Summary of Contents for Mercedes-Benz E 300

  • Page 1 E 300 E-class E 320 E 430 Operator’s Manual E 55 AMG...

  • Page 2: Product Information

    We recommend using Mercedes-Benz original parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have subjected these parts to a special test in which their reliability, safety and their special suitability for Mercedes-Benz vehicles have been determined.
  • Page 3 Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To ensure your pleasure of ownership, and for your safety and that of your passengers, we ask you to make a small investment of your time: •...
  • Page 4 Important Notice for California Retail Buyers of Mercedes-Benz Automobiles Under California law you may be entitled to a replacement of your vehicle or a refund of the purchase price, if Mercedes-Benz of North America, Inc. or its authorized dealer fails to conform the vehicle to its express warranties after a reasonable number of repair attempts during the period of one year or 12 000 miles from original delivery of the vehicle.
  • Page 5 The Service Booklet describes all the necessary maintenance work which should be performed at regular intervals. Always have the Service Booklet with you when you take the vehicle to your authorized Mercedes-Benz dealer for service. The service advisor will record each service in the booklet for you.
  • Page 6 If there are any equipment details that are not shown or described in this Owner's Manual, your authorized Mercedes-Benz dealer will be glad to inform you of correct care and operating procedures.
  • Page 7 Approximately 30 days or 2 000 miles (2 000 km) prior to the next recommended service, the remaining distance or days are displayed in the multifunction indicator. See Flexible Service System (FSS) in Index. We strongly recommend that you have your vehicle serviced by your authorized Mercedes-Benz dealer, in accordance with the Service Booklet.
  • Page 8 Introduction Rear Passenger Compartment Steering Lock Adjustable Air Outlet Combination Switch Product information Car keys Headlamp Cleaning System Operator's manual Start Lock-out Exterior Lamp Switch Consumer Information Central Locking System Night Security Illumination Problems with your vehicle Radio Frequency and Inside Rear View Mirror Reporting Safety Defects Infrared Remote Control...
  • Page 9 Low Engine Oil Level Warning Lamp Bleeding of Diesel Fuel System Warranty Coverage Engine Oil Consumption Automatic Trans. Fluid Level Technical Data E 300 Diesel Fuel Reserve and Fuel Cap Placement Trunk Lamp E 320 Warning Spare Wheel, Vehicle Tools,...
  • Page 10 Instruments and Controls For more detailed descriptions see Index For adjustment of air outlets, refer to Automatic Climate Control (see Index). Hazard warning flasher switch Side defroster outlet Central locking switch Indicator lamp for antitheft alarm system Side air outlet, adjustable Right front seat heater switch Air volume control for side outlet Glove box (illuminated with key in steering lock position 1 or 2)
  • Page 12 Left turn signal indicator lamp (green) ASR, ESP or ETS warning lamp (yellow). See Index Speedometer Trip odometer. See Index Outside temperature indicator. See Index Main odometer Clock. See Index 8-11 Multifunction indicator, or FSS indicator. See Index Right turn signal indicator lamp (green) Tachometer.
  • Page 13 Multifunction Indicator Engine oil level low. See Index If a malfunction occurs, the appropriate warning symbol appears, Coolant level low. See Index supplemented by a message in the field normally occupied by the displays for outside temperature, odometers, and clock. Battery not being charged properly.
  • Page 14 Additional Lamp Symbols in the Instrument Function Indicator Lamps in the Instrument Cluster Cluster, and Warnings in the Multifunction Indicator Fasten seat belts. See Index. High beam Brake fluid low (except Canada). Parking brake engaged. Preglow (Diesel engine only). See Index See Index.
  • Page 15 Catalytic Converter Caution! Warning! Your Mercedes-Benz is equipped with To prevent damage to the catalytic As with any vehicle, do not idle, park monolithic type catalytic converters, an converters, use only premium unleaded or operate this vehicle in areas where important element in conjunction with gasoline in this vehicle.
  • Page 16 Starting recommend that an engine block heater be installed. Your authorized Do not depress accelerator. Mercedes-Benz dealer will advise you on this subject. Briefly turn electronic key in steering lock clockwise to the stop and release. The starter will engage until the engine is running.
  • Page 17 Starting preglow system is defective and should be repaired at your authorized Turn electronic key to steering lock Mercedes-Benz dealer at the earliest position 2. Preglow indicator lamp possible date. should come on with cold engine. The preglow process starts. When the...
  • Page 18 Mercedes-Benz dealer. towed to the nearest Mercedes-Benz or tire dealer for repairs. It can also result in the brakes Install only brake pads and brake...
  • Page 19 Caution! Specified tire pressures must be maintained. This applies particularly if When driving down long and steep the tires are subjected to high loads grades, relieve the load on the brakes (e.g. high speeds, heavy loads, high by shifting into a lower gear to use the ambient temperatures).
  • Page 20 Despite the tire rating, local speed limits should be obeyed. Use prudent The safe speed on a wet, snow covered E 300 Turbodiesel, E 320 and E 430: driving speeds appropriate to prevailing or icy road is always lower than on a Your vehicle is factory equipped with conditions.
  • Page 21 Parking Winter Driving Instructions If the vehicle is parked after being driven on salt treated roads, the braking Warning! The most important rule for slippery or efficiency should be tested as soon as icy roads is to drive sensibly and to possible after driving is resumed while To reduce the risk of personal injury avoid abrupt acceleration, braking and...
  • Page 22 Mercedes-Benz Limited Warranty.

