O W N E R ' S G U I D E
INSTALLATION GUIDE
Drawer-Type DVD Player
MODEL DV1700

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV1700 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed Video DV1700

Summary of Contents for Directed Video DV1700

  • Page 1 O W N E R ’ S G U I D E INSTALLATION GUIDE Drawer-Type DVD Player MODEL DV1700...

  • Page 2: Table Of Contents

    Table of Contents Limited One-Year Warranty..3 Safety Instructions ... . 4 Region Management Information ...4 Important Safeguards ..4 When Driving ...4 When Car Washing ...4 When Parked...4...

  • Page 3: Limited One-Year Warranty

    Limited One-Year Warranty For a period of ONE YEAR from the date of purchase, Directed Electronics, Inc. ("DIRECTED") promises to the original purchaser to repair or replace, free of cost, with a comparable reconditioned model any DVD PLAY- ER (hereafter the "UNIT”), which proves to be defective in workmanship or material defect under normal use, provided the following conditions are met: the unit was purchased and installed by an authorized DIRECTED...

  • Page 4: Safety Instructions

    Safety Instructions CAUTION: MOBILE DVD PLAYER IS A CLASS I LASER PRODUCT. HOWEVER THIS MOBILE DVD PLAYER USES A VIS- IBLE/INVISIBLE LASER BEAM THAT COULD CAUSE HAZARDOUS RADIATION IF EXPOSED DIRECTLY. BE SURE TO OPERATE THE MOBILE DVD PLAYER AS INSTRUCTED. USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

  • Page 5: Protect The Disc Mechanism

    PROTECT THE DISC MECHANISM Avoid inserting any foreign objects into the disc tray of this player. Failure to observe this may cause malfunction due to the precise mechanism of this unit. REPAIRS Do not attempt to disassemble or adjust this precision product.

  • Page 6: Important Information

    Important Information FCC NOTICE This device complies with Part 15 of FCC rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interfer- ence that may cause undesired operation.

  • Page 7: Disc Notes

    Disc Notes DISC FORMATS SUPPORTED BY THIS PLAYER VI D EO 12 cm disc/8 cm disc (Single-sided disc only) Video CD 12 cm disc/8 cm disc Super-VCD 12 cm disc CD/MP3 12 cm disc/8 cm disc DISC FORMATS NOT SUPPORTED BY THIS PLAYER ■...

  • Page 8: Front Panel Operation

    Front Panel Operation FRONT PANEL FEATURES On/Standby Button Video Input Audio Input Display Panel Disc Tray Play/Stop/Pause/Menu Button Open/Close Button FRONT PANEL CONTROLS ■ Power ON/OFF - Press ON/STANDBY button (1) to turn the unit on/off. ■ Loading a Disc - Press OPEN/CLOSE button (7) and set the disc (label side up) onto the disc tray (4).

  • Page 9: Display Panel Operation

    Display Panel Operation DISPLAY PANEL FEATURES DVD Indicator Title Indicator Chapter/Track Indicator Repeat Play Indicator Second Indicator Minute Indicator Hour Indicator Title/Chapter/Track Indicator Pause Indicator Play Indicator PBC Indicator © 2003 Directed Electronics, Inc.

  • Page 10: Remote Operation

    Installation section of this guide. ■ If the DVD player is connected to the mon- itor through a VCR, the picture may not be played back normally. It is strongly recom- mended not connecting the DVD player through a VCR.

  • Page 11: Remote Control Functions

    Remote Control Functions BUTTON FUNCTION OPEN/CLOSE DVD & MV/TV SELECT SUBTITLE LANGUAGE REPEAT A-B REPEAT VOLUME FR/FF SEARCH PBC/SLOW SETUP DIRECTION BUTTONS PLAY/ENTER TITLE ZOOM MENU PAUSE/STEP STOP PREVIOUS/NEXT AUDIO MODE RETURN SYSTEM TV/AV MUTE POWER © 2003 Directed Electronics, Inc.

