Published Manual Number/ECN: MPP52WE1AE/2000183N
• Publishing System: TPAS
• Access date: 04/27/2000
• Document ECN's: Latest Available
Service—
52038 WP1/WTL/WTN
Washer Extractors
PELLERIN MILNOR CORPORATION
POST OFFICE BOX 400, KENNER, LOUISIANA 70063-0400, U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 52038 WP1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Milnor 52038 WP1

Summary of Contents for Milnor 52038 WP1

  • Page 1 Published Manual Number/ECN: MPP52WE1AE/2000183N • Publishing System: TPAS • Access date: 04/27/2000 • Document ECN's: Latest Available Service— 52038 WP1/WTL/WTN Washer Extractors PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063-0400, U.S.A.
  • Page 2 “Troubleshooting” chapter or section. See the table of contents. Trademarks of Pellerin Milnor Corporation The following, some of which may be used in this manual, are trademarks of Pellerin Milnor Corporation: ®...

  • Page 3: Table Of Contents

    Table of Contents for MPP52WE1AE/2000183N 52038 WP1/WTL/WTN Washer Extractors Page Description Document/ECN About This Manual MHPHYDROAE/9541AV Warranty BMP720097/92732A How to Order Parts BMP720097R/72332A Installation and Service Safety for Suspended Washer-Extractors and Centrifugal Extractors MSINA405AE/9909AV Glossary of Tag Illustrations - Suspended Washer-...

  • Page 4: Page Description

    Table of Contents, cont. Page Description Document/ECN Suspension Adjustments for Open Pocket, Hydro- Cushion Machines MSSM0208AE/8506BV Suspension Cylinder Locations BMP701235/2000133V Suspension Cylinder Assembly BMP701408/2000133V Section 6: Control and Sensing Devices Description and Maintenance of the Electronic Balancing System for Washer-Extractors and Textile Machines MSSMA401BE/9526AV Vibration Safety Switch Adjust...
  • Page 5 Table of Contents, cont. Page Description Document/ECN Section 10: Hydraulic Schematics and Devices 52038, 64042, 72044 Tilt 1 Way Manual Door Hydraulic Schematiac BMP850006/85097A 52038, 64042, 72044 Tilt 2 Ways Manual Door Hydraulic Schematic BMP850007/85097A 52038, 64042, 72044 Tilt 1 Way Auto Door Hydraulic Schematic BMP850008/85097A 52038, 64042, 72044 Tilt 2 Ways Auto Door...

  • Page 7: About This Manual

    Fax: (504) 467-9777 P. O. Box 400 Kenner, LA 70063-0400 Ë T rademarks of Pellerin Milnor Corporation —The following, some of which may be used in this pub- lication, are trademarks of Pellerin Milnor Corporation: ® ® ® ® ®...
  • Page 8 MSSM0201CE/9840AV (2 of 11)

  • Page 9: Warranty

    (including purchased components) without obligation to change any equipment previously supplied. ANY SALE OR FURNISHING OF ANY EQUIPMENT BY MILNOR IS MADE ONLY UPON THE EXPRESS UNDERSTANDING THAT MILNOR MAKES NO EXPRESSED OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR USE OR PURPOSE.

  • Page 11: How To Order Parts

    How to order repair parts Repair parts may be ordered either from the authorized dealer who sold you this machine, or directly from the MILNOR factory. In most cases, your dealer will have these parts in stock. When ordering parts, please be sure to give us the following information: 1.