  • Page 23: Operation

    Operation...
  • Page 24 Air volume control for center air outlets, turn wheel up to open. Air volume control for side air outlet. To open air outlets: Turn wheel to position To open defroster outlets: Turn wheel to position Center air outlet, adjustable Side air outlet, adjustable Side defroster outlets Display and Controls The automatic climate control removes...
  • Page 25 Basic Setting - Automatic Mode Press left and right button for automatic mode. Simultaneously press both buttons for temperature setting of 72°F. Air volume and distribution are controlled automatically. This setting can be used all year Display and Controls Activated charcoal filter around.
  • Page 26 Special Settings Rear Window Defroster Air Distribution (use only for short duration) Turn electronic key in steering lock to Defogging Windows position 2. Switch off button. To select, press button. Press button repeatedly until the To cancel, press button again. requested symbol is displayed.
  • Page 27 Air Recirculation Dust Filter Activated Charcoal Filter This mode can be selected to temporarily Nearly all dust particles and pollen are To select, press button. reduce the entry of annoying odors or filtered out before outside air enters the To cancel, press button again.
  • Page 28 Residual Engine Heat Utilization Front Center Console Compartment Ventilation With the engine switched off, it is possible to continue heating the interior The front center console compartment for a short while. has its own air outlet. Air volume and distribution are To open: Push lever down.
  • Page 29 Car Keys The mechanical key (2) can be removed by sliding it out of the remote Included with your vehicle are: control. To do so, move lock (3) in direction of arrow and slide the • 2 electronic main keys with mechanical key (2) in direction of integrated radio frequency and arrow (5).
  • Page 30 In case the engine cannot be started, compartment locks. the system is not operational. Contact an authorized Mercedes-Benz dealer or To use the mechanical key (2), remove call 1-800-FOR-MERCedes. it from its electronic reserve key (1).
  • Page 31 Central Locking System Radio Frequency and Infrared Remote Control The electronic main key has an integrated radio frequency and infrared remote control. Due to the extended operational range of the remote control, it could be possible to unintentionally lock or unlock the vehicle by pressing the transmit button.
  • Page 32 Press transmit button twice to Locking: unlock doors, fuel filler flap, and trunk. Press transmit button once. All Global unlocking mode -Press turn signal lamps blink three times to transmit button once to unlock indicate that the vehicle is locked. doors, fuel filler flap, and trunk.
  • Page 33 Opening the Trunk Opening and Closing Windows from Warning! Outside A minimum height clearance of 5.9 ft Never operate the windows if there is (1.8 m) is required to open the trunk Aim transmitter eye (5) of remote the possibility of anyone being lid.
  • Page 34 Note: Mechanical Keys For operation in the USA only: This The entire vehicle may be locked or device complies with Part 15 of the unlocked by using either the FCC Rules. Operation is subject to the mechanical key in driver's door or following two conditions: trunk lock, or central locking switch located in center console.
  • Page 35 If the car has previously been locked from the outside, only the door being opened from the inside will unlock, and the alarm will come on. The other door, the trunk lid and fuel filler flap remain locked. Notes: In case of a malfunction in the central locking system the doors can be locked and unlocked individually.
  • Page 36 The doors and trunk can only be Automatic Central Locking locked with the central locking switch, if both doors are closed. The central locking switch also operates the automatic central locking. If the vehicle was previously locked with the remote control or mechanical To activate: key, the doors and trunk cannot be unlocked with the central locking...
  • Page 37 Notes: Important! Emergency Unlocking in Case of Accident If doors are unlocked with the central When towing the vehicle, or with the locking switch after activating the vehicle on a dynamometer test stand, The doors unlock automatically a short automatic central locking, and neither please, note the following: time after an accident (this is intended door is opened, then the doors remain...
  • Page 38 To deny any unauthorized person access to the trunk, lock it separately. Leave only the electronic main key less its mechanical key with the vehicle. Notes: In case of a malfunction in the central locking system the trunk can be locked and unlocked individually.
  • Page 39 When locking doors or trunk, turn Warning! mechanical key in door lock or trunk lock to position 3 and hold. The Never operate the windows or windows and the sliding/popup roof sliding/pop-up roof if there is the begin to close automatically after possibility of anyone being harmed approximately 1 second.
  • Page 40 Antitheft Alarm System The alarm will last approximately 2 minutes in the form of flashing exterior The antitheft alarm is automatically lamps. At the same time an alarm will armed or disarmed with the remote sound for 30 seconds. The alarm will control or any of your vehicle's stay on even if the activating element mechanical keys by locking or...
  • Page 41 Once the alarm system has been armed, To do so, turn electronic key in the exterior vehicle lamps will flash and steering lock to position 1 or 0, or an alarm will sound when someone remove electronic key from steering attempts to raise the vehicle.
  • Page 42 Power Seats, Front Turn electronic key in steering lock to position 1 or 2 (with the driver's or Warning! passenger's door open, the power seats can also be operated with the electronic Do not adjust the driver's seat while key removed or in steering lock driving.
  • Page 43 Synchronizing Head Restraints restraint/steering wheel and exterior rear view mirrors can be programmed If the power supply was interrupted into memory by pushing first memory (battery disconnected or empty), the button (6) and then "2", respectively "3". power seats and head restraints are no longer adjusted automatically.
  • Page 44 Mercedes-Benz child restraint system, which is seat back angle to insure adequate authorized BabySmart™ compatible properly secured with the vehicle's control, reach, operation, and comfort.
  • Page 45 Multicontour Seat (optional) The seat cushion movement and amount of backrest cushion height and Seat cushion depth curvature can be continuously varied Backrest bottom with regulators (1, 2 and 3) after Backrest center turning the electronic key in steering Side bolster adjustment lock to position 2.
  • Page 46 Heated Seats (optional) Note: The front seat heaters can be When in operation, the seat heater switched on with the electronic key in consumes a large amount of electrical steering lock positions 1 or 2. power. It is not advisable to use the seat heater longer than necessary.

