Dexter Laundry OPL Stack Express Owner's Booklet

30 lb (13kg) capacity computer control opl washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
P/N 8514-197-001PR
DEXTER
LAUNDRY,
INC.
WARNING - THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE
OPERATION. TO AVOID INJURY OR ELECTRICAL SHOCK, DO NOT PERFORM ANY SERVICING
UNLESS QUALIFIED TO DO SO.
IT IS THE RESPONSIBILITY OF THE OWNER TO CHECK THIS EQUIPMENT ON A FREQUENT
BASIS TO ASSURE ITS SAFE OPERATION.
A machine should not be allowed to operate if any of the following occur:
- Excessively high water level.
- If machine is not connected to a properly grounded circuit.
- If the door does not remain securely locked during the entire cycle.
- Vibration or shaking from an inadequate mounting or foundation.
1. Always shut off power and water supply before servicing.
2. Do not overload the washer.
3. Do not open door when cylinder is in motion or it contains water.
4. Do not bypass any safety devices of this washer.
5. Do not use volatile or flammable substances in or near this washer.
6. Keep all panels in place. They protect against shock and injury and add rigidity to the washer.
DAILY
- Check that the loading door remains securely locked and cannot be opened during the entire cycle.
- Check the water connections for leaks.
- Clean the top and sides of the cabinet to remove residue.
- Clean the soap dispenser and lid and check that all dispenser mounting screws are in-place and tight.
- Check the drain valve for leaking and that it opens properly.
- Check the loading door for leaks. Clean the door seal of all foreign matter.
- Leave the loading door open to aerate the washer when not in use.
QUARTERLY
- Make sure the washer is inoperative by switching off the main power supply.
- Check the V-belts for wear and proper tension.
- Clean lint and other foreign matter from around motor.
- Check all water connections for leaks.
- Wipe and clean the inside of the washer and check that all electrical components are free of moisture and dust.
- Remove and clean water inlet hose filters. Replace if necessary.
- Check anchor bolts - retighten if necessary
IMPORTANT: Replace any and all panels that were removed to perform daily and/or quarterly maintenance.
OWNER'S BOOKLET
INSTALLATION & OPERATION
INSTRUCTIONS
Please read this information and retain for reference.
WARNING - FOR SAFETY
PREVENTIVE MAINTENANCE REQUIREMENTS
STACK EXPRESS
30 LB (13kg) CAPACITY
COMPUTER CONTROL
OPL WASHER

Advertisement

Table of Contents
loading

Related Manuals for Dexter Laundry OPL Stack Express

Summary of Contents for Dexter Laundry OPL Stack Express

  • Page 1 P/N 8514-197-001PR STACK EXPRESS 30 LB (13kg) CAPACITY COMPUTER CONTROL OPL WASHER DEXTER LAUNDRY, INC. OWNER'S BOOKLET INSTALLATION & OPERATION INSTRUCTIONS Please read this information and retain for reference. WARNING - THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE OPERATION.
  • Page 2 MODE LIGHTS FLUSH WASH RINSE FINAL SPIN WASH CYCLE WASH RINSE WASHER INSTRUCTIONS DISPENSER Load clothes, latch door securely. Add fabric Put detergent and fabric softener, softener. if required, into dispenser on front Bleach (Optional) of machine (see diagram at right). 3 Select desired wash CYCLE with buttons.

  • Page 3: Installation Instructions

    30 LB STACK EXPRESS WASHER/DRYER DEXTER LAUNDRY, INC. INSTALLATION INSTRUCTIONS This washer may have been purchased as part of a stacked washer/dryer. In addition to thesr instructions, please also refer to the installation instructions that accompany the dryer when installing this product. All washers must be installed in accordance with all local, state and national building, electrical, plumbing and other codes in effect in the area.
  • Page 4 PLUMBING...
  • Page 5 Water supply hoses are furnished with each machine. Separate hot and cold water lines must be provided, maintaining 30 P.S.I . (207 kPa) to 120 P.S.I. (827 kPa) water flow pressure. A 140F (60C) degree hot water supply is recommended for best washing results. DRAIN The drain outlet tube at the rear of the machine is 3 inches (76 mm) in diameter.
  • Page 6 The washer control may be programmed to send 120V (60Hz) or 24V (50 Hz) output signals for a chemical injection system. The signals are not intended as a power source and must be limited to less than 100 milliamps of current. There is a separate terminal block for connection of the external injection signals.