  • Page 12: Installation And Service Safety For Suspended

    (owner/user) is responsible for understanding and ensuring the proper operation and maintenance of the machine. The owner/user must familiarize himself with the contents of all machine instruc- ® tion manuals. The owner/user should direct any questions about these instructions to a Milnor dealer or the Mil- ®...
  • Page 13 Ê H azards During Installation ELECTROCUTION HAZARD—Contact with high voltages can kill or seriously injure you. All electrical connections must be made by a competent electrician. EQUIPMENT DAMAGE HAZARD—Machine can be damaged if shipping re- straints are improperly utilized. These include various bolts, brackets, and safety stands (painted red), brake blocks and the vibration safety switch (tie wrapped).
  • Page 14 MULTIPLE HAZARDS—Failure to maintain machine in proper working order can result in fatal or serious injury to operators and/or damage to property. DO NOT permit operation under any of the following circumstances: Malfunctioning door interlock mechanism. Malfunctioning limit switches. Malfunctioning two hand inching. Any evidence of cylinder damage.
  • Page 15 Ê A dditional Hazards During Tilting Machine Maintenance CRUSH/SEVER HAZARD—Tilting mechanisms can crush or sever parts of your body caught in them. Install the safety stands before performing maintenance under a tilted ma- chine. NEVER test or operate (manually or automatically) any machine function with any portion of a person’s body under the tilted machine—even if the safety stands are installed.
  • Page 17 <B8D?DC604(''0E Illustration Explanation Stop! Read the manual first for complete instructions before continuing. Do not jack the machine here. Do not lift the machine here. Use three point or four point lifting as determined by the lifting eyes furnished. Rig the load using lifting cables of sufficient size and length to en sure cables are not over-stressed.
  • Page 18 Illustration Explanation Do not start this machine until the packing materials, lifting brackets, etc. with this tag attached or behind this panel are removed. These materials are painted red. Safety stands or brackets (also painted red) may be provided with this machine. Do not discard safety stands or brackets Do not step or stand on this machine part.
  • Page 19 7\_ccQbi _V DQW 9\\ecdbQdY_^c± Cec`U^TUT GQcXUb5hdbQSd_bc Do not start this machine until the part with this tag is installed on the machine. Do not remove this component from the machine. Install the appropriate part here before operating the machine. Do not strap or chain over box...
  • Page 20 =C9E@ED715)( (1F "  # Do not pump grease here. During drain and extract, the cylinder must rotate counterclockwise when viewed from here. During drain and extract, the cylinder must rotate clockwise when viewed from here. & Do not strike shell front of washer-extractors during fork lifting.
  • Page 21 7\_ccQbi _V DQW 9\\ecdbQdY_^c± Cec`U^TUT GQcXUb5hdbQSd_bc Set main bearing air pad gauge at 10 psi (.70 kg/cm ), 64" and 72" ExN and JxN models only. Set disc brake air gauge at 10 psi (.70 kg/cm ), 64" and 72" ExN and JxN models only.

  • Page 23: Section 1: Service And Maintenance

    Section Service and Maintenance...

