Directed Video DV2600 Owner's Installation Manual

1 din dvd player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
O W N E R ' S G U I D E
INSTALLATION GUIDE
1 DIN DVD Player
MODEL DV2600

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV2600 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed Video DV2600

Summary of Contents for Directed Video DV2600

  • Page 1 O W N E R ’ S G U I D E INSTALLATION GUIDE 1 DIN DVD Player MODEL DV2600...

  • Page 3: Table Of Contents

    Table of Contents Warranty ..........4 Safety Instructions .

  • Page 4: Warranty

    Limited One-Year Warranty For a period of ONE YEAR from the date of purchase, Directed Electronics, Inc. ("DIRECTED") promises to the original purchaser to repair or replace, free of cost, with a comparable reconditioned model any DVD PLAY- ER (hereafter the "UNITS), which prove to be defective in workmanship or material defect under normal use, provided the following conditions are met: the unit was purchased and installed by an authorized DIRECTED...

  • Page 5: Safety Instructions

    Safety Instructions MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD CAUTION: PLAYER USES A VISIBLE/INVISIBLE LASER BEAM THAT COULD CAUSE HAZ- ARDOUS RADIATION IF EXPOSED DIRECTLY. BE SURE TO OPERATE THE MOBILE DVD PLAYER AS INSTRUCTED. USE OF CONTROLS, ADJUSTMENTS OR PERFOR- MANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

  • Page 6: Protect The Disc Mechanism

    PROTECT THE DISC MECHANISM Avoid inserting any foreign objects into the slot of this player. Failure to observe this may cause malfunction due to the precise mechanism of this unit. USE AUTHORIZED SERVICE CENTERS Do not attempt to disassemble or adjust this precision product.

  • Page 7: Features

    Features FEATURES Compatible with PAL DVD (Video CD) and NTSC DVD (Video CD). A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoders. L/R stereo analog audio outputs (RCA) for connection to existing head unit aux inputs.

  • Page 8: Disc Notes

    Disc Notes DISC FORMATS SUPPORTED BY THIS PLAYER VI D EO 12 cm disc/8 cm disc (Single-sided disc only) Video CD 12 cm disc/8 cm disc 12 cm disc/8 cm disc DISC FORMATS NOT SUPPORT- ED BY THIS PLAYER DVD-ROM DVD-R/ DVD-RAM CD-RAM CD-G...

  • Page 9: Front Panel Operation

    Front Panel Operation FRONT PANEL FEATURES IR Receiver Open Button Power Button Display Disk Slot Security LED Reset Button Eject Release button Power ON/OFF - Press the POWER button (3) to turn the unit on/off. Opening the Front Panel - Press the OPEN button (2) and the front panel will fold down.

  • Page 10: To Detach The Front Panel

    TO DETACH THE FRONT PANEL Press OPEN; the front panel will fold down. Press the RELEASE button (9) on the back- side of the front panel and pull outward. For safekeeping, store the front panel in the supplied protective case immediately after removing.

  • Page 11: Remote Control

    Switch the Repeat mode, following by REPEAT, REPEAT 1, and REPEAT OFF. Press once to PAUSE a play, press again to resume continuous playback. Changing of the AV output signal form AV IN cable or DVD player. ENTER Confirm the Track/Chapter selected with the number key or selected with the cursor buttons on TV screen.

  • Page 12: Remote Operation

    Remote Operation TURNING THE PLAYER ON/OFF Press on the remote control to turn the play- er on or off. PLAY/PAUSE/STOP DVD DISC Press to play or pause the disc. Press once to stop playback; press twice to stop and return to the beginning of the disc.

  • Page 13: Multi-Audio Function

    PLAYBACK TIME This displays how much time has elapsed or how much time is remaining on the chapter or the disc (Title). NOTE: Some functions are not available on all discs. If the function requested is not available on the disc that is playing, a will appear in the upper left corner of the screen.

  • Page 14: Initial Setup

    Initial Setup SETUP --- MAIN PAGE Press SETUP in the stop mode. (Press STOP twice to ensure the player is in STOP mode.) The initial SETUP menu is displayed. General Setup SETUP --- GENERAL PAGE Select the preferred item by using the buttons.
  • Page 15 SETUP --- GENERAL SETUP TV TYPE SETUP This player can play discs recorded in either PAL or NTSC format. Select NTSC format when con- nected to NTSC TV. Select PAL format when con- nected to PAL TV. Select MULTI format; the play- er TV output format will adjust according to the DVD disc format.

  • Page 16: Preference Page

    SETUP --- GENERAL SETUP CAPTION Activate the CAPTIONS feature by selecting ON. Release these feature by selecting OFF. SPEAKER SETUP This is to activate the audio output from DOLBY AC3 5.1 DOWNMIX to two-channel mode. Select the preferred SPEAKER connection by using the cursor buttons.
  • Page 17 PREFERENCE PAGE* DISC MENU LANGUAGE SETUP Select the preferred DISC MENU language by using the cursor buttons. PREFERENCE PAGE* LOCALE Select preferred country by using the cursor but- ton, the player will depend on this setting to choose related setting up. (For example: SUBTI- TLE and MULTI LANGUAGE, etc.) ©...

  • Page 18: Default Settings

    PREFERENCE PAGE* Select RESET to return to the initial, factory settings. *Note: To enter the Preference Page the DVD must be in STOP mode or ejected. DEFAULT SETTINGS GENERAL SET UP TV display Normal/PS TV type Multi PIC mode AUTO Angle mark OSD Language English...

  • Page 19: Installation

    Installation Before installing the unit, connect the wiring temporarily and test the system for proper operation. Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunc- tions. Consult with your nearest dealer if installation requires the drilling of holes or other modifications of the vehicle.

  • Page 20: Din Rear-Mount (Method B)

    REMOVING THE UNIT Trim ring. Remove the trim ring by first detaching the face plate. Then using your fingers, press up and down at the top and bottom of the trim ring and pull out. Insert the removal keys into the slots at either side of the unit until they click.

  • Page 21: Wiring Guide

    Wiring Guide WIRING CONNECTIONS Audio/video outputs for the amplifier and monitor. Inputs for a second audio/video source (i.e., headunit, VCP, or video game). Port for an external IR sensor. This allows the same functions as the IR sensor on the main unit but from a remote location.

  • Page 22: Specifications

    Specifications Supply voltage: Current consumption: Signal system: Discs played: Audio output level: Audio signal output characteristics: NOTE: Specifications and design are subject to modification, without notice, due to improvements in technology. 12V DC (11V-16V), test voltage 14.4V, negative ground Less than 2.0A while operating Composite video 1.0Vp-p 75 RCA pin jack (1) DVD-VIDEO disc 5”...
  • Page 23 The company behind this system is Directed Electronics, Inc. Since its inception, DEI ® has had one purpose, to provide consumers with the finest vehicle security, car stereo products, rear seat entertainment, and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered.
