O W N E R ' S G U I D E
INSTALLATION GUIDE
Slot-Type DVD Player
MODEL DV2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV2005 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed Video DV2005

Summary of Contents for Directed Video DV2005

  • Page 1 O W N E R ’ S G U I D E INSTALLATION GUIDE Slot-Type DVD Player MODEL DV2005...
  • Page 2 © 2002 Directed Electronics, Inc.

  • Page 3: Table Of Contents

    Remote Control Functions ..11 Basic Operation ....12 Turning the Player On/Off...12 © 2002 Directed Electronics, Inc. Play Disc...12 Stop Disc ...12 Remove Disc ...12...

  • Page 4: Limited One-Year Warranty

    Limited One-Year Warranty For a period of ONE YEAR from the date of purchase, Directed Electronics, Inc. ("DIRECTED") promises to the original purchaser to repair or replace, free of cost, with a comparable reconditioned model any DVD PLAY- ER (hereafter the "UNIT”), which proves to be defective...

  • Page 5: Safety Instructions

    Safety Instructions CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VIS- IBLE/INVISIBLE LASER BEAM THAT COULD CAUSE HAZARDOUS RADIATION IF EXPOSED DIRECTLY. BE SURE TO OPERATE THE MOBILE DVD PLAYER AS INSTRUCTED. USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

  • Page 6: Important Safeguards

    In a steamy or very humid vehicle. NOTE: If moisture forms inside this player, it may not operate properly. In this case, turn the power on and wait about one hour for the moisture to evaporate. © 2002 Directed Electronics, Inc.

  • Page 7: Important Information

    10 bit video D/A converter reproduces images faithfully. Auxiliary inputs for use with optional video game console. © 2002 Directed Electronics, Inc. YOUR WARRANTY Your warranty registration must be completely filled out and returned within 10 days of pur- chase. Your product warranty will not be vali- dated if your warranty registration is not returned.

  • Page 8: Disc Notes

    NOTE: A disc may become somewhat scratched (although not enough to make it unusable) depending on how it is handled and conditions in the usage environment. These scratches are not an indica- tion of any problem with the player. © 2002 Directed Electronics, Inc.

  • Page 9: Front Panel Operation

    Loading a Disc - Insert the disc (label side up) into the DISC SLOT (3). Ejecting a Disc - Press EJECT (9) and the disc will slide out. © 2002 Directed Electronics, Inc. Turns the unit on and off. Begins or pauses playback. Insert disc into the slot.

  • Page 10: Remote Operation

    The monitor and audio equipment are properly connected to the player. The power for the monitor and audio equipment is turned on. The input setting for the monitor and audio equipment is properly selected. © 2002 Directed Electronics, Inc.

  • Page 11: Remote Control Functions

    Play/Pause Reverse Skip Rewind Slow Fast Rewind Audio Subtitle Repeat Volume Channel Channel Search A/V Select Mute Program Zoom Go To Step Angle Fast Forward Forward Slow Forward Skip Stop Menu Enter Display Clear Power © 2002 Directed Electronics, Inc.

  • Page 12: Basic Operation

    FSKIP (27) or RSKIP (8) buttons. Press FSKIP (27) or RSKIP (8) to advance to the next chapter/track on the disc. Press FSKIP (27) or RSKIP (8) to return to the previous chapter/track on the disc. © 2002 Directed Electronics, Inc.

  • Page 13: Repeat Play

    Press MUTE (19) to mute the audio portion of the disc during playback. Press again to resume audio playback. © 2002 Directed Electronics, Inc. ZOOM PLAY Press ZOOM (21) during playback to enlarge the picture to twice its size. Press ZOOM (21) again to enlarge the picture to three times its size.

  • Page 14: Advanced Operation

    If a disc that supports closed captioning is being played, the subtitles may overlap the closed cap- tion on the monitor. Turn the subtitles off to avoid this. © 2002 Directed Electronics, Inc.

  • Page 15: Cd/Vcd Operation

    DISC PLAYBACK Press PLAY/PAUSE (7) to begin playback; the screen will show the track information. Some VCDs require number input. © 2002 Directed Electronics, Inc. MP3 OPERATION BASIC MP3 OPERATION Stop Disc, OSD, Mute, Play/Pause, Volume, Skip Tracks, Audio Mode, and Repeat Play operate as described in the Basic Operation section of this guide.

  • Page 16: Setup Menu

    SETUP (4) button. LANGUAGE MENU The Language Menu allows the user to change the subtitle language. PARENTAL LOCK MENU The Parental Lock Menu allows the user to have parental control over the DVDs played. © 2002 Directed Electronics, Inc.

  • Page 17: Audio Menu

    AUDIO MENU The Audio Menu allows the user to change audio type or to turn the audio off. © 2002 Directed Electronics, Inc. DISPLAY OPTIONS MENU The Display Options Menu allows the user to determine the size of the screen and what for-...

  • Page 18: Screen Format

    First determine the screen format for the disc you are playing and adjust the player accordingly. The graphic below gives a depiction of how dif- ferent disc formats will look on a monitor. © 2002 Directed Electronics, Inc.

  • Page 19: Installation

    Always mount the player to a solid location to avoid possible vibration and shock. NOTE: The DV2005 can be mounted vertically or hori- zontally for greater versatility.

  • Page 20: Wiring Connections

    Insert the 1/8" pin plug for the External Remote Sensor eye into this socket. VIDEO SIGNAL - Connect the YELLOW Composite Video RCA cable to this jack. AUDIO SIGNAL - Connect the system L/R stereo Audio RCA cables to these jacks. © 2002 Directed Electronics, Inc.

  • Page 21: Troubleshooting

    2. If the disc won't eject with the EJECT button on the front FORGOT YOUR PASSWORD 1. Press POWER from a cold start with the unit off. Press the 2. Press the SETUP button on the remote control to select © 2002 Directed Electronics, Inc. lowered. improper connections. improper connections.

  • Page 22: Specifications

    48 kHz Sampling: 4Hz to 22 kHz 96 kHz Sampling: 4Hz to 44 kHz 110 dB 100 dB 0.02% 1.0 Vp-p 47k ohm unbalanced, RCA jack Line Input -8.8 dBm, 47k ohm minimum Air: 2~69 Channels CATV: 1~125 Channels © 2002 Directed Electronics, Inc.
  • Page 23 © 2002 Directed Electronics, Inc.
  • Page 24 The recipient of more than 20 patents in the field of advanced electronic technology, Directed is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world. Call (800) 274-0200 for more information about our products and services.