  • Page 7: Drain Valve

    SPECIFICATONS MODEL STACK WASHER/DRYER 30LB EXPRESS WASHER CAPACITY 30LBS/4 CUBIC FT. (13.6 kg/113 L) CYLINDER SIZE 25” DIA X 14 1/8” DEEP (63.5cm X 36cm) ELECTRICAL 208-240 VAC, 60 HZ, 1 OR 3 PHASE OR 208-240 VAC, 50HZ, 1 PHASE DRIVE SYSTEM SOFT START REVERSING INVERTER DRIVE, 2 HP MOTOR WASH SPEED...

  • Page 8: Starting The Washer

    STARTING THE WASHER A. Load the clothes into the cylinder and latch the door securely. Be sure clothing does not get caught between the door gasket and tub front when closing the door. Maximum load is 30 pounds (13.6kg) clothes, dry weight. Do not load the washer with more than 30 lbs. (13.6kg).

  • Page 9: Programming Instructions

    PROGRAMMING INSTRUCTIONS: Programming can be accomplished manually using the machine controls or by connecting to the machine control using a PDA (personal digital assistant). For instructions on using a PDA with this washer control, please contact your local Dexter distributor. Please read below for manual programming instructions.
  • Page 10 Ct ** Tumble Time Two-digit amount of time in minutes. Water Temperature HH for hot, CH for warm, CC for cold and EE for no water. L ** Water Level Lo for low, Hl for high. dF * Type of Fill d for delayed fill, t for timed fill.
  • Page 11 Cycle 1 Sheets & Pillowcases (Health Care) Bath Bath Cycle Water Water Delay Spin Injection Source Time Temp. Level Fill Time (min.) (min.) Flush Prewash Wash 1 (Detergent) Rinse 1 2 (Bleach) Rinse 2 Rinse 3 Rinse 4 Final 4 (Sour/Soft) Rinse Cycle 2 Towels / Pads / Diapers (Health Care)
  • Page 12 Cycle 3 White Towels (Hotel / Motel) Bath Bath Cycle Water Water Delay Spin Injection Source Time Temp. Level Fill Time (min.) (min.) Flush Prewash Wash 1 (Detergent) Rinse 1 Rinse 2 2 (Bleach) Rinse 3 Rinse 4 Final 4 (Sour/Soft) Rinse Cycle 4 Guest Laundry (Hotel / Motel or Health Care)
  • Page 13 Cycle 5 Rags & Mops (Hotel / Motel) Bath Bath Cycle Water Water Delay Spin Injection Source Time Temp. Level Fill Time (min.) (min.) Flush Prewash Wash Rinse 1 1 (Detergent) Rinse 2 Rinse 3 2 (Bleach) Rinse 4 Final Rinse Cycle 6 Colored Cotton Linen (Food &...

  • Page 14: Rapid Advance Mode

    RAPID ADVANCE MODE To enter the Rapid Advance mode, turn the key counter-clockwise (CCW). The Rapid Advance setting is not marked next to the key, but turning the key CCW until it stops selects this mode. The Rapid Advance mode can be entered from either the Idle mode or during the cycle. If the cycle has not yet started, press the “START”...
  • Page 15 WASHER ERROR CODES Fault # Description Customer Action (F #) The door failed to close and lock or the door Turn off the power to the washer. Check wire connections to door /lock switches. Check wire failed to remain locked after three tries of connections from switches to controller.
  • Page 16 The drive size setting has changed. Turn off the power to the washer. Check to ensure all the harnesses are properly connected to the controller. Check to ensure the drive horsepower is proper for this size of washer. Turn on power to the washer. (See Note) If problem reappears, contact your Dexter representative.
  • Page 17 QTY. 9990-027-011 Hose, Water Supply 8641-242-000 Washer, Inlet Hose 9565-003-001 Strainer, Inlet Hose Contact your distributor or Dexter Laundry, Inc. if a steel-mounting base is required. © 2010, Dexter Laundry, Inc. 2211 West Grimes, Fairfield, IA 52556 U.S.A. 1-800-524-2954 www.dexterlaundry.com...