  • Page 24: Lubrication And Preventive Maintenance For Hydro-Cushion Machines

    Ê G eneral Requirements Maintenance procedures require: • A hand operated grease gun. • The correct lubricants (see “LUBRICANTS FOR MILNOR MACHINES,” in the Table of Contents). Ê L ubricant Requirements ® To achieve the optimum performance and service life from the Milnor machine and as a warranty require- ment, the machine must be lubricated in strict accordance with the instructions in this section.
  • Page 25 MSSM0201CE/9840AV (2 of 11) CRUSH/SEVER HAZARD—Tilting machines with tilt wheels/cradles may lunge forward or rearward and even fall over if the tilt wheels at the non-tilted end are raised out of their cradles—killing/injuring personnel and/or damaging prop- erty. NEVER manually tilt (lift) both ends of the machine at the same time. One end must always be seated in its cradle.
  • Page 36 <BB<!&#04(&" 0E Most of the information in this document is taken from the Baldor Electric Company Instruction, Operation, and Maintenance Manual, and provides a means of more accurately determining motor lubrication requirements based on local conditions. Inspect, clean, and test motors at regular intervals— approximately every 500 operating hours or every three months, whichever comes first.
  • Page 37 21<4?B =?D?B =19>D5>1>35 =CC= "'$15)'#!1F"$ —The useful life of antifriction bearing grease can be estimated, based on service conditions, frame type, and motor rpm. An example of determining the correct lubrication interval is provided below. Ex: A fan motor, operating at an ambient temperature of 109 F (43 C) in a moderately corrosive atmosphere.
  • Page 38 21<4?B =?D?B =19>D5>1>35 =CC= "'$15)'#!1F#$ Table 3 — Recommended Lubrication Intervals at Standard Service Conditions NEMA (IEC) Rated Speed - RPM Frame Size 3600 1800 1200 Up to 215 (132) 5500 Hrs. 12000 Hrs. 18000 Hrs. 22000 Hrs. 254 to 286 (160 - 180) 3600 Hrs.
  • Page 39 21<4?B =?D?B =19>D5>1>35 =CC= "'$15)'#!1F$$ —Use Shell Dolium R (factory installed) or Chevron SRI greases for standard service conditions. The extreme and low temperature conditions are not normally encountered in the laundry. However, for extreme conditions, use Darmex 707 and for low temperature conditions, use Arrowshell 7.
  • Page 40 <BB<!& 04(&#0E 41>75B* 5>D1>7<5 1>4 3BEC8 81J1B4 2^]cPRc fXcW \^eX]V R^\_^]T]cb ]^a\P[[h Xb^[PcTS Qh VdPaSb R^eTab P]S _P]T[b T]cP]V[T RadbW h^da [X\Qb CWTbT R^\_^]T]cb \^eT Pdc^\PcXRP[[h 3^ ]^c bTaeXRT d][Tbb `dP[XUXTS P]S PdcW^aXiTS ;^RZ >55 P]S cPV ^dc _^fTa Pc cWT fP[[ SXbR^]]TRc QTU^aT bTaeXRX]V ^a X] PRR^aSP]RT fXcW UPRc^ah bTaeXRT _a^RTSdaTb —This procedure requires bulb pump kit (p/n KZ5CP00100), one gallon (3.8 liters) of mineral spirits, a hand operated grease pump, and the specified lubricants.
  • Page 41 6<EC89>7 G1D5B C51<C 1>4 <51;?66C =CC= "'!15)' $1F"# 9> %" 1>4 <1B75B G1C85B5HDB13D?BC >?D935* 251B9>7 41=175 81J1B4 140A8=6 30<064 70I0A3°1TPaX]Vb fX[[ `dXRZ[h Qda] VaTPbT R^]cP\X]PcTS Qh \X]TaP[ b_XaXcb 3> =>C PccT\_c c^ U^aRT \X]TaP[ b_XaXcb X]c^ cWT QTPaX]V W^dbX]V 8U \X]TaP[ b_XaXcb S^ ]^c U[^f TPbX[h cWa^dVW cWT bTP[ RPeXch VaTPbT aT[XTU P]S [TPZ^UU aTP\ ^dc VaTPbT aT[XTU P]S [TPZ^UU SaPX] 3>...
  • Page 42 6<EC89>7 G1D5B C51<C 1>4 <51;?66C =CC= "'!15)' $1F## 9> %" 1>4 <1B75B G1C85B5HDB13D?BC Internal passage Vented plug Remove the vented plug at the flushing connection to leak-off for flushing and install the bulb pump. cavity connection Pump approximately two quarts (1.9 liters) of mineral spirits into the flushing connection until the spirits flow easily out of the leak-off drains.

