Page 2
“Troubleshooting” chapter or section. See the table of contents. Trademarks of Pellerin Milnor Corporation The following, some of which may be used in this manual, are trademarks of Pellerin Milnor Corporation: ®...
How to Order Parts BMP720097R/72332A Installation and Service Safety for Suspended Washer-Extractors and Centrifugal Extractors MSINA405AE/9909AV About the Forces Transmitted by Milnor Washer-Extractors MSIN0210AE/9330AV Glossary of Tag Illustrations - Q-Style Washer-Extractors MSIUUQTGAE/9449CV Section 1: Service and Maintenance Preventive Maintenance for the 30022 Suspended...
—This instruction manual is intended to provide preventive maintenance procedures, service proce- ® dures and mechanical parts identification for all Milnor 30022Fxx suspended washer-extractors. Measurements are in common US and metric units unless otherwise noted. Always use new fasteners when replacing or repair- ing parts.
(including purchased components) without obligation to change any equipment previously supplied. ANY SALE OR FURNISHING OF ANY EQUIPMENT BY MILNOR IS MADE ONLY UPON THE EXPRESS UNDERSTANDING THAT MILNOR MAKES NO EXPRESSED OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR USE OR PURPOSE.
How to order repair parts Repair parts may be ordered either from the authorized dealer who sold you this machine, or directly from the MILNOR factory. In most cases, your dealer will have these parts in stock. When ordering parts, please be sure to give us the following information: 1.
(owner/user) is responsible for understanding and ensuring the proper operation and maintenance of the machine. The owner/user must familiarize himself with the contents of all machine instruc- ® tion manuals. The owner/user should direct any questions about these instructions to a Milnor dealer or the Mil- ®...
Page 11
Ê H azards During Installation ELECTROCUTION HAZARD—Contact with high voltages can kill or seriously injure you. All electrical connections must be made by a competent electrician. EQUIPMENT DAMAGE HAZARD—Machine can be damaged if shipping re- straints are improperly utilized. These include various bolts, brackets, and safety stands (painted red), brake blocks and the vibration safety switch (tie wrapped).
Page 12
MULTIPLE HAZARDS—Failure to maintain machine in proper working order can result in fatal or serious injury to operators and/or damage to property. DO NOT permit operation under any of the following circumstances: Malfunctioning door interlock mechanism. Malfunctioning limit switches. Malfunctioning two hand inching. Any evidence of cylinder damage.
Page 13
Ê A dditional Hazards During Tilting Machine Maintenance CRUSH/SEVER HAZARD—Tilting mechanisms can crush or sever parts of your body caught in them. Install the safety stands before performing maintenance under a tilted ma- chine. NEVER test or operate (manually or automatically) any machine function with any portion of a person’s body under the tilted machine—even if the safety stands are installed.
Estimates of the maxi- ® mum force normally encountered are available for each Milnor model and size upon request. Floor or foundation ®...
Page 16
® dation poured integrally with the slab. Current machine data is available from Milnor upon request. All data is subject to change without notice and may have changed since last printed. It is the sole responsibility of every ®...
Page 17
<B8DD@C604(##(2E Illustration Explanation Stop! Read the manual first for complete instructions before continuing. Do not jack the machine here. Do not lift the machine here. Use three point or four point lifting as determined by the lifting eyes furnished. Rig the load using lifting cables of sufficient size and length to ensure cables are not over-stressed.
Page 18
Illustration Explanation Do not start this machine until the packing materials, lifting brackets, etc. with this tag attached or behind this panel are removed. These materials are painted red. Safety stands or brackets (also painted red) may be provided with this machine. Do not discard safety stands or brackets Do not step or stand on this machine part.
Page 19
7\_ccQbi _V DQW 9\\ecdbQdY_^c± ACdi\U GQcXUb5hdbQSd_bc This is the hot water inlet. Do not start this machine until the part with this tag is installed on the machine. Do not remove this component from the machine. Install the appropriate part here before operating the machine.
