1. What's in the box?
User manual
EN
Instrukcja obsługi
PL
User manual
Remote Control
2. Connect - basic connection
Connect at least speakers and FM antenna
FM antenna
AV290DVD with speakers
2x AAA baterries
Unit
CAUTION!
DO NOT OPEN
RISK OF ELECTRIC SHOCK
ACHTUNG!
UWAGA!
NICHT ÖFFNEN
LEBENSGEFAHR
R
Qucik Start Guide
A/V cable
FM antenna wire
Left speaker
Right speaker
Advertisement
Table of Contents
Related Manuals for Ferguson AV290DVD
Summary of Contents for Ferguson AV290DVD
- Page 1 Qucik Start Guide 1. What’s in the box? AV290DVD with speakers User manual Instrukcja obsługi User manual Remote Control 2x AAA baterries A/V cable FM antenna wire Unit 2. Connect - basic connection CAUTION! Connect at least speakers and FM antenna...
- Page 2 Press SETUP to exit. 4. Use Copy multimedia files to USB memory. Connect USB memory to USB port in AV290DVD Use keys to navigate in the menu. Choose in “Files Manager” file that you want to play Press OK to start playback.
-
Page 3: Table Of Contents
Contents Introduction Major functions 1 Product Overview 13 Playable Discs 1 Safety Information 13 Playable Content 2 User manual 15 Basic radio playback controls 3 Software upgrade 16 Playing discs 3 Symbols used on the device 16 Basic playback controls 4 Setup 17 Operations for video playback (DVD/ VCD/SVCD) -
Page 5: Introduction
Introduction Product Overview Safety Information Thank you for purchasing the AV290DVD. Please observe all warnings and This user manual provides step-by-step instructions on the equipment and instructions for installing and using your contained in these operating instructions. new system. -
Page 6: User Manual
Introduction User manual Ferguson has used all the available Do not use damaged cables for means to ensure the latest information connections: you could cause fires. regarding its products. Ferguson does not Please switch off completely the device give a warranty regarding the contents while making all connections. -
Page 7: Software Upgrade
Introduction Software upgrade Symbols used on the device Periodically Ferguson may issue software CAUTION! DO NOT OPEN upgrade to enhance your user experience. RISK OF ELECTRIC SHOCK ACHTUNG! UWAGA! NICHT ÖFFNEN NIE OTWIERAĆ LEBENSGEFAHR RYZYKO PORAŻENIA To download and install the latest... -
Page 8: Setup
Introduction Setup Avoid high temperatures, moisture, Finding a suitable location water and dust – Place the set on a flat, hard and stable – Apparatus shall not be exposed to surface.Do not place the set on a carpet. dripping or splashing. –... -
Page 9: Connections
Connections Connecting speakers and antenna CAUTION! DO NOT OPEN RISK OF ELECTRIC SHOCK ACHTUNG! UWAGA! NICHT ÖFFNEN LEBENSGEFAHR FM antenna Left speaker Right speaker IMPORTANT! Connect FM antenna For optimal sound, use the supplied speakers only. Connect only speakers with imped- ... -
Page 10: Connecting The Power Cord
Connections Connecting the power cord CAUTION! DO NOT OPEN RISK OF ELECTRIC SHOCK ACHTUNG! UWAGA! NICHT ÖFFNEN NIE OTWIERAĆ LEBENSGEFAHR RYZYKO PORAŻENIA After everything is connected properly, connect the power cable into an AC power outlet. Never make or change any connections with the power switched on. -
Page 11: Optional: Connecting Tv
AUDIO IN jacks on the TV. Using Component Video Jacks (Y Pb Pr) Use the component video cables (red/blue/green) to connect the AV290DVD system’s Y Pb Pr jacks to the Corresponding Component video input jacks (or labeled as Y Pb Pr) on the TV. -
Page 12: Optional: Connecting A Supported Usb Devices And Memory Cards
You can only view the content of Not all portable audio/video players and supported USB devices through digital cameras are supported. AV290DVD system. While connected to a card reader, only Connect the supported USB device one card can be read at the same time. -
Page 13: Functional Overview
Functional Overview Front and Rear panel A VFD display - Shows information E Disc tray F Card reader - Input the supported about the current status B IR Sensor - Point the remote control flash card. SD, MMC G USB 2.0 port - Input the supported towards this sensor C Function buttons - various functions USB device... -
Page 14: Remote Control Unit Rcu290
Functional Overview Remote Control Unit RCU290 POWER - Turns the system on or switches it to standby mode SETUP - Enters or exits system setup menu (TV connection required) EJECT - Open / close the disc tray Numeric keypad 0-9, 10+ - Selects numbered items in a menu - Enter radio station frequency - Radio mode MEDIA... -