  • Page 47: Adjustable Steering Wheel

    Note: The steering wheel position can be stored in memory together with the seat/head restraint and exterior rear view mirror positions, see Index. Warning! Do not adjust the steering wheel while driving. Adjusting the steering wheel while driving could cause the driver to lose control of the vehicle Armrest, Rear Bench Adjustable Steering Wheel...
  • Page 48 Head Restraints, Rear Placing head restraints upright: Cargo Tie-Down Hooks Pull head restraint forward until it Folding head restraints backward (with locks in position. Inside the trunk are four cargo tie-down engine running) Angle of head restraints: hooks. The head restraint angle can be Press symbol-side of rocker switch to adjusted manually.
  • Page 49 Mercedes-Benz tensioning retractors for the front seat restraint. authorized BabySmart™ compatible...
  • Page 50 Seat Belt Warning System With the electronic key in steering lock position 2, a warning sounds for a short time if the driver's seat belt is not fastened. Warning! Failure to wear and properly fasten and position your seat belt greatly increases your risk of injuries and their likely severity in an accident.

  • Page 51: Use Seat Belts Properly

    Warning! USE SEAT BELTS PROPERLY. • Each occupant should wear their seat belt at all times, because seat belts help reduce the likelihood of and potential severity of injuries in accidents, including rollovers. "SRS" (driver airbag, front passenger airbag, side impact airbags), "ETR"...

  • Page 52: Use Child Restraints Properly

    If the belt is never ride in the front seat, except in instructions. positioned across your abdomen, a Mercedes-Benz authorized it could cause serious injuries in a BabySmart™ compatible child seat, A child's risk of serious or fatal crash.
  • Page 53 Special child seats, designed for use System will ONLY work with a special otherwise-do not transport child re- with the Mercedes-Benz system and seat designed to operate with it. It will straints on the front passenger seat available at any authorized Mercedes- not work with seats which are not until the system has been repaired.
  • Page 54 Supplemental Restraint System (SRS) Seat belt fastened The emergency tensioning retractors are designed to activate only when the The term Supplemental Restraint System • first threshold exceeded: ETR activates seat belts are fastened during frontal means that airbags are intended as a •...
  • Page 55 In conjunction with wearing the seat belts with emergency tensioning retractors, the airbags can provide increased protection for the driver and front passenger in certain major frontal (for front airbags), and side impacts (for side impact airbags).The operational readiness of the airbag system is verified by the indicator lamp "SRS"...
  • Page 56 "SRS" is indicated as outlined above, the "SRS" may not be operational. For your safety, we strongly recommend that you visit an authorized Mercedes-Benz dealer Side impact airbag, front the crash-sensor are detected and indicated (the "SRS" indicator lamp immediately to have the system...
  • Page 57 In cases of other frontal impacts, should be inspected by an authorized conjunction with a properly positioned angled impacts, roll-overs, other side Mercedes-Benz dealer at that time and fastenend seat belt. impacts, rear collisions, or other and replaced when necessary.
  • Page 58 Keep you in a safe occupied. severity of injury. Mercedes-Benz distance from the airbag: • Children 12 years old and under encourages you to replace deployed...
  • Page 59 • An airbag system component with an "SRS" by alerting him to the Mercedes-Benz dealer. within the steering wheel gets applicable section in the Owner's hot after the airbag has inflated. Manual.
  • Page 60 Infant and Child Restraint Warning! Important! Systems Never release the seat belt buckle The use of infant or child restraints is We recommend that all infants and while vehicle is in motion, since the required by law in all 50 states and all children be properly restrained at all special seat belt retractor will be Canadian provinces.
  • Page 61 Since 1986 all U.S. child restraints must never ride in the front seat, could be crushed between the comply with U.S. regulations without except in a Mercedes-Benz occupant and seat belt. the use of a tether strap. authorized BabySmart™ compatible...
  • Page 62 Steering Lock Steering is unlocked. (If necessary, move steering wheel The electronic key can be slightly to allow the electronic key to withdrawn in this position only. be turned clockwise to position 1.) The steering is locked with the Most electrical consumers can be electronic key removed from the operated.
  • Page 63 Warning! Notes: Unnecessary strain on the battery and charging system may be minimized by When leaving the vehicle always A warning sounds when the driver's turning off the following power remove the electronic key from the door is opened with the electronic key consumers, for example: Heated seats, steering lock, and lock the vehicle.
  • Page 64 Control for windshield wiper/washer system: Push briefly for single wipe without adding washer fluid (use only when windshield is wet) Push past detent and hold to activate wiper and washer Windshield wiper 0 Wiper off I Intermittent wiping (optional rain sensor: One initial wipe, pauses between wipes are automatically controlled by a rain sensor...
  • Page 65 Windshield and Headlamp Washer Windshield Wiper Smears Fluid Mixing Ratio If the windshield wiper smears the For temperatures above freezing: windshield, even during rain, activate the washer system as often as MB Windshield Washer Concentrate necessary. The fluid in the washer "S"...
  • Page 66 Standing lamps, right the vehicle's exterior lamps (except (turn left one stop) standing lamps) are not switched off. Standing lamps, left (turn left two stops) Fog lamps will operate with the Front fog lamps parking lamps and/or the low beam (pull out one stop) with headlamps on.
  • Page 67 The lamp-on passenger side convex mirror. time period can be changed at your With gear selector lever in position Mercedes-Benz dealer. "R", or with the interior lamp switched on, the mirror brightness does not respond to changes in light sensitivity.
  • Page 68 With the electronic key in steering lock Note: position 2, the driver's side mirror reflection brightness responds to The exterior mirrors have electrically changes in light sensitivity. heated glass. The heater switches on automatically, depending on outside With gear selector lever in position temperature.
  • Page 69 Parking position At speeds above approx.6 mph (10 One passenger side mirror position km/h), or gear selector lever moved can be stored in memory. To do so: The passenger side exterior mirror can from "R" Reverse, or driver's side be adjusted and programmed to assist mirror selected, the passenger side 1.
  • Page 70 Prior to removing the ashtray insert, move the gear selector lever to position "N". Warning! Remove front ashtray only with vehicle standing still. With the gear selector lever in position “N", turn off the engine and set the parking brake. Otherwise the vehicle might move as a result of unintended contact with the gear selector lever.
  • Page 71 Lighter Sun Visors Illuminated Vanity Mirrors Turn electronic key in steering lock to Swing sun visors down to protect With the visor engaged in its inner position 1 or 2. against sun glare. mounting, the lamp is switched on by Push in lighter (1);...
  • Page 72 Interior Lighting Entrance Lamps, Exit Lamps in Doors Door contact switch: Press once and interior lamps are The lamps are switched on and off by switched on when opening a door. the door contact switches. Interior lamps are switched on, and off (soft fade) delayed, when Note: unlocking or locking the vehicle,...
  • Page 73 Storage Compartments and Storage Compartments in Center To store cup holder: Cup Holder Console Push button (7) down until cup Glove Box holder engages. Close cover (6). To open compartment in armrest: Unlocking: Turn mechanical key Lift lid with handle (4). Caution! to vertical position and remove.
  • Page 74 Warning! When closing the sliding/ pop-up roof, be sure that there is no danger of anyone being harmed by the closing procedure. The closing procedure can be immediately reversed by either moving the switch in direction (1) or (3), turning the mechanical key to the unlocking position, or pressing button on the...
  • Page 75 Express Opening and Closing Press switch past re- sistance point and release - window opens or closes completely. To interrupt procedure, briefly press If the upward movement of the window is blocked during the closing procedure, the window will stop during the last few inches before closure and open slightly.
  • Page 76 Warning! Warning! Parcel Net in Front Passenger Footwell When closing the windows, be sure When leaving the vehicle, always that there is no danger of anyone remove the electronic key from the A small convenience parcel net is being harmed by the closing steering lock, and lock your vehicle.
  • Page 77 With vehicle centrally locked, the trunk can also be opened by using the infrared remote control. Aim transmitter eye at a receiver and press transmit button twice. Note: The trunk lid cannot be released by the switch when previously locked with the key.
  • Page 78 Display Illumination The display for temperature, odometer, multifunction indicator, FSS indicator and clock is illuminated briefly when opening the driver door. The display illumination brightness responds automatically according to changes in the surrounding light sensitivity. To briefly illuminate the display (with electronic key removed or in steering lock position 0 or 1), press button O, +, -, h, m or R.
  • Page 79 If you should experience difficulties with the inside rear view mirror until programming the transmitter, contact its control light begins to flash at your authorized Mercedes-Benz dealer a rate of about once a second. or call Mercedes-Benz Customer Continue holding down the Assistance Center (in the U.S.A.
  • Page 80 control, until the inside rear view programmed button on the or until the control light blinks mirror remote control light starts to integrated remote control trans- rapidly, will erase the codes of flash rapidly. This means that the mitter once again to turn off the all three channels.
  • Page 81 Driving...

