- Page 1 PrintServer 32 Printer Optional Large Capacity Input Tray Operator’s Guide This is a new manual. Revision/Update Information: Order Number: EK–PSLCO–OC. A01 Digital Equipment Corporation Maynard, Massachusetts...
- Page 2 First Printing, March 1994 Digital Equipment Corporation makes no representations that the use of its products in the manner described in this publication will not infringe on existing or future patent rights, nor do the descriptions contained in this publication imply the granting of licenses to make, use, or sell equipment or software in accordance with the description.
-
Page 3: Table Of Contents
Contents 1 Using the Optional Large Capacity Input Tray Supported Paper Sizes ........1–1 Adding Paper . -
Page 5: Using The Optional Large Capacity Input Tray
Using the Optional Large Capacity Input Tray This book describes the following operator functions for the PrintServer 32 Printer Optional Large Capacity Input Tray (OLCIT). Adding paper (capacity 3000 sheets of 20 lb paper) • • Clearing paper jams • Troubleshooting Refer to the PrintServer 32 Printer Operator’s Guide for information on using the PrintServer 32 printer. -
Page 6: Parts Of The Olcit
Using the Optional Large Capacity Input Tray 1.1 Supported Paper Sizes Parts of the OLCIT The following illustration and table describe the parts of the OLCIT. Figure 1–1 Parts of the OLCIT ADJUST AT 3 PLACES Paper Mis-set Cover Open DSG-000495 Number Description... -
Page 7: Adding Paper
Using the Optional Large Capacity Input Tray 1.2 Adding Paper 1.2 Adding Paper This section explains how to add paper to the OLCIT. Note When adding paper, make sure the PrintServer is not in the process of printing and the operator panel reads Ready. 1. - Page 8 Using the Optional Large Capacity Input Tray 1.2 Adding Paper 2. Press the Tray Down button on the OLCIT. Be sure the paper tray has stopped before continuing with the procedure. ADJUST AT 3 PLACES Paper Mis-set Cover Open DSG-000496 Note If the tray runs out of paper while printing, the tray automatically lowers.
- Page 9 Using the Optional Large Capacity Input Tray 1.2 Adding Paper 3. Open the OLCIT door £ Remove the two smaller paper trays above the OLCIT. This makes for easy loading of paper and reduces the likelihood of paper jams. DSG-000500 4.
- Page 10 Using the Optional Large Capacity Input Tray 1.2 Adding Paper Note Sloppy paper loading or folded/damaged paper edges and corners can cause printer paper jams. • Use recommended paper only, as listed in the PrintServer 32 Printer Operator’s Guide. • Do not add more than six reams of paper to the paper tray.
- Page 11 Using the Optional Large Capacity Input Tray 1.2 Adding Paper 6. Make sure the two paper adjustment levers and the paper selection knob ¢ are set to the identical setting for the paper size you just loaded. ¡ ADJUST AT 3 PLACES Paper Mis-set Cover...
-
Page 12: Clearing Paper Jams
Using the Optional Large Capacity Input Tray 1.3 Clearing Paper Jams 1.3 Clearing Paper Jams This section explains how to clear paper jams from the OLCIT. 1. Press on the PrintServer 32 operator panel. Pause 2. Press the Tray Down button on the OLCIT. - Page 13 Using the Optional Large Capacity Input Tray 1.3 Clearing Paper Jams 3. Open the OLCIT door £ DSG-000500 4. Remove all jammed paper from the PrintServer and the PrintServer’s cavity. DSG-000501 Using the Optional Large Capacity Input Tray 1–9...
- Page 14 Using the Optional Large Capacity Input Tray 1.3 Clearing Paper Jams 5. Close the OLCIT door £ DSG-000497 Note The elevator moves the paper stack to the top of the OLCIT automatically. 6. Press on the PrintServer 32 operator panel. Resume 1–10 Using the Optional Large Capacity Input Tray...
-
Page 15: Troubleshooting
Using the Optional Large Capacity Input Tray 1.4 Troubleshooting 1.4 Troubleshooting Note If the paper selection knob and the paper adjustment levers are not set to the paper size loaded in the OLCIT, paper jams will occur. Table 1–2 shows the LEDs and what to do to correct the situations listed. Table 1–2 OLCIT LEDs This LED . -
Page 16: Service Notes
Using the Optional Large Capacity Input Tray 1.5 Service Notes 1.5 Service Notes The OLCIT is similar in operation and service to the 1000 sheet LCIT. The OLCIT has an internal controller that operates the elevator tray motor and signals the PrintServer duplexer-table controller. The 1000 sheet LCIT has no internal controller and its motor and other functions are controlled directly by the duplexer-table controller. -
Page 17: Technical Support
Fax: (809) 749-8377 3 Digital Plaza, 1st Street Suite 200 Metro Office Park San Juan, Puerto Rico 00920 Canada Phone: 800-267-6215 Digital Equipment of Canada Ltd. Fax: (613) 592-1946 100 Herzberg Road Kanata, Ontario, Canada K2K 2A6 Attn: DECdirect Sales International —————... - Page 19 Reader’s Comments PrintServer 32 Printer Optional Large Capacity Input Tray Operator’s Guide EK–PSLCO–OC. A01 Your comments and suggestions help us improve the quality of our publications. Thank you for your assistance. I rate this manual’s: Excellent Good Fair Poor Accuracy (product works as manual says) Completeness (enough information) Clarity (easy to understand) Organization (structure of subject matter)
- Page 20 United States BUSINESS REPLY MAIL FIRST CLASS PERMIT NO. 33 MAYNARD MASS. POSTAGE WILL BE PAID BY ADDRESSEE DIGITAL EQUIPMENT CORPORATION Information Design and Consulting MRO1–2/L12 2 RESULTS WAY MARLBORO, MA 01752-9840 Do Not Tear – Fold Here...