  • Page 12: Basic Operation

    Basic Operation Operations in this section are common for all discs types (DVD, CD, Video CD, and Super-VCD). TURNING THE PLAYER ON/OFF Press on the remote control to turn POWER (25) the player on, off, or to standby mode. PLAY DISC Press POWER (25) to turn on the player.

  • Page 13: Timed Repeat Play

    ■ REPEAT CHAPTER - Repeats the DVD chap- ter or the audio CD track. ■ REPEAT TITLE - Repeats the DVD title or the Audio CD title. ■ REPEAT OFF - Repeat function discontinued TIMED REPEAT PLAY Sections of chapters/tracks can be chosen and repeated with the A-B (6) button.

  • Page 14: Advanced Operation

    Advanced Operation DVD OPERATION TITLE MENU The title menu has selections for disc playback setup that usually include audio, language, sub- titles, playback and special features. The avail- able selections are determined by the recorded material on the disc. Press TITLE (13) on the remote and the title menu will be displayed.

  • Page 15: Cd/Vcd Operation

    LANGUAGE CONTROL Many discs have several languages available dur- ing disc playback. They can be changed at any time by pressing LANGUAGE (4). Each time the button is pressed, the language will change and the information about the current language will appear in the OSD.

  • Page 16: Setup Menu

    If the menu appears on more than one page the << >> icons will be displayed. Use the PREVI- OUS/NEXT (18) buttons to move to the addi- tional menu pages. Use the PREVIOUS/NEXT (18) buttons to high- light an ALBUM or ROOT then press PLAY (12). If an ALBUM is selected, the album sub-menu will be displayed.

  • Page 17: General Setup Page

    GENERAL SETUP PAGE When the General Setup page has been entered the on-screen display will appear as shown. TV DISPLAY The TV Display submenu sets the screen shape output to match the type of monitor connected. For information about monitor types refer to the Screen Format section of this guide.

  • Page 18: Preferences Page

    Enter the Password by pressing NEXT (18) five times. Press PLAY (12) to enter the password; the Password Setup Page will appear. Then press the left DIRECTION BUTTON (11) to highlight the password mode. The password mode is now set. PREFERENCES PAGE Enter the Preferences Page.

  • Page 19: Screen Format

    SCREEN FORMAT TV SYSTEM NTSC is the default setting and is the standard system for video monitors in North America. PAL, PAL 60, and PAL M are settings for moni- tors outside the North American continent. Consult your authorized dealer for the proper setting.

  • Page 20: Installation

    Installation CONNECTING TO A STEREO TV BASIC CONNECTION ■ Do not block ventilation holes of the DVD player and arrange it so air can circulate freely. ■ Read these instructions thoroughly before connecting audio and video cables. ■ Ensure that you observe the color coding when connecting audio and video cables.

  • Page 21: Wiring Connections

    WIRING CONNECTIONS POWER CONNECTOR - The RED power wire must be connected to a wire that has (+) 12 volts when the key is in the accessory posi- tion. The BLACK ground wire must be con- nected to a metal chassis point, preferably scraped sheet metal.

  • Page 22: Troubleshooting

    Troubleshooting PROBLEM NO SOUND NO PICTURE NO REMOTE FUNCTION PARTIAL OR NO DISPLAY DISC TRAY WON'T OPEN SOLUTION 1. Check all audio cable connectors in the system for loose or improper connections. 2. Test system components for proper power and operation. 3.

  • Page 23: Specifications

    Specifications Laser: Video System: Frequency Response: Signal/Noise Ratio: Audio Distortion/Noise: Channel Separation Dynamic Range Output - Audio Out (Analog) Output - Video Out Power Supply Environment Temperature Power Consumption Dimensions Weight NOTE: Specifications and design are subject to modification, without notice, due to improvements in technology. ©...
  • Page 24 The company behind this system is Directed Electronics, Inc. Since its inception, DEI ® has had one purpose, to provide consumers with the finest vehicle security, car stereo products, rear seat entertainment, and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered.
