue 1 BOARD INSTALLATION JAN, 2007 4.6.2 Modem Function Unit (MODU) MODU should be installed on the MODU connectors (CN4) of the MBU, and provides an analog modem connection. It supports Bell, ITU-T, V.34, V.32BIS, V.90 Protocol at a speed rate of 300bps up to 33Kbps, and automatic rate negotiation.

  • Page 56: Terminal Connection And Wiring Method

    TERMINAL CONNECTION AND WIRING METHOD JAN, 2007 5.1 Terminal and Door Phone Models Various types of digital terminals can be used with the ipLDK-60 MBU / EMBU / CHB308 / CSB316 / PRHB8 as listed in the Table and show below:...

  • Page 57: Terminal Cabling Distance

    Hardware Description and Installation Manual Issue 1 TERMINAL CONNECTION AND WIRING METHOD JAN, 2007 5.1.1 Terminal Cabling Distance FIGURE 5.1.1 TERMINAL CABLING DISTANCE...

  • Page 58: Basic Terminal Connection

    Hardware Description and Installation Manual Issue 1 TERMINAL CONNECTION AND WIRING METHOD JAN, 2007 5.1.2 Basic Terminal Connection 5.1.2.1 DKT and DSS The following illustrates how to connect the DKT to your System: FIGURE 5.1.2 DKT AND DSS CONNECTION...

  • Page 59: Connecting Additional Terminals

    Hardware Description and Installation Manual Issue 1 TERMINAL CONNECTION AND WIRING METHOD JAN, 2007 5.1.3 Connecting Additional Terminals The MBU provides connections for one external music source, one external page port, one relay contact, and an alarm detection input monitor through the PJ1 (RED, External MOH) and PJ2 (BLUE, External Page) audio jack and a MJ3 (RJ11 Modular Jack).

  • Page 60: Cable Wiring

    Hardware Description and Installation Manual Issue 1 TERMINAL CONNECTION AND WIRING METHOD JAN, 2007 5.2 Cable Wiring 5.2.1 Wall Mount Wiring To install wall mount wiring, perform the following Steps: 21. Ensure the BKSU and EKSU have been installed correctly.

  • Page 61: Rack Mount Wiring

    Hardware Description and Installation Manual Issue 1 TERMINAL CONNECTION AND WIRING METHOD JAN, 2007 5.2.2 Rack Mount Wiring 27. Ensure the BKSU and EKSU have been installed correctly. 28. Connect cables to the CO/STA port and the MOH/RS-232C ports as shown in Figure 5.2.2.

  • Page 62: Starting The Ipldk-60

    33. The DIP switch (SW2) should be turned ON prior to installing the MBU to protect the System data in case of power failure. Check the DIP switch (SW1) of the MBU to All ON. Plug the AC power cord into the ipLDK-60 System and AC outlet. Program the Nation Code (PGM100) as applicable. Reset the ipLDK-60 System.

  • Page 63: Basic Programming

    Issue 1 STARTING THE ipLDK-60 JAN, 2007 6.2 Basic Programming The ipLDK-60 System can be programmed to meet an individual customer’s needs. There are two ways to perform Admin Programming: § PC Admin – Refer to PC Admin Programming Manual §...

  • Page 64: Entering The Programming Mode

    Hardware Description and Installation Manual Issue 1 STARTING THE ipLDK-60 JAN, 2007 FIGURE 6.2.1.2 DESCRIPTION OF LIP-7024D BUTTONS 6.2.2 Entering the Programming Mode To enter programming mode, perform the following Steps: 34. Lift the Handset. Or 1. Press the [MON] button on the Admin Station; the ICM tone should be heard.

  • Page 65: Pre-Programming

    41. Press the [TRANS/PGM] button + PGM number (100) then [FLEX1] + 55 [Nation Code for Brazil]. 42. Press the [HOLD/SAVE] button to accept the change. 43. Now Rest ipLDK-60 to initialize Database for Nation. 44. Set the 4 pole (SW1) of the MBU OFF when the System operates normally, to protect programmed features.
  • Page 66 When registering board, if the 4 pole (SW1) of the MBU is on, the board is automatically registered. And while using ipLDK-60 System, in case of adding some of boards, if passively assigning those, you can use it. When the 4 pole...
  • Page 67 Hardware Description and Installation Manual Issue 1 STARTING THE ipLDK-60 JAN, 2007 SLOT DEFINITION SLOT NUMBER SLOT POSITION KINDS OF BOARDS Hybrid on BKSU HYBRID Optional extension board on BKSU HYBRID,SLIB8,SLIB16 Hybrid port on EKSU HYBRID Optional extension board on EKSU...
  • Page 68 Hardware Description and Installation Manual Issue 1 STARTING THE ipLDK-60 JAN, 2007 6.2.3.4 Numbering Plan Type (PGM 104) To program the Numbering Plan Type, perform the following: 56. Press the [TRANS/PGM] button + 104. 57. Enter the Numbering Plan Type (1 digit, refer to Table).
  • Page 69 Hardware Description and Installation Manual Issue 1 STARTING THE ipLDK-60 JAN, 2007 6.2.3.6 Flexible Numbering Plan (PGM 106-107) To program Flexible Numbering using PGM 106, perform the following Steps: 62. Press the [TRANS/PGM] button + 106. 63. Enter the desired code (refer to Table).
  • Page 70 Hardware Description and Installation Manual Issue 1 STARTING THE ipLDK-60 JAN, 2007 To program Flexible numbering using PGM 109, perform the following Steps: 68. Press the [TRANS/PGM] button + 109. 69. Enter the desired code (refer to Table). 70. Press the [HOLD/SAVE] button to accept changes.

  • Page 71: Troubleshooting

    Hardware Description and Installation Manual Issue 1 STARTING THE ipLDK-60 JAN, 2007 PROBLEM CAUSE/SYMPTOM SOLUTION Exchange the malfunctioning board for Power short circuit in some board(s) one in good working condition. SYSTEM POWER Dust each board with a dry cloth.
  • Page 72 Hardware Description and Installation Manual Issue 1 STARTING THE ipLDK-60 JAN, 2007...