Page 20
=C9EEAD715)$$)3F " " Do not pump grease here. During drain and extract, the cylinder must rotate counterclockwise when viewed from here. During drain and extract, the cylinder must rotate clockwise when viewed from here. & Do not strike shell front of washer-extractors during fork lifting.
È P REVENTIVE MAINTENANCE FOR THE 30022 SUSPENDED WASHER-EXTRACTOR ® As required by the warranty and to achieve optimum performance and service life from Milnor washer- extractors, the schedules, instructions, and precautions herein must be strictly followed. Ê M ain Bearing Housing Preventive Maintenance ENTANGLE AND CRUSH HAZARD—Belts and pulleys can entangle and crush...
Page 23
Ï P reventive Maintenance Schedule Component Action Frequency: Specifications Monthly (See NOTE) Every four months = F Annually = A Additional Information Main bearing Change lubricant, 22 US ounces FIGURE 1 (Item 2) Shell Morlina housing (0.65 liter). ISO 220 (SAE 50) or equivalent Water seals Slowly grease at one location until...
Page 25
Check belt tension (see FIGURE 8) when replacing and adjusting drive train components. A belt tension testing tool ® (Milnor part number 30T001), straight edge, and Belt Ten- sion Specification table is required when setting belt tension. Check tension for new belts according to the following schedule.
Page 26
Ë A bout Belts —All V-belts are not alike. So called “Super” or “High Capacity” belts frequently have consider- ably higher capacities than “Standard” belts. Sometimes a particular manufacturer’s V-belt will be more suitable for a certain application, and another manufacturer’s V-belt may be suitable for a different application. This may occur in spite of the fact that both manufacturer’s V-belts are reputedly “interchangeable”.
Lock OFF and tag out power at the wall disconnect before servicing. Maintenance must be performed only by qualified, authorized service personnel. ® NOTE: A cylinder puller kit (P/N PK33-008) is available from Milnor on a rental basis. Maintenance procedures require: •...
Page 28
Ê R eplacing Seals, Bearings, and Bearing Housing Front shaft Bearings seal holder NOTE: See FIGURE 1 during the following procedures. Shims Ë R eplacing Seals —If no water or metal par- Seals ticles are present in drained oil, replace seals and O-rings as follows.
Page 29
Bolts can break off and the seal holder can leak or loosen. Follow seal holder installation instructions carefully. Nylon insert Do not over tighten bolts. NOTE: The two 3/8" socket cap bolts are drilled to facilitate greasing the water seals (see BMP980022, FIGURE 2, and FIGURE 4). Drilled to allow greasing Initally, grade 8 hex head bolts are used to seat the seal holder, clamp- of water seals...
Page 30
5. Center the shaft within the housing, then gently tap in the front bearing cup. Install the front shaft seal holder. 6. The shaft should turn in the housing. Ë S etting Bearing Clearances NOTE: This procedure is required only if a major bearing housing component is replaced. See “Replacing Bearings”...
Page 31
Ê R einstalling the Cylinder and Shell Front 1. Screw two new allen screws into the puller mounting holes. 2. Determine that the main shaft is clean and free from any foreign materials and that the main shaft key is prop- erly seated on the shaft.
The specifications in this section apply to 1/4 inch and larger Unified National fine and coarse fasteners used on ® Milnor machines. This information is to be used only when torque specifications are not stated in the installation or service instructions.
Page 34
MSSM0101CE/9906AV (2 of 19) Ê A pplying Threadlocker NOTE: The following threadlocker information and ® illustrations are excerpts from the Loctite User’s Guide and are used with permission. For maximum strength, threadlocker must fill the thread voids completely, as shown in FIGURE 2. Organic or petro- leum solvent will remove excess uncured adhesive from joints.
Page 35
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (3 of 19) Ë R emoving Fasteners ® High strength threadlockers like Loctite 271 (or equivalent) may be weakened by heating to at least 500 F (260 C) as follows. 1. Apply localized heat to fastener as shown in FIGURE 5. 2.