  • Page 43: Fastener Torque Requirements

    The specifications in this section apply to 1/4 inch and larger Unified National fine and coarse fasteners used on ® Milnor machines. This information is to be used only when torque specifications are not stated in the installation or service instructions.
  • Page 44 MSSM0101CE/9906AV (2 of 19) Ê A pplying Threadlocker NOTE: The following threadlocker information and ® illustrations are excerpts from the Loctite User’s Guide and are used with permission. For maximum strength, threadlocker must fill the thread voids completely, as shown in FIGURE 2. Organic or petro- leum solvent will remove excess uncured adhesive from joints.
  • Page 45 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (3 of 19) Ë R emoving Fasteners ® High strength threadlockers like Loctite 271 (or equivalent) may be weakened by heating to at least 500 F (260 C) as follows. 1. Apply localized heat to fastener as shown in FIGURE 5. 2.
  • Page 46 MSSM0101CE/9906AV (4 of 19) Ï A ll values in foot pounds and (Newton meters) Nomi- Grade Designation Zinc or If instructions call for : nal bolt and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare size Plated 222 or 1/4 - 28 SAE Grade 1 ASTM A307 (3.80)
  • Page 47 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (5 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc If instructions call for : bolt size and Standard orCadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 5/16 - 24 SAE Grade 1 10.4 ASTM A307...
  • Page 48 MSSM0101CE/9906AV (6 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for : bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 3/8 - 24 SAE Grade 1 10.2 12.2...
  • Page 49 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (7 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Zinc or If instructions call for : bolt size Designation and Cadmium Loctite Loctite Loctite Loctite Loctite Bare Standard Plated 222 or 7/16 - 20 SAE Grade 1 16.0 19.2...
  • Page 50 MSSM0101CE/9906AV (8 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Standard and Zinc or If instructions call for : bolt size Grade Designation Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 1/2 - 20 SAE Grade 1 24.8 29.8...
  • Page 51 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (9 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for: bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 9/16 - 18 SAE Grade 1 35.3 42.4...
  • Page 52 MSSM0101CE/9906AV (10 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for: bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 5/8 - 18 SAE Grade 1 49.5 59.4...
  • Page 53 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (11 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for: bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 3/4 - 16 SAE Grade 1 86.5...
  • Page 54 MSSM0101CE/9906AV (12 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for: bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 7/8 - 14 SAE Grade 1 137.8 165.4...
  • Page 55 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (13 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Zinc or If instructions call for : bolt size Designation and Cadmium Loctite Loctite Loctite Loctite Loctite Bare Standard Plated 222 or 1 - 12 SAE Grade 1 205.3...
  • Page 56 MSSM0101CE/9906AV (14 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for : bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 1-1/8 • 7 SAE Grade 1 265.8 318.9 354.4...
  • Page 57 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (15 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Zinc or If instructions call for : bolt size Designation and Cadmium Loctite Loctite Loctite Loctite Loctite Bare Standard Plated 222 or 1-1/4 •...
  • Page 58 MSSM0101CE/9906AV (16 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for : bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 1-3/8 • 6 SAE Grade 1 491.1 589.4 654.8...
  • Page 59 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (17 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Zinc or If instructions call for : bolt size Designation and Cadmium Loctite Loctite Loctite Loctite Loctite Bare Standard Plated 222 or 1-1/2 •...
  • Page 60 MSSM0101CE/9906AV (18 of 19) Ï O ther Fastener Torque Specifications Ï A ll values in foot-pounds and (Newton-meters) Nominal bolt size 18 - 8 Brass Aluminum Stainless Steel Stainless Steel 2024 - T4 1/4 - 20 6.3 (8.54) 6.6 (8.95) 5.1 (6.91) 3.8 (5.15) 1/4 - 28...
  • Page 61 FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (19 of 19) Ï O ther Fastener Torque Specifications Ï A ll values in foot-pounds and (Newton-meters) Nominal bolt size 18 - 8 Brass Aluminum Stainless Steel Stainless Steel 2024 - T4 7/8 - 9 194.0 (263.03) 202.5 (274.55) 158.8 (215.30) 124.6 (168.93)

  • Page 63: Section 2: Shell And Door Assemblies

    Section Shell and Door Assemblies...

  • Page 67: Section 3: Drive Assemblies

    Section Drive Assemblies...

  • Page 68: Drive Base Components On Hydro-Cushion Machines

    A dvance Preparations for Drive Assembly Maintenance ® The drive train on your Milnor machine has been designed to give long, trouble-free service under continu- ous use. Strict adherence to the lubrication schedule, proper belt tensioning, and the normal good practice of inspect-...
  • Page 69 Wash motor Drain motor E1 motor is optional on 42" and 48" machines and standard on larger Gear re- models ducer E-1 mo- E-2 mo- Centrifugal switch Jackshaft pulley Clutch drum (clutch tire in- side) A jackshaft (not shown) is Brake (42"...
  • Page 70 Part numbers for belts, pulleys, and related components may be found on the Drive Chart and/or Drive Assem- ® bly drawings for your machine. When ordering motors and motor parts from the Milnor factory, provide the machine model and serial number and the motor function (i.e., wash, drain, E1 (low extract), E2 (high extract) or ®...
  • Page 71 Ë T o Replace Pulleys and Belt(s) 1. Clean the tapered bore of the sheave, mating surface of the bushing, bore of the bushing, and the shaft until free of any foreign substance (including paint). NOTE: Do not use lubricants, “Locktite,” or other adhesives on these mating surfaces. 2.
  • Page 72 the motor position with the motor mount (or other component) jack screws until all slack is taken up. Do not force belts onto the sheaves by using a pry bar or rolling the sheaves. 6. Check for sheave alignment as shown in FIGURES 3. The sheaves must be aligned within 1/64" per foot be- tween shaft centerlines and in no case greater than 1/8".