  • Page 82: Parking Brake

    Drinking and Driving Driving Off Warning! Apply the service brakes to test them briefly after driving off. Perform this Drinking and driving can be a very procedure only when the road is clear dangerous combination. Even a small of other traffic. amount of alcohol or drugs can affect your reflexes, perceptions and Warm up the engine smoothly.

  • Page 83: Automatic Transmission

    Automatic Transmission Driving Important! The automatic transmission selects The selector lever is automatically After selecting any driving position individual gears automatically, locked while in position "P". To move from "N" or "P", wait a moment to dependent upon the selector lever out of position "P", allow the gear to fully engage before the service brake pedal must be firmly accelerating, especially when the...
  • Page 84 Selector Lever Positions selector lever in position "P". With damage that is not covered by the the electronic key removed, the Mercedes-Benz Limited Warranty. The automatic gear shifting process can selector lever is locked in position be adapted to specific operating "P".
  • Page 85 D The transmission automatically Important! usual manner. The transmission will upshifts through 5th gear. Position then shift down automatically. "D" provides optimum driving With selector lever in position "D", "4" characteristics under all normal or "3", upshifting from 1st to 2nd to 3rd To prevent the engine from laboring at operating conditions.
  • Page 86 Maneuvering Warning! To maneuver in tight areas, e.g. when Getting out of your vehicle with the pulling into a parking space, control the selector lever not fully engaged in vehicle speed by gradually releasing position "P" is dangerous. Also, the brakes. Accelerate gently and never when parked on an incline, position abruptly step on the accelerator.
  • Page 87 4. Wait 10 seconds. 5. Restart the engine. 6. Move selector lever to position "D" (for 2nd gear), or move selector lever to position "R" (for reverse gear). Have the transmission checked at your authorized Mercedes-Benz dealer as soon as possible.

  • Page 88: Cruise Control

    1 or 2 Mercedes-Benz dealer as soon as Cruise Control until the desired speed is reached, or possible.
  • Page 89 Notes: Important! Warning! If the engine does not brake the vehicle Moving gear selector lever to position Only use the cruise control if the sufficiently while driving on a "N" switches the cruise control off. traffic and weather conditions make downgrade, the speed you set on the it advisable to travel at a steady cruise control may be exceeded and...

  • Page 90: Multifunction Indicator Language Selection

    Multifunction Indicator Multiple Malfunctions Defective Language Selection When the multiple malfunction symbol When the message "Display Defective" appears, this indicates that several appears, this indicates that the system Warning message selection is available malfunction messages are stored in is not operational, and possibly other in the English, French, German, Italian, memory.