Page 15: Getting Started
Aim the Remote Control directly at the video modes. remote sensor (IR) on the front panel. Do not put any objects between the Remote Control and AV290DVD while If you are using external equipment, (eg. operating the Player. audio system or receiver), turn it on and select the appropriate input source for the Fergusona player output. -
Page 16: Step 3: Setting Language Preference
Getting Started Step 3: Setting language preference The language options are different depending on your country or region. It may not correspond to the illustrations shown on the user manual. Setting the OSD language Press SETUP. Press to select Language Setup tab. Press to highlight Menu Language, ... -
Page 17: Major Functions
ISO-9660 and partly UDF on CD/DVD discs Playable Discs Video containers MPEG-1/2 Program Stream (MPG, MPEG) Your AV290DVD will play: MPEG-4 Part 14 (MP4) Digital Video Discs (DVDs) VOB Video CDs (VCDs) AVI ... - Page 18 Videos with resolution higher than 720x576@25/30P may not work properly Movies larger than 2 GiB may not be Extensions recognized in Ferguson file played correctly browser. Playing a movie via a USB/memory card List of recognized multimedia file that doesn’t support high speed may not...
-
Page 19: Basic Radio Playback Controls
Major functions RDS Radio Function Basic radio playback controls Press the TITLE/RDS button on the Press the FM button on the remote remote control to switch to RDS radio control to enter radio mode. mode. If there RDS signal is broadcasted, you may get following information: Select radio station PS: Program service name. -
Page 20: Playing Discs
Remote Control use. Connect the power cords of the Use and OK button to navigate AV290DVD and TV to a power outlet. in the menu. Turn on the TV power and set to the correct Video in channel. -
Page 21: Operations For Video Playback (Dvd/ Vcd/Svcd)
Major functions Operations for video playback Playback info (DVD/ VCD/SVCD) OSD menu shows playback information Using the Disc Menu (for example, file name, current playback progress, audio and video codecs). Depending on the disc, a menu may During playback, press OSD appear on the TV screen once you load in A list of available information the disc. -
Page 22: Playing Multimedia Files From The Usb Device Or Memory Card
Major functions General Operation Playing multimedia files from the USB device or memory card Load a disc or USB device. The disc reading time may exceed 30 This AV290VD system able to access seconds due to the complexity of the and view the data in the supported USB directory/file configuration. -
Page 23: Setup Menu Options
DVD. Use keys to press OK to confirm your selection. Warning: When the AV290DVD is set to Y Pb Pr (YUV), some TV may not properly synchronise with player on the SCART... -
Page 24: Audio Setup Menu
{LT/RT} - Select this option if your AV290DVD is connected to a Dolby Pro Logic decoder. Surround sound will be like in a movie theatre only if movie disc was recorded in the Dolby Pro Logic format. -
Page 25: General Setup Menu
{ SPDIF/PCM } - Select this if the connect- password for Parental and Disc Lock. ed device is not capable of decoding mul- tichannel audio. Ferguson will convert the In ‘Preference Page’ , use keys to Dolby Digital and MPEG-2 multichannel highlight { Default }, then press ... -
Page 26: Troubleshooting
– Operations may not be permitted. Refer to the user manual operating commands during playback. No sound during movies playback – The audio codec may not be supported by the Ferguson The contents of the USB flash drive – The USB flash drive format is not compatible with the player. -
Page 27: Specification
Specifications Processor FM radio Mediatek MT1389J 87.50 MHz to 108.00 MHz Cabinet Loader Dimensions (w x h x d) 511 x 258 x 250 mm (main unit Sanyo HD850 with speakers) Set Weight Approximately 7,5 kg Connections Scart Output Euroconnector Power consumption YPbPr Output 3x Cinch... -
Page 28: Glossary
Glossary Composite (CVBS) - Low quality analogue Digital: Sound that has been converted into video signal format. Can carry PAL signal.. numerical values. Digital sound is available when you use the DIGITAL AUDIO OUT Component (YPbPr) - Higher quality analogue COAXIAL or OPTICAL jacks.