  • Page 73: Reducer Air Seal

    “short circuit” exhaust connection near the clutch. The quick release valve is necessary for the clutch used on ® Milnor washer-extractors, and is furnished as original equipment. The air supplied to the clutch must be free of oil and moisture.
  • Page 74 It is essential when removing the gear reducer, to record the positions of these shims so that they may be replaced in the exact same position later. Bearing this in mind, carefully remove the gear reducer mount- ing bracket (with the reducer attached) from the drive base. Note that the clutch tire, attached to the reducer output shaft, must be allowed to slip out of the clutch drum as the reducer is removed.
  • Page 75 3. Temporarily disconnect the internal air line to the gear reducer and connect an external, valve-controlled air line to the reducer, but do not inflate the tire yet. 4. Loosen but do not remove the bolts that attach the gear reducer mounting brackets to the drive base. (On 64" machine models, check to be sure the jacking bolts under the input shaft side of the reducer are resting on the drive base then loosen the bolts and remove the dowel pins if they were reinstalled.) 5.
  • Page 76 To replace the jackshaft, reassemble all components in reverse order of their removal. Make certain that the jackshaft is properly oriented with the clutch end of the shaft to the front of the machine and that all shims are returned to their original positions. Install all jackshaft mounting bolts hand tight. Lift each end of the jackshaft with a pry bar (one end at a time) then tighten the bolts on that end, so that the jackshaft will sit as high as possible in the housing.

  • Page 77: Centrifugal Switch Assembly

    Ê C entrifugal Switch Ë C oncept of Operation —After an extraction, the centrifugal switch will signal the Miltrol as soon as the washer cylinder has slowed sufficiently to permit the wash speed clutch to re-engage. Also, until this low speed has been attained, the Miltrol circuits prevent the opening of the shell door, thus providing safety interlocking.

  • Page 79: Parts List-Drive Base Assembly

    Drive Base Assembly BMP740129R/89086A (Sheet 1 of 2) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Drive Base Assembly Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 80 BMP740129R/89086A (Sheet 2 of 2) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List, cont.—Drive Base Assembly Description Item Part Number Comments Used In P044 15G232 SQNUT 1/2-13UNC3B SAE ZINC GR2 P045 15U475 SQFLATWASHER 1/64X2X2 9/16ID ZINCPL...

  • Page 82: Parts List - 5238 Weu Drive Chart (50 & 60 Cycle)

    5238 WEU Drive Chart BMP740120R/97108V (Sheet 1 of 1) 50 + 60C Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—5238 WEU Drive Chart Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...

  • Page 85: Brake Installation - 5238

    Brake Installation BMP750050R/85341A 52038 (Sheet 1 of 1) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—BRAKE INSTALLATION Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...

  • Page 87: Jackshaft Bearing Assembly - 5238, 6036, 6044

    Jackshaft Bearing Assembly BMP820109R/89253A 52, 60, 64, 72 (Sheet 1 of 2) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Jackshaft Bearing Assembly Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 88 BMP820109R/89253A (Sheet 2 of 2) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List, cont.—Jackshaft Bearing Assembly Description Item Part Number Comments Used In X2 19381 94182D BEARHOUSE=LG BRG REAR TIMKEN...
  • Page 91 72044SG3 72044WE2 72044WE3 72044WTB 72044WTG 72044WTH ® A belt tension testing device (Milnor part number 30T001) and a straight edge are required when tensioning unbanded belts. Ê T ension Settings—Unbanded Belts Set the o-rings on the tension testing device (see FIGURE 1) as follows: 1.
  • Page 92 Ê B elt Tension Measurements Ë U nbanded Belts 1. Place a straight edge along the top edge of the belt to be tested so that it spans both pulleys. Place the tension tester in the center of the belt and press down on the cap until the lower o-ring is in line with the straight edge, as shown.
  • Page 93 Ë T ensioning Banded Belts Ï 4 8032BHE, BTG, BTH 48036QHE, QTG, QT Belt Initial Initial Belt Initial Initial Deflect. Tension Tension Deflect Tension Tension (inches) (lbs.) (ref.) (lbs.) (ref.) (in.) (lbs.) (ref.) (lbs.) (ref.) WASH/ 2 SPEED 9/32 6.6 - 9.2 5.1 - 7.1 5/16 5.7 - 7.6...
  • Page 94 Ï Ï 4 8032BHE, BTG, BTH 48036QHE, QTG, QT Belt Initial Initial Belt Initial Initial Deflect. Tension Tension Deflect Tension Tension (inches) (lbs.) (ref.) (lbs.) (ref.) (in.) (lbs.) (ref.) (lbs.) (ref.) WASH/ 2 SPEED 5.7 - 7.6 4.4 - 5.9 17/64 5.7 - 7.6 4.4 - 5.9...

