Setup Guide
For your own safety,
Please read carefully.
Compact Speaker System for iPod
Thank you for purchasing the TDK Life on Record iCUBIC speaker.
• Please read the "Setup Guide" and "Safety and Care Instructions"
carefully and thoroughly before connecting or operating this product for
optimum performance and safety.
• After reading, store the manual in a convenient place for future reference.
iCUBIC
Product name: ADS-01

Advertisement

Table of Contents
loading

Summary of Contents for TDK iCUBIC

  • Page 1 Imation Asia Paci c Pte Ltd. Thank you for purchasing the TDK Life on Record iCUBIC speaker. * The TDK Life on Record logo is a trademark of TDK Corporation and 23, New Industrial Road, is used under a trademark license from TDK Corporation.

  • Page 2: Safety And Care Instructions

    Safety and Care Instructions Do not use the equipment other than with 240 volts AC. (Be sure to read before using this product) 240V AC Using the equipment with different voltages abroad could cause fire or electrical shock. Enforced • The cautions listed here include important matters to prevent injury to users or other persons as well Fire as any property damage, in addition to insuring correct and safe use of the product.

  • Page 3: Placement Of The System

    Operating Instructions for Optimum Safety Cautions Regarding Batteries Performance and Safety Do not touch the fluid with your bare hands if fluid has leaked from the battery. Warning Battery fluid in the eyes can cause blindness or injury. Fluid on body parts or clothing can cause injury or skin inflammations.

  • Page 4: What's In The Package

    What’s in the Package? TDK Life on Record Compact Speaker System for iPod Dual alarm and snooze function which plays your iPod or favourite FM Main unit x 1 station when activated. Power adapter x 1 Recharges iPod battery while connected.

  • Page 5: Parts Names

    Parts Names Main unit LCD display window iCUBIC iPod dock Stereo indicator Clock button Play/pause button Sleep button Memory button Function button Skip/tuner up button Standby indicator Volume up button Skip/tuner down button Track/number/time indicator Volume down button Snooze button...

  • Page 6: Preparing To Use

    Preparing to Use Setting a dock adapter Power cord connection Before using, connect the DC power cord to the DC outlet. 1. Use in C-display 2. Use in iPod -40GB 3. Use in iPod-Video 4. Use in iPod-20GB -40GB/60GB-iPod -60GB 5.

  • Page 7: Operating The Unit

    Operating the Unit iPod Operation When you first plug the unit into the AC outlet, the unit will be in standby mode. You can press the During standby mode standby button on the unit (or on the remote control) to switch the unit ON or OFF. Pull the AC plug out of the wall socket if you want to switch off completely.

  • Page 8: Radio Operation

    Radio Operation AUX Input • Press the function button to select the tuner mode on the unit (or remote control) to select the radio The AUX input is located at the rear of the unit. Use a 3.5 mm stereo jack cable to connect audio FM operation.

  • Page 9: Troubleshooting

    Alarm Clock Operation Troubleshooting During the unit in standby mode. Symptom Possible Cause Remedy To set the correct “Alarm 1” • Press the “Alarm 1” button once on the remote control only. The “AL 1 bell symbol” indicator will light on and the “Hour”...

  • Page 10: Main Specifications

    Main Specifications Main unit Power supply: AC/DC adaptor input 230V-50Hz output DC 12V 1.0A Output power: Unit dimensions: 135 x 143.7 x 135 (width/height/depth) Weight: 1.25kg Radio section Frequency range: FM 87.5 - 108 MHz ∗The specifications and appearance of this product are subject to change for improvement without prior notice.