Page 36
MSSM0101CE/9906AV (4 of 19) Ï A ll values in foot pounds and (Newton meters) Nomi- Grade Designation Zinc or If instructions call for : nal bolt and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare size Plated 222 or 1/4 - 28 SAE Grade 1 ASTM A307 (3.80)
Page 37
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (5 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc If instructions call for : bolt size and Standard orCadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 5/16 - 24 SAE Grade 1 10.4 ASTM A307...
Page 38
MSSM0101CE/9906AV (6 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for : bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 3/8 - 24 SAE Grade 1 10.2 12.2...
Page 39
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (7 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Zinc or If instructions call for : bolt size Designation and Cadmium Loctite Loctite Loctite Loctite Loctite Bare Standard Plated 222 or 7/16 - 20 SAE Grade 1 16.0 19.2...
Page 40
MSSM0101CE/9906AV (8 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Standard and Zinc or If instructions call for : bolt size Grade Designation Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 1/2 - 20 SAE Grade 1 24.8 29.8...
Page 41
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (9 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for: bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 9/16 - 18 SAE Grade 1 35.3 42.4...
Page 42
MSSM0101CE/9906AV (10 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for: bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 5/8 - 18 SAE Grade 1 49.5 59.4...
Page 43
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (11 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for: bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 3/4 - 16 SAE Grade 1 86.5...
Page 44
MSSM0101CE/9906AV (12 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for: bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 7/8 - 14 SAE Grade 1 137.8 165.4...
Page 45
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (13 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Zinc or If instructions call for : bolt size Designation and Cadmium Loctite Loctite Loctite Loctite Loctite Bare Standard Plated 222 or 1 - 12 SAE Grade 1 205.3...
Page 46
MSSM0101CE/9906AV (14 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for : bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 1-1/8 • 7 SAE Grade 1 265.8 318.9 354.4...
Page 47
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (15 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Zinc or If instructions call for : bolt size Designation and Cadmium Loctite Loctite Loctite Loctite Loctite Bare Standard Plated 222 or 1-1/4 •...
Page 48
MSSM0101CE/9906AV (16 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Designation Zinc or If instructions call for : bolt size and Standard Cadmium Loctite Loctite Loctite Loctite Loctite Bare Plated 222 or 1-3/8 • 6 SAE Grade 1 491.1 589.4 654.8...
Page 49
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (17 of 19) Ï A ll values in foot pounds and (Newton meters) Nominal Grade Zinc or If instructions call for : bolt size Designation and Cadmium Loctite Loctite Loctite Loctite Loctite Bare Standard Plated 222 or 1-1/2 •...
Page 50
MSSM0101CE/9906AV (18 of 19) Ï O ther Fastener Torque Specifications Ï A ll values in foot-pounds and (Newton-meters) Nominal bolt size 18 - 8 Brass Aluminum Stainless Steel Stainless Steel 2024 - T4 1/4 - 20 6.3 (8.54) 6.6 (8.95) 5.1 (6.91) 3.8 (5.15) 1/4 - 28...
Page 51
FASTENER TORQUE REQUIREMENTS MSSM0101CE/9906AV (19 of 19) Ï O ther Fastener Torque Specifications Ï A ll values in foot-pounds and (Newton-meters) Nominal bolt size 18 - 8 Brass Aluminum Stainless Steel Stainless Steel 2024 - T4 7/8 - 9 194.0 (263.03) 202.5 (274.55) 158.8 (215.30) 124.6 (168.93)
Page 90
BMP900031/96081V (Sheet 2 of 2) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Pressure Regulators Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
Page 95
BMP940037/98183V (Sheet 2 of 2) Pellerin Milnor Corporation Pellerin Milnor Corporation Litho in U.S.A. P. O. Box 400, Kenner, LA 70063-0400 Parts List—Dry Soap Chute Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In"...
