O W N E R ' S G U I D E
INSTALLATION GUIDE
Slot-Type DVD Player
MODEL DV2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV2005 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed Video DV2005

Summary of Contents for Directed Video DV2005

  • Page 1 O W N E R ’ S G U I D E INSTALLATION GUIDE Slot-Type DVD Player MODEL DV2005...
  • Page 2 © 2002 Directed Electronics, Inc.

  • Page 3: Table Of Contents

    Table of Contents Limited One-Year Warranty..4 Play Disc..........12 Stop Disc ..........12 Safety Instructions ... . 5 Remove Disc ..........12 Region Management Information ....5 Pause/Resume Play ........12 Important Safeguards .

  • Page 4: Limited One-Year Warranty

    Limited One-Year Warranty For a period of ONE YEAR from the date of purchase, your authorized dealer to obtain the service charge for Directed Electronics, Inc. ("DIRECTED") promises to the your unit. original purchaser to repair or replace, free of cost, TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL with a comparable reconditioned model any DVD PLAY- ER (hereafter the "UNIT”), which proves to be defective...

  • Page 5: Safety Instructions

    Safety Instructions CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VIS- IBLE/INVISIBLE LASER BEAM THAT COULD CAUSE HAZARDOUS RADIATION IF EXPOSED DIRECTLY. BE SURE TO OPERATE THE MOBILE DVD PLAYER AS INSTRUCTED. USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

  • Page 6: Important Safeguards

    Important Safeguards WHEN DRIVING Excessive dust. Vibration, impact, or high foot traffic. Keep the volume level low enough to be aware Surface tilt - the internal parts may be of road and traffic conditions. seriously damaged. WHEN CAR WASHING WHEN NOT IN USE Do not expose the product to water or excessive When not in use, set the player to standby mode.

  • Page 7: Important Information

    Important Information FCC NOTICE YOUR WARRANTY This device complies with Part 15 of FCC rules. Your warranty registration must be completely Operation is subject to the following two condi- filled out and returned within 10 days of pur- tions: (1) This device may not cause harmful chase.

  • Page 8: Disc Notes

    Disc Notes DISC FORMATS SUPPORTED BY DISC CLEANING THIS PLAYER Use a dry soft cloth to wipe the surface. If the disc is quite dirty, use a soft cloth slightly mois- VI D EO tened with isopropyl (rubbing) alcohol. Never 12 cm disc/8 cm disc use solvents such as benzine, thinner, or con- (Single-sided disc only)

  • Page 9: Front Panel Operation

    Front Panel Operation FRONT PANEL FEATURES Power Button Turns the unit on and off. Play/Pause Button Begins or pauses playback. Disc Slot Insert disc into the slot. Stop Button Stops playback. Reverse Skip Button Skips to the previous chapter/track. Remote LED Receiver Receives remote control command.

  • Page 10: Remote Operation

    Remote Operation REMOTE CONTROL BATTERY PRIOR TO USE Battery Installation During playback, the TV volume may be at Pull down on the tab located on the a lower level then other source units. If back of the remote control and pull this is the case, adjust the volume to the the battery cover off.

  • Page 11: Remote Control Functions

    Remote Control Functions BUTTON FUNCTION Open/Close Numerals Return Setup Directional Title Menu Play/Pause Reverse Skip Rewind Slow Fast Rewind Audio Subtitle Repeat Volume Channel Channel Search A/V Select Mute Program Zoom Go To Step Angle Fast Forward Forward Slow Forward Skip Stop Menu Enter...

  • Page 12: Basic Operation

    Basic Operation Operations in this section are common for all Press repeatedly or hold the volume button to discs types (DVD, CD, Video CD, and Super-VCD). raise or lower the volume. TURNING THE PLAYER ON/OFF SLOW REWIND/SLOW FORWARD Press POWER on the remote control to turn (23) Slow motion playback can be done by pressing...

  • Page 13: Repeat Play

    REPEAT PLAY ZOOM PLAY Chapters and tracks can be repeated during Press ZOOM (21) during playback to enlarge the playback. Press REPEAT (14) during playback to picture to twice its size. Press ZOOM (21) again toggle through the following repeat functions. to enlarge the picture to three times its size.

  • Page 14: Advanced Operation

    Advanced Operation DVD OPERATION Press PLAY/PAUSE (7) to return to normal playback speed. SETUP MENU NOTE: The rate of slow motion playback will be dis- The setup menu has selections for disc playback played in the On-Screen Display (OSD). setup that usually include audio, language, sub- titles, playback, and special features.

  • Page 15: Cd/Vcd Operation

    VIEWING ANGLE MP3 OPERATION Many DVDs have scenes that are recorded from BASIC MP3 OPERATION multiple angles. These scenes can be viewed from Stop Disc, OSD, Mute, Play/Pause, Volume, Skip other angles by using the ANGLE (24) button. Tracks, Audio Mode, and Repeat Play operate as Press ANGLE (24);...

  • Page 16: Setup Menu

    Setup Menu The setup menu contains settings for disc play- Use the left DIRECTION BUTTON (5) to exit the submenu. back and should be used to adjust the DVD play- To exit the Setup Menu at any time press er according to the disc being played, personal the SETUP (4) button.

  • Page 17: Audio Menu

    AUDIO MENU DISPLAY OPTIONS MENU The Audio Menu allows the user to change audio The Display Options Menu allows the user to type or to turn the audio off. determine the size of the screen and what for- mat the DVD is to be played back in. Audio Options Menu Display Options Menu Bit Stream...

  • Page 18: Screen Format

    SCREEN FORMAT If the picture has no color, abnormal color or the video doesn't play properly, check the monitor and player settings to make sure they are the NOTE: This is controlled in the display options of the Setup Menu. same.

  • Page 19: Installation

    The use of unauthorized parts can cause malfunc- NOTE: The DV2005 can be mounted vertically or hori- tions. Consult with your nearest dealer if zontally for greater versatility. installation requires the drilling of holes or other modifications of the vehicle.

  • Page 20: Wiring Connections

    WIRING CONNECTIONS EXTERNAL REMOTE CONTROL CONNECTOR - Insert the 1/8" pin plug for the External POWER CONNECTOR - The RED fused power Remote Sensor eye into this socket. wire must be connected to a wire that has VIDEO SIGNAL - Connect the YELLOW (+) 12 volts when the key is in the acces- Composite Video RCA cable to this jack.

  • Page 21: Troubleshooting

    Troubleshooting PROBLEM SOLUTION NO SOUND 1. Using the remote control, make sure the volume is not lowered. 2. Check all audio cable connectors in the system for loose or improper connections. 3. Test system components for proper power and operation. 4.

  • Page 22: Specifications

    Specifications Power Requirements: DC + 12V ± 3V Power Consumption: 18 Watts DVD Reading Speed: 11.45 ft/sec. DVD Approx. Play Time: 135 min. (Single-sided, single-layer disc) CD Reading Speed: 3.9 to 4.6 ft/sec. CD Maximum Play Time (5”): 74 min. CD Maximum Play Time (3.5”): 20 min.
  • Page 23 © 2002 Directed Electronics, Inc.
  • Page 24 The company behind this system is Directed Electronics, Inc. Since its inception, Directed has had one purpose, to provide consumers with the finest vehicle security, car audio products, rear seat entertainment, and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, Directed is ISO 9001 registered.