  • Page 91: Engine Oil Consumption

    Note: authorized Mercedes-Benz dealer as soon as possible. When the symbol and message appear E 300 Turbodiesel - Oil level check via while the engine is running and at multifunction indicator not possible. Leaving the engine running and the fuel operating temperature, the engine oil cap open can cause the "Check Engine"...

  • Page 92: Tachometer

    This means that the accuracy of 266°F (130°C). covered by the Mercedes-Benz Limited the displayed temperature can only be Warranty. verified by comparison to a During severe operating conditions and...
  • Page 93 Antifreeze contains ethylene which may have leaked into the covered by the Mercedes-Benz Limited glycol which may burn if it comes engine compartment to catch fire. Warranty. into contact with hot engine parts.

  • Page 94: Brake Warning

    Have the brake system checked at your warning lamp stays on. Don't add authorized Mercedes-Benz dealer as brake fluid before checking the If an exterior lamp fails, the indicator soon as possible.

  • Page 95: Flexible Service System (Fss)

    Following a completed service the Mercedes-Benz dealer sets the counter to 10 000 miles (Canada: 15 000 km) and 365 days. The counter can also be set by any individual. To do so: Turn electronic key in steering lock to position 2.
  • Page 96 FSS can be added by from 365 to 730 days between services. your Mercedes-Benz dealer. The interval between services is determined Model E 300 TURBODIESEL: by the kind of vehicle operation. Driving at extreme speeds, and cold The FSS allows for distances between...

  • Page 97: Antilock Brake System (Abs)

    ABS should be pulsating brake pedal can be an operational. indication of hazardous road conditions Have the system checked at your and functions as a reminder to take authorized Mercedes-Benz dealer as extra care while driving. soon as possible.

  • Page 98: Brake Assist System (Bas)

    The BAS/ASR or BAS/ESP Have the BAS, ASR or ESP checked at malfunction indicator lamp in the your authorized Mercedes-Benz dealer instrument cluster comes on with the as soon as possible. electronic key in steering lock position 2 and should go out with the engine running.

  • Page 99: Electronic Traction System (Ets)

    The ETS warning lamp, located in the Have the BAS or ETS checked at your lock position 2. They should go out speedometer dial, starts to flash at authorized Mercedes-Benz dealer as with the engine running. any vehicle speed, as soon as the soon as possible.
  • Page 100 Index), the engine must be shut off Have the BAS or ASR checked at your and spin due to excessive acceleration. (electronic key in steering lock position authorized Mercedes-Benz dealer as While engaged, the yellow warning 0 or 1). Otherwise, the acceleration slip soon as possible.
  • Page 101 Avoid spinning of one drive wheel. the upper half of the ASR switch. The Doing so may cause serious damage to ASR warning lamp, located in the the drive train which is not covered by speedometer dial, is continuously the Mercedes-Benz Limited Warranty. illuminated.

  • Page 102: Electronic Stability Program (Esp)

    (standard on E 430 and E 55 AMG; combined with that of the BAS. electronic stability program may optional on E 300 TD and E 320) The yellow BAS/ESP malfunction activate (yellow ESP warning lamp in indicator lamp in the instrument cluster speedometer dial comes on).
  • Page 103 Avoid spinning of one drive wheel. the upper half of the ESP switch. The Doing so may cause serious damage to ESP warning lamp, located in the the drive train which is not covered by speedometer dial, is continuously the Mercedes-Benz Limited Warranty. illuminated.

  • Page 104: Emission Control

    Mercedes-Benz servicing Mercedes-Benz dealer as soon as requirements. For details refer to the On-Board Diagnostic System possible. Service Booklet.

  • Page 105: Winter Driving

    Have your vehicle winterized at your temperature. A well charged • For diesel fuels, refer to Index. authorized Mercedes-Benz dealer battery helps to ensure that the before the onset of winter. engine can be started, even at low •...

  • Page 106: Snow Chains

    For tips on driving on slippery winter Traveling Abroad roads, refer to Index. Use only snow chains that are tested Abroad, there is a widely-spread and recommended by Mercedes-Benz. Vehicles with Acceleration Slip Mercedes-Benz service network at Your authorized Mercedes-Benz dealer Regulation (ASR) or Electronic your disposal.

  • Page 107: Practical Hints

    Practical Hints...

  • Page 108: Hood

    Warning! To help prevent personal injury, stay clear of moving parts when the hood is open and the engine is running. Be sure the hood is properly closed before driving. When closing hood, use extreme caution not to catch hands or fingers. If you see flames or smoke coming from the engine compartment, or if the coolant temperature gauge...

  • Page 109: Checking Coolant Level

    Adding Coolant • Do not remove pressure cap on coolant reservoir if engine If coolant has to be added, a 50/50 temperature is above 194°F (90°C). mixture of water and MB Allow engine to cool down before anticorrosion/antifreeze should be removing cap.

  • Page 110: Checking Engine Oil Level

    ADD 1.0 Q OF OIL (Canada: 1.0 L) catalytic converter not covered by the vehicle on level ground, with engine at Mercedes-Benz Limited Warranty. normal operational temperature. ADD 1.5 Q OF OIL (Canada: 1.5 L) For Low engine oil level warning, see ADD 2.0 Q OF OIL (Canada: 2.0 L)

  • Page 111: Bleeding Of Diesel Fuel System

    Bleeding of Diesel Fuel System covered by the Mercedes-Benz Limited Warranty. If the engine ran out of fuel, the fuel system has to be purged of air after The symbol flashes in the refilling tank.

  • Page 112: Trunk Lamp

    To remove spare tire: Turn luggage bowl counterclockwise and remove. To store spare tire: Place spare tire in wheel well and secure it with luggage bowl. Turn luggage bowl clockwise to its stop. Note: Always lower trunk floor before closing trunk lid. Stowing Things in the Vehicle Warning! Trunk Lamp...