  • Page 95: Section 4: Bearing Assemblies

    Section Bearing Assemblies...

  • Page 100: Air Inject Assembly

    BMP970012/99303V (Sheet 2 of 2) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Air Inject Assembly Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...

  • Page 101: Section 5: Frame, Pivots And Suspension

    Section Frame, Pivots and Suspension...
  • Page 102 ® POCKET, HYDRO-CUSHION MACHINES ® ® The suspension system on Milnor Hydro-cushion machines is adjusted and thoroughly tested at the factory. It should not require subsequent adjustment unless the machine is distorted during shipment or installation or unless ® some component of the system, such as a Hydro-cushion cylinder is replaced.
  • Page 103 ® Hydro-cushion Frame adjusting and lock nuts Shell ® Hydro-cushion cylinder Push-down device (air bag) Rest pad Push-down travel dimension Î F IGURE 1 (MSSM0208AE) ® Î H ydro-cushion Suspension System Components (Does not depict a specific machine) ® Hydro-cushion shaft Locknut Keypad lock-...
  • Page 104 Ê A djustments to 42" and 48" Machines Ë S hell Hanging Dimensions and Adjustment Procedures —These machine models have three ® Hydro-cushion cylinders: one on each front corner and one centered in the rear. Locate the shell hanging dimen- sions for your machine in FIGURE 3 and adjust your machine accordingly.
  • Page 105 Some of the following procedures require power to the machine. Take the necessary precautions to assure that no-one operates the machine controls while personnel are ad- justing the push-down components. To adjust the push-down travel, proceed as follows: 1. With the Master switch set to off and the shell hanging free, verify that gaps A and B as shown in FIGURE 4 are correct for your machine.
  • Page 106 Ê A djustments to 52" and 72" Machines Ë S hell Hanging Dimensions and Adjustment Procedures —To adjust the shell, see FIGURES 5 and 6 and proceed as follows: 1. Locate the shell hanging dimensions for your machine in the table and illustration in FIGURES 5 and 6 and adjust your machine accordingly.
  • Page 107 Frame Shell front *This dimension ap- Shell plies to all 72" Open- 3/4 Shim back pocket machine models. 72044WE1 72044WTG 72044WTH 28" 72044WTB NOTE: On these machines, the frame slopes as well as the shell and cylinder. Bubble Level Tilt base (tilting machines only) 3 7/8"...
  • Page 108 Mounting bracket Shell Shell (hanging (hanging free) free) Frame 2" Shims Shims Ring Ring weldment weldment Î F IGURE 7 (MSSM0208AE) Î S himming and Reconnecting Ring Weldments To adjust the push-down travel, proceed as follows: 1. With the Master switch set to off and the shell hanging free, remove the bolts securing the ring weldments to the mounting brackets.
  • Page 109 5. While observing the movement of the shell, cycle the Master switch between off and manual. 6. If any rocking or twisting motion of the shell is detected as the shell pushes down, throttle the air supply valve(s) as required, to achieve a smooth even downward motion of the shell. NOTE: On 72"...
  • Page 110 —The procedures herein apply to the following machine models: 64042BHP 64042BTL (AAC) and later models 64042BTN (AAC) and later models For adjustments to 64042BTL (AAA) or (AAB) models and 64042BTN (AAA) or (AAB) models consult the ® Milnor factory. Ë S hell Hanging Dimensions and Adjustment Procedures Shell —...
  • Page 111 2. Set the ring weldments on top of the plugs then measure the gap between each ring weldment and its mount- ing. 3. Remove or add shims where shown in FIGURES 10 and 11 to achieve the gaps shown. If the gap at any loca- tion is less than that specified, without shims, the shell must then be raised in the frame, using the proce- dures previously described.
  • Page 112 Ring weldments (bolted in position) Shims Plugs REAR FRONT Î F IGURE 11 (MSSM0208AE) Î R econnecting Ring Weldments (64" Machines)

