Table 6: Ratings & Physical / Electrical Data
Input
BTUH/
Max/Min
Cabinet/CFM
MBH
60B12 60/21 17.6/6.2
80B12 80/28 23.4/8.2
80C16 80/28 23.4/8.2
100C16 100/35 29.3/10.2
100C20 100/35 29.3/10.2
120D20 120/42 35.1/12.3
Max. Outlet
BTUH
Air Temp
Cabinet/CFM
°F
60B12 170
80B12 175
80C16 175
100C16 175
100C20 180
120D20 180
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
SUPPLY VOLTAGE CONNECTIONS
Junction
Box
Connect ground
lead to screw
Electrical Entry
L1-Hot
BLK
Neutral
WHT
FIGURE 17: Electrical Wiring
1. Provide a power supply separate from all other circuits. Install
overcurrent protection and disconnect switch per local/national
electrical codes. The switch should be close to the unit for conve-
nience in servicing. With the disconnect or fused switch in the OFF
position, check all wiring against the unit wiring label. Refer to the
wiring diagram in this instruction.
12
Output
Max/Min
kW MBH kW
58/20 17.0/5.9
77/27 22.6/7.9
78/27 22.8/7.9
97/34 28.4/10.0
97/34 28.4/10.0
116/40 34.0/11.7
Blower
°C HP Amps
76.7 1/2 4.8
79.4 1/2 4.8
79.4 3/4 7.5
79.4 3/4 7.5
82.2 1 14.5
82.2 1 14.5
Nominal Air Temp. Rise
Airflow Max Input
3
CFM °F
m /min
1200 34.0 40-70
1200 34.0 40-70
1600 45.3 40-70
1600 45.3 40-70
2000 56.6 45-75
2000 56.6 45-75
Blower Max
AFUE
Wheel Over-Current
Size Protect
%
11 x 8 97.5 15
11 x 8 97.5 15
11 x 10 97.7 15
11 x 10 97.7 15
11 x 11 97.7 20
11 x 11 98.0 20
2. Remove the screws retaining the wiring box cover. Route the
power wiring through the opening in the unit into the junction box
with a conduit connector or other proper connection. In the junc-
tion box there will be 3 wires, a Black Wire, a White Wire. Connect
the power supply as shown on the unit-wiring label on the inside of
the blower compartment door or the wiring schematic in this sec-
tion. The black furnace lead must be connected to the L1 (hot)
wire from the power supply. The white furnace screw must be con-
nected to neutral. Connect the power supply ground to the green
screw (equipment ground) An alternate wiring method is to use a
field provided 2" (5.1 cm) x 4" (10.2 cm) box and cover on the out-
side of the furnace. Route the furnace leads into the box using a
protective bushing where the wires pass through the furnace
panel. After making the wiring connections replace the wiring box
cover and screws. Refer to Figure 17.
3. The furnace's control system requires correct polarity of the power
supply and a proper ground connection. Refer to Figure 17.
The power connection leads and wiring box may be relocated to the
left side of the furnace. Remove the screws and cut wire tie holding
excess wiring. Reposition on the left side of the furnace and fasten
using holes provided.
Air Temp. Rise
Min Input
°C °F
22-39 20-50
22-39 20-50
22-39 20-50
22-39 20-50
25-42 25-55
25-42 25-55
Approximate
Min. wire Size
Total Unit
Operating Wgt.
(awg) @ 75 ft
Amps
one way
7.0 14
7.5 14
10.0 14
10.0 14
12.0 12
12.0 12