  • Page 113: Vehicle Jack

    See your vehicle. To help avoid personal authorized Mercedes-Benz dealer for injury, use the jack only to lift the further information. vehicle during a wheel change. Never...
  • Page 114 We recommend that you break in new When replacing rims, use only Notes: tires for approx. 60 miles (100 km) at genuine Mercedes-Benz wheel bolts moderate speed. specified for the particular rim Thoroughly clean the inner side of the type. Failure to do so can result in...
  • Page 115 Spare Wheel Warning! Warning! (except E 430 with Sport Package and The spare wheel rim is for temporary The spare wheel rim is for temporary E 55 AMG) use only. Use for over a total of 12 000 use only. Use for over a total of 12 miles (20 000 km) may cause wheel 000 miles (20 000 km) may cause Important!
  • Page 116 Spare Wheel (E 55 AMG) Warning! Warning! The spare wheel rim size is The dimensions of the spare wheel The jack is designed exclusively for 8 J x 18 H 2 (same as front wheel). are different from those of road jacking up the vehicle at the jack wheels on the rear axle.

  • Page 117: Changing Wheels

    Changing Wheels wheels of the other axle. On a level 6. Insert jack arm fully into the tube road, place one chock in front of hole up to the stop. Place jack Move vehicle to a level area which is a and one behind the wheel that is on firm ground.
  • Page 118 9. Remove wheel. Grip wheel from 11. Lower car. Remove jack and Warning! the sides. Keep hands from beneath insert jack tube cover. the wheels. Before storing the jack, the jack Always replace wheel bolts that are arm must be lowered almost to the damaged or rusted.
  • Page 119 Do not overinflate tires. inflation pressures specified for Tire temperature and pressure Overinflating tires can result in Mercedes-Benz recommended tires as increase with the vehicle speed. Tire sudden deflation (blowout) because well as for the varying operating pressure should therefore only be they are more likely to become conditions.

  • Page 120: Exterior Lamps

    Exterior Lamps Headlamp Adjustment Correct headlamp adjustment is extremely important. Check and readjust headlamps at regular intervals and when a bulb has been replaced. Headlamp Assembly Electrical connector for low beam headlamp bulb Headlamp horizontal adjustment Electrical connector for high screw beam headlamp bulb Headlamp vertical adjustment...
  • Page 121 Replacing Bulb: Bulbs for Low or High Beam Turn Signal Lamp H7 (55 W) 1156 NA (26.9/5 W/32/4 cp bulb) When replacing bulbs, install only 12 volt bulbs with the specified watt Open hood. Open hood. rating. Move retaining clamps (3) aside and Twist bulb socket (4) counterclockwise When replacing halogen bulbs do not remove cover.
  • Page 122 Adjusting Headlamp Correct headlamp adjustment is extremely important. To check and readjust a headlamp, follow steps 1 through 7. Please note: • Low beam adjustments simultaneously aim the high beam. • Vehicle should have a normal trunk load. • Vertical aim adjustments change horizontal aim.
  • Page 123 Graduations: 0.38° pitch. centerline (11) of each lamp. Note: The left and right headlamps must be adjusted individually If it is not possible to obtain a proper headlamp adjustment, have the system checked at your authorized Mercedes-Benz dealer.
  • Page 124 Adjusting Headlamp Aim 1. Park vehicle on level surface not check, have the system verified (Xenon) approximately 25 ft. (7.6 m) at an authorized Mercedes-Benz from a vertical test screen or dealer. Correct headlamp adjustment is wall. The centerline of the (Low beams off): extremely important.
  • Page 125 6. Horizontal headlamp aim Note: (Low beams on): Turn adjusting screw (1) If it is not possible to obtain a proper (counterclockwise to adjust to the headlamp adjustment, have the system left, clockwise to the right) until the checked at your authorized Mercedes- headlamps (low beam) illuminate Benz dealer.
  • Page 126 Taillamp Assemblies Driver's side: Side Marker Lamp, Front Rear fog lamp (5 W/4 cp bulb) Open trunk lid. (21 W/32 cp bulb) Backup lamp From inside wheel house (arrow) Turn signal lamp (21 W/32 cp bulb) reach behind side marker lamp and (21 W/32 cp bulb) press tab.

  • Page 127: Battery

    Battery Important! Therefore, we strongly recommend that you have the battery charge Warning! Battery replacement information: checked frequently, and corrected if necessary, especially if you use the Failure to follow these instructions The maintenance-free battery is located vehicle less than approximately 200 can result in severe injury or death.
  • Page 128 While the engine is running the battery Battery Recycling terminal clamps must not be loosened or detached, otherwise the generator Batteries contain materials that can and other electronic components would harm the environment with improper be damaged. disposal. Notes: Large 12 Volt storage batteries contain lead.

  • Page 129: Fuses

    Fuses Main fuse box in engine Auxiliary fuse box below rear compartment seat bench Before replacing a blown fuse, determine the cause of the short circuit. To gain access to the main fuse To gain access, remove rear seat box (1), release clamp (arrow), bench.

  • Page 130: Jump Starting

    Jump Starting If the battery is discharged, the engine should be started with jumper cables Warning! and the (12 V) battery of another vehicle. Jump start the car by using the Failure to follow these directions will battery terminals located under hood. cause damage to the electronic Proceed as follows: components, and can lead to a battery...