  • Page 113: Suspension Cylinder Locations

    Suspension Cylinder Locations BMP701235/2000133V Use with BMP701408 (Sheet 1 of 1) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Note: A letter is stamped CYLINDER #4 on the end of the upper bolt to designate the cylinder assembly.
  • Page 117 Section Control and Sensing Devices...
  • Page 118 MSSMA401BE/9526AV È D ESCRIPTION AND MAINTENANCE OF THE ELECTRONIC BALANCING SYSTEM FOR WASHER-EXTRACTORS AND TEXTILE MACHINES Ê C omponents of the Balancing System The water balancing system consists of electrical and me- chanical components which sense the location and magnitude of an imbalance in the cylinder, and by injecting water into the rib (or ribs) opposite that imbalance, re-balance the cylinder.
  • Page 119 Î F IGURE 3 (MSSMA401BE) Î F IGURE 4 Î B alance Board Details (MSSMA401BE) Î P roximity Switch and Tar- recycle, if shell excursions or an out-of-balance condition exceed acceptable get ( 64046 E6N shown) limits. The machine excursion input causes a recycle at any time in extract, whereas the balance excursion input is checked just before the onset of high speed extraction, and then again from a few seconds after the onset of high speed extract throughout the remainder of extraction.
  • Page 120 Ê H ow the Balancing System Works Determining where the imbalance is and correcting the imbalance takes place in two steps over several revo- lutions. FIGURE 6, Step One—Finding the Imbalance, describes in detail how the machine determines the location of the imbalance.
  • Page 122 Ê M onitoring the Balancing System Status panel lamps monitor balancing system functions. This status panel (FIGURE 8), includes: Ë B alance Excursion Lamp —This lamp illuminates whenever the three wire circuit is energized. If this lamp extin- guishes during E1 (low extract), the ma- chine will not enter E2 (high extract), but recycles instead (see “Recycle Circuit”...
  • Page 123 Î F IGURE 10 (MSSMA401BE) Î W ater Pressure Gauge Î F IGURE 9 (MSSMA401BE) Î A iming the Balancing Nozzles Ë C hecking Water Pressure —Check pressure regulator for 28 PSI (1.96 Kg/sq cm) water pressure when there is no water flow and approximately 10 - 15 PSI (0.70 - 1.05 Kg/sq cm) when water valves are operating.
  • Page 124 DRAINING TO SEWER Cancels step. The water, chemical, and steam valves close, the drain opens (ma- chines with normally open drain valves), and the shellfront tilts to the angle neces- sary for the correct adjustment of the accelerometer. Machines with normally closed drain valves must be drained before continuing (See VIEWING INPUTS/OUTPUTS AND ACTUATING OUTPUTS ON THE MARK III MICROPROCESSOR CON- TROL...).
  • Page 125 The excursion switch actuator must be exactly in the center of the slotted hole - both when the machine is pushed down and when it is hanging free. If not, the switch will actuate prematurely (during the initial excursion at the onset of extraction), causing unnecessary recycles.
  • Page 126 Ê A djustments ® When the machine leaves Milnor , the actuator arm is tie-wrapped to prevent damage (except on 30015, 30020, and 30022 models). This tie wrap must be removed after the machine is set into position but before the machine is op- erated.
  • Page 127 that it has reset. In the released position the arm should rest lightly but definitely against the stop on the micro-switch case that prevents any further arm movement to the left. For machines with rigid mounted shells, where the machine is bolted to a very substantial foundation, very little machine movement will occur for a given degree of out-of-balance.
  • Page 128 ® All limit switches were properly set at the Milnor factory and do not normally require adjustment when the machine is installed. However, the up limit switch(es) should be adjusted if the tilt limits vary from those called for herein, especially if the hydraulic cylinders bottom out.
  • Page 129 Ê U p Limit Switch Adjustment (Front and Rear Same) The proper tilt limits are shown in FIGURES 2, 3, and 4. Measurements are taken from the base vertically to the center of the appropriate tilt wheel. Machine tilted forward Machine tilted rearward (applies to tilt forward (applies only to tilt both...
  • Page 130 Front up limit switch (rearward tilt) Mounting bracket Hydraulic cylinder depresses Mounting bracket switches Rear up limit switch (forward tilting) Î F IGURE 3 (MSSMA415AE) Î U p Limit Switches (52" machine in down position) 5. Reset the up limit switch mounting bracket, such that the switch is depressed by the actuating device just enough to make the switch actuate and no more (listen for the click).
  • Page 131 Ê D own Limit Switch Adjustment (Front and Rear Same) To adjust any down limit switch, see FIGURE 4 and proceed as follows: 1. Place the machine in the down position. 2. With the machine fully seated in the cradle, de-energize the machine. 3.
  • Page 133 Limit Switch Pivot Plate Mounting BMP820051R/82212A (Sheet 1 of 1) Assembly Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Limit Switch Pivot Plate Mounting Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...