  • Page 131: Towing The Vehicle

    9 mph (15 top securely. unsuccessful starting attempts, have it km/h) or more. checked at the nearest authorized Mercedes-Benz dealer. To prevent the vehicle door locks from locking, deactivate the automatic Excessive unburned fuel may damage central locking...
  • Page 132 We recommend that the vehicle be Warning! transported using flat bed equipment. This method is preferable to other types With the engine not running, there is of towing. no power assistance for the braking and steering systems. In this case, it The vehicle may be towed with all is important to keep in mind that a wheels on the ground and the selector...
  • Page 133 Caution! Caution! Caution! Vehicles with Acceleration Slip Vehicles with Electronic Traction Vehicles with Electronic Traction Regulation (ASR) System (ESP) System (ETS) If the vehicle is towed with the front axle If the vehicle is towed with the front axle If the vehicle is towed with one axle raised, the engine must be shut off raised, the engine must be shut off raised, the engine must be shut off...

  • Page 134: Cleaning And Care Of The Vehicle

    Cleaning and Care of the Vehicle Frequent washing reduces and/or Mercedes-Benz because of the eliminates the aggressiveness and possibility of incompatibility between Warning! potency of the above adverse influences. materials used in the production process and others applied later. Many cleaning products can be More frequent washings are necessary hazardous.
  • Page 135 - in particular one Use a mild car wash detergent, such as the engine compartment after every of the older installations -rewipe the Mercedes-Benz approved Car engine cleaning. Before applying, all recessed sections in the taillamps Shampoo, with plenty of water.
  • Page 136 Steering Wheel and Gear particular care when cleaning Selector Lever perforated leather as its underside Pour Mercedes-Benz approved Interior should not become wet. Care onto soft lint-free cloth and apply Wipe with a damp cloth and dry with light pressure.
  • Page 137 Paintwork, Painted Body Light Alloy Wheels Ornamental Moldings Components Mercedes-Benz approved Wheel Care For regular cleaning and care of very Mercedes-Benz approved Paint Care should be used for regular cleaning of dirty chrome-plated parts, use a chrome should be applied when water drops on the light alloy wheels.

  • Page 138: Electronic Main Key, Remote Control

    Electronic Main Key Changing Batteries Insert mechanical key (2) in side Remote Control opening (3) to open latch. Press briefly Move lock (1) in direction of right (do not use mechanical key as lever) to Transmit buttons arrow and slide out mechanical key (2, release battery compartment.
  • Page 139 Important! Synchronizing Remote Control Batteries contain materials that can The remote control may have to be harm the environment if disposed of resynchronized, if the vehicle cannot improperly. Recycling of batteries is be locked or unlocked. the preferred method of disposal. For disposal, please follow manufacturer's To synchronize insert electronic key in recommendation on battery package.

  • Page 140: Front Head Restraint

    Front Head Restraints Installation: Warning! Push button (1) of the power adjustable head restraint up for approximately 5 For your protection, drive only with seconds. properly positioned head restraints. Insert the head restraint and push it Adjust head restraint to support the down to the stop.

  • Page 141: Rear Seat Cushion

    Rear Seat Cushion Emergency Operation of To slide the roof closed or to raise the Sliding/Pop-Up Roof roof at the rear: turn crank clockwise. Removal: Pull locking tabs up (on left and right side of seat) and lift seat at the The sliding/pop-up roof can be opened To slide the roof open or to lower the front.
  • Page 142 Replacing Wiper Blade Insert For safety reasons, remove electronic key from steering lock before replacing the wiper blade, otherwise the motor can suddenly turn on and cause injury. Notes: Do not open engine hood with wiper arm folded forward. Do not allow the wiper arm to contact the windshield glass without a wiper blade inserted.

  • Page 143: Manual Release Of Fuel Filler Flap

    The manual release knob is located Use only those roof racks approved by Mercedes-Benz vehicles. behind the right side trunk panel. Mercedes-Benz to avoid damage to the vehicle. Follow manufacturer's Therefore, Mercedes-Benz original In case the central locking system does installation instructions.

  • Page 144: Layout Of Poly-V-Belt Drive

    E 300 TURBODIESEL E 320, E 430, E 55 AMG Layout of Poly-V-belt Drive Coolant pump, fan Generator (alternator) Automatic belt tensioner Idler pulley Crankshaft Power steering pump Air conditioning compressor...

  • Page 145: Technical Data

    Technical Data...

  • Page 146: Identification Labels

    Certification Label Vehicle Identification No. (VIN) VIN, visible (lower edge of windshield) Engine No. E 320, E 430: rear right, E 300 TURBODIESEL: front left Body No. and Paintwork No. Emission Control Label Information Label California version Vacuum line routing for...

  • Page 147: Warranty Coverage

    Should you lose your Owner's Service Owner's Service and Warranty and Warranty Information Booklet, Information Booklet and your have your authorized Mercedes-Benz authorized Mercedes-Benz dealer will dealer arrange for a replacement. It exchange or repair any defective parts will be mailed to you.
  • Page 148 2140 mm Generator (alternator) 14 V/120 A Starter motor 12 V/2.2 kW The quoted data apply only to the standard vehicle. See Battery 12 V/100 Ah an authorized Mercedes-Benz dealer for the corresponding data of all special bodies and special equipment.
  • Page 149 Technical Data E 300 TURBODIESEL Main Dimensions See certification tag Weights Roof load max. 100 kg (220 lb) Overall vehicle length 4810 mm (189.4 in) Trunk load max. 100 kg ( 220 lb) Overall vehicle width 1799 mm ( 70.8 in) Overall height: 1439 mm ( 56.7 in)
  • Page 150 12 V/1.7 kW The quoted data apply only to the standard vehicle. See Battery 12 V/100 Ah an authorized Mercedes-Benz dealer for the corresponding Spark plugs Bosch F 8 DPER data of all special bodies and special equipment. Electrode gap 0.8 mm (0.032 in)
  • Page 151 Technical Data E 320 Main Dimensions See certification tag Weights Roof load max. 100 kg (220 lb) Overall vehicle length 4810 mm (189.4 in) Trunk load max. 100 kg ( 220 lb) Overall vehicle width 1799 mm ( 70.8 in) Overall height: 1439 mm ( 56.7 in) Wheel base...
  • Page 152 Wheel offset 41 mm (1.6 in) The quoted data apply only to the standard vehicle. See Summer tires: an authorized Mercedes-Benz dealer for the corresponding Radial-ply tires 215/55 R 16 93 H data of all special bodies and special equipment.
  • Page 153 Technical Data E 430 See certification tag Electrical System Weights Roof load max. 100 kg (220 lb) Generator (alternator) 14 V/150A Trunk load max. 100 kg ( 220 lb) Starter motor 12 V/1.7 kW Battery 12 V/100 Ah Main Dimensions Spark plugs Bosch F 8 DPER Beru 14 FGH 8 DPUR X 2...
  • Page 154 Rims The quoted data apply only to the standard vehicle. See (light alloy rims) 8 J x 18H 2 an authorized Mercedes-Benz dealer for the corresponding Wheel offset 31 mm (1.2 in) data of all special bodies and special equipment.
  • Page 155 Technical Data E 55 AMG See certification tag Electrical System Weights Roof load max. 100 kg (220 lb) Generator (alternator) 14 V/150A Trunk load max. 100 kg ( 220 lb) Starter motor 12 V/1.7 kW Battery 12 V/100 Ah Main Dimensions Spark plugs Bosch F 8 DPER Overall vehicle length...

  • Page 156: Fuels, Coolants, Lubricants Etc

    Fuels, Coolants, Lubricants etc. – Capacities Vehicle components and their respective lubricants must match. Therefore use only brands tested and recommended by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your authorized Mercedes-Benz dealer. Model Capacity Fuels, coolants, lubricants etc.
  • Page 157 MB Windshield washer concentrate "S" system Headlamp washer system approx. 1 .9 US qt (1 .8 I) MB Windshield washer concentrate "S" E 300 Turbo Diesel approx. 1 0.6 US qt (10 I) MB Anticorrosion/antifreeze Cooling system E 320 E 430 approx.

  • Page 158: Engine Oils

    Mercedes-Benz Limited Warranty. It is recommended to use only brake Engine Oil Additives fluid approved by Mercedes-Benz. Your authorized Mercedes-Benz dealer Do not blend oil additives with engine will provide you with additional oil. They may be harmful to the engine information.

  • Page 159: Premium Unleaded Gasoline

    A major concern among engine ASTM standard D 439: manufacturers is carbon build up Caution! caused by gasoline. Mercedes-Benz The octane number (posted at the recommends the use of only quality To maintain the engine's durability and pump) must be 91 min. It is an average...
  • Page 160 At very low temperatures the fluidity of Mercedes-Benz Limited Warranty. No. 2 diesel fuel may become The following table can be used as a insufficient due to paraffin separation.

  • Page 161: Coolants

    The engine coolant is a mixture of anticorrosion/ antifreeze. car: Mercedes-Benz Anti corrosion/ water and anticorrosion/antifreeze, Antifreeze Agent. which provides: If the coolant level is low, water and...
  • Page 162 Consumer Information from the norm due to variations in controlled conditions on a specified driving habits, service practices and indoor laboratory test wheel. Sustained This has been prepared as required of differences in road characteristics and high temperature can cause the material all manufacturers of passenger cars climate.
  • Page 163 If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact your authorized Mercedes-Benz dealer to have the problem diagnosed and corrected if required. If the matter is not handled to your satisfaction, please discuss the problem with the dealership management, or if necessary contact us at the following addresses: In the U.S.A.: Customer Assistance Center...
  • Page 164 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz of North America Inc..
  • Page 165 Index...
  • Page 166 ABS 85-86, 97-100, 102, BabySmart™ Cruise control Acceleration slip regulation (ASR) BAS 97-100, Cup holder 47, Air conditioner refrigerant Battery Air distribution Battery charge indicator Daytime running lamps Air volume Airbag Brake assist system Diesel fuel system, bleeding Airbag deactivation system Brake fluid 18, 94, 134, 157-158 Display illumination...
  • Page 167 First aid kit Jump starting Night security illumination Flexible service system Front center console compartment Keys, vehicle Outside temperature indicator ventilation FSS 78, 95-96 Lamps, exterior Fog lamps Parcel net Fuel Headlamp, adjusting Parking brake 16-18,21,70, 82-84, Diesel fuel additives Headlamps 66, 94, 120, 123, 125, 86, 94, 100, 102, 104, 113, 116- Diesel fuels 105, 157,...
  • Page 168 Safety guidelines for the seat belt, Tachometer Vanity mirrors emergency tensioning retractor Technical data Vehicle jack and airbag Temporarily switching off Vehicle tools Seat belt warning lamp Tie down rings Seat belts and warning system Tire inflation pressure Warranty coverage Shelf below rear window Tires 18-20,98-103, 105, Washing the car...

  • Page 171: Service And Literature

    Mercedes-Benz dealer. If you have any question about carrying out some service, turn to the advice of an authorized Mercedes-Benz dealer. We consider this to be the best way for you to obtain accurate information for your vehicle.
  • Page 172 Check Regularly and Before a Long Trip E 320 shown • Fuel Supply Windshield Washer System Open flap by pushing near front (arrow). Turn fuel cap to the For refilling reservoir see Index left and hold on to it until possible pressure in tank has been Headlamp Cleaning System released, then remove cap.
  • Page 173 What You Should Know at the Gas Station • Spark Plugs: • Fuel: Approved spark plugs, refer to "Technical Data". To prevent fuel vapors from escaping into open air, • Bulbs: fully insert filler nozzle unit. Only fill fuel tank until the filler nozzle unit cuts out - High and low beams: H7 (55 W), low beam: do not top up or overfill.

This manual is also suitable for:

E 320E 430E 300td

Table of Contents

Save PDF