  • Page 135: Vibration Switch Assembly

    Vibration Switch Assembly BMP700613R/83211A (Sheet 1 of 1) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Vibration Switch Assy. Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 137 Section Chemical Supply Devices...
  • Page 138 APPLICABILITY: All Washer-Extractor Models Ê G ENERAL Pellerin Milnor Corporation does not guarantee machines against damage from corrosion caused by improper installation and/or operation of pumped-type liquid supply systems. The following precautions must be observed when pumps are used: Always install the pumping unit lower than the dis-...

  • Page 139: Rules For The Field Installation Of Pumped-Type

    RULES FOR THE FIELD INSTALLATION OF PUMPED-TYPE LIQUID SUPPLY SYSTEMS MSSM0213AE/89457V (2 of 2) of the tube after the pump stops will be diluted by the water remaining in the cup. Never inject any concentrated chemical directly onto any metal, rubber, or plastic surface of the machine other than the plastic cups provided.
  • Page 141 BMP700940/97287V (Sheet 2 of 2) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Supply Injector Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 143 Section Water and Steam Piping Assemblies...

  • Page 146: Water Level Float Chamber Assembly

    WATER LEVEL FLOAT CHAMBER BMP810111R/89256A ASSEMBLY (Sheet 1 of 2) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—WATER LEVEL FLOAT CHAMBER Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 147 BMP810111R/89256A (Sheet 2 of 2) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List, cont.—WATER LEVEL FLOAT CHAMBER Description Item Part Number Comments Used In 5N0K04AG42 NPT NIPPLE 1/2X4 TBE GALSTL SK40 COOLDOWN OPT.
  • Page 151 BMP920005/96067V (Sheet 3 of 3) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List, cont.—Universal Actuators & Mounting Hardware for Watts Ball Valves Description Item Part Number Comments Used In 15G126...
  • Page 157 Section Pneumatic Piping and Assemblies...

  • Page 162: Pressure Regulators

    BMP900031/96081V (Sheet 2 of 2) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Pressure Regulators Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...

  • Page 164: Quick Exhaust Valves

    BMP701406/98296V (Sheet 2 of 2) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Quick Exhaust Valves Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 165 S ERVICING AIR CYLINDERS ® This is the general procedure for rebuilding an air cylinder using a Milnor furnished repair kit, once the air cylinder has been removed from the machine. See the specific air cylinder and major assembly parts drawing(s) for component identification and removal/replacement information.
  • Page 166 4. Loosen nuts on threaded rods evenly, permitting cylinder heads to separate. Use only a few turns on one nut before moving to the other one. Continue until springs have no tension. Î F IGURE 2 Î F IGURE 3 (MSSM0130AE) (MSSM0130AE) Î...

  • Page 169: Air Cylinder Assemblies

    BMP830078/2000133V (Sheet 3 of 3) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List, cont.—Air Cylinder Assemblies Description Item Part Number Comments Used In 20L601D ID TAG NAT'L #1614 ALUM EMB LET "D"...
  • Page 173 Air Valves & Mounting Hardware BMP780087R/83457A (Sheet 1 of 2) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Air Valves & Mounting Hardware Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 174 BMP780087R/83457A (Sheet 2 of 2) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List, cont.—Air Valves & Mounting Hardware Description Item Part Number Comments Used In 96V350 1/4" VALVEBODY ASCO #UFTX8320A89 03 01523 85096C BRKT=LOCK AIR VALVE...
  • Page 176 P/L UNIVERSAL AIRVALVE BOX BMP780088R/93046N (Sheet 1 of 2) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—P/L UNIVERSAL AIRVALVE BOX Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 177 BMP780088R/93046N (Sheet 2 of 2) Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List, cont.—P/L UNIVERSAL AIRVALVE BOX Description Item Part Number Comments Used In 96J019E 1/4"PRESSREG2-50PSI #R07-200-RNEA 30N095 03Z PRESSGAUGE 1/8"BACKCONN 0-15PS1 5N0E03KBE2 NPT NIPPLE 1/4X3.5 TBE BRASS 125#...

  • Page 179: Air Cushion Installation

    AIR CUSHION INSTALLATION BMP750049R/89086A (Sheet 1 of 1) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—AIR CUSHION INSTALLATION Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
  • Page 181 Section Hydraulic Schematics and Devices...
