INSTRUCTION MANUAL

(SETUP INSTRUCTIONS)

H.264 NETWORK ENCODER
MODEL
IEN-10
H . 2 6 4 N
e t w o r k
E n c o d e
P S
r
E
S D C A R
D
OUTDOOR USE WARNING
WARNING — TO PREVENT FIRE OR
ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
Ikegami Tsushinki Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IEN-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ikegami IEN-10

Summary of Contents for Ikegami IEN-10

  • Page 1: Setup Instructions

    E n c o d e S D C A R OUTDOOR USE WARNING WARNING — TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Ikegami Tsushinki Co., Ltd.
  • Page 2 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    Contents Page 1. Introduction ......................1 1-1. Handling precautions ................... 1 1-2. Checking the supplies .................. 2 1-3. License for third party software ..............2 1-4. Distribution of source code of free software ..........3 1-5. Limitations on Equipment Use ..............3 2.

  • Page 4: Introduction

    Accidents or breakdowns due to mistaken usage or negligence. Disassembly or repair of equipment that is not recognized by Ikegami. Improper use by a third party of the surveillance images produced by this equipment, or damages resulting from such use.

  • Page 5: Checking The Supplies

    * SD Card • Please be aware that this company assumes no responsibility regarding guarantees in cases where images were not recorded due to problems with this device or the SD card. • The following cases may involve destruction (loss) of recorded data. Please be aware that this company cannot assume any responsibility regarding damages due to destruction of data.

  • Page 6: Distribution Of Source Code Of Free Software

    1-4. Distribution of source code of free software If you would like to purchase the GPL/LGPL software used in this product, please contact our sales division. In accordance with the licence terms, we will provide this at cost. 1-5. Limitations on Equipment Use This equipment has its usage regulated by the VC-1 and AVC/H.264 Patent Portfolio Licenses Concerning Personal and Non-Commercial Use.

  • Page 7: Outline

    2. Outline This equipment is a PoE-compatible network encoder (box-type) that can compress both image and voice signals from conventional analog surveillance cameras into digital data to be delivered over a network. It uses the state-of-the-art H.264/AVC technology to compress image data for allowing high-quality images to be delivered at a highly efficient rate.

  • Page 8: Names Of Parts And Their Functions

    4. Names of parts and their functions 4-1. Front panel H.264 Network Encoder SD CARD IEN-10 MODEL SD CARD ........Possible to insert an SD card. Also operates with SDHC card. LED displays P (green) ........This LED is lit when the power is ON.

  • Page 9: Rear Panel

    For details, see the Instruction Manual (Application Instructions). IO2 ....Same as IO1. RS-485 ..Communications possible with Ikegami I-LAN compatible equipments. Terminal block 2 ..Input of DC12V or AC24V (normally not in use). Do not simultaneously use the power source in item (AC adapter).

  • Page 10: Attach Rubber Feet

    5. Attach Rubber Feet In accordance with your operating environment, attach rubber feet as shown on the diagram below.

  • Page 11: Setting This Equipment

    6. Setting this equipment PC setting Before installing this equipment, change the settings on this equipment to match the network you are using. The settings on this equipment can be changed by using Internet Explorer on your PC. Before connecting this equipment with your PC, change the PC network settings. (First disconnect from existing network before setting).
  • Page 12 Click on “Network Connections”. Right-click on “Local Area Connection” and click on “Properties”. Getting the “Internet Protocol (TCP/IP)” properties displayed Click on “Internet Protocol (TCP/IP)” first and then on “Properties”.
  • Page 13 • Set the IP address at “192.168.1. ” (not 100 for the blank). • Set the subnet mask at “255.255.255.0”. For reference The initial values of the IP addresses for products operating with the Ikegami network are as follows. Network Camera 192.168.1.100 Network Decoder 192.168.1.150...

  • Page 14: Setting This Equipment

    7. Setting this equipment Turning on the power There is no power switch on this equipment. It is possible to supply power for this equipment with the following three methods: (1) AC adapter, (2) terminal block, (3) PoE. When the power is inserted, the LED display P (green) lights and operation starts after about 40 seconds.

  • Page 15: Supplying Power With Poe

    Power cable Remove about 10 mm from the end of the power cable. The thickness of cables for connection should be AWG24-12. Remove about 10 mm. • Do not use simultaneously with AC adapter. • When supplying AC24V, do not use simultaneously with PoE. •...

  • Page 16: Setting This Equipment

    8. Setting this equipment Connect the equipment to the PC When connecting this equipment to the PC, connect with the LAN cable. IEN-10 H. 26 4 Ne tw ork De co de r SD CA RD Enter this equipment ’s URL in the Internet Explorer address bar.

  • Page 17: Setting This Equipment

    • Easy Setting Tool This is a handy tool for easy changing of the IP address of this equipment and other equipments operating with an Ikegami. It is also possible to change the IP address after installing the equipment. You can download the tool (software) from the below website. Before use, carefully read the...

  • Page 18: Installation Connecting The Lan Cable

    10-1. Installing on the same network This is an example of installing this equipment and the IDE-10 on the same network. Be sure to correctly set the IP address and subnet mask. Camera Example (IEN-10) H.2 64 Ne two rk Enc ode r IP address : 192.168.1.100...

  • Page 19: Installing On Different Networks

    Carry out setting of the router firewall and port forward for communications with these protocols. For details consult the Instruction Manual (Application Instructions) and the manual of the router you are using. Camera Example (IEN-10) H.2 64 Ne two rk Enc ode r IP address : 192.168.1.100...

  • Page 20: Installing In Separate Locations With Use Of Internet And Wan

    Carry out setting of the router firewall and port forward for communications with these protocols. For details consult the Instruction Manual (Application Instructions) and the manual of the router you are using. Example (IEN-10) IP address : 192.168.1.100 Subnet mask : 255.255.255.0...

  • Page 21: Installation Connecting To Video/Audio

    11. Installation Connecting to video/audio 11-1. Connecting to VIDEO IN/LOOP OUT VIDEO IN LOOP OUT OPTION Monitor Camera VIDEO IN loop out Coaxial cable Video Input • Use a coaxial cable. • Set the video format on the format setting screen to match the inputted images. •...

  • Page 22: Installation Connecting To I/O Terminal

    12. Installation Connecting to I/O terminal IO1 and IO2 on the terminal block can be used as connection input terminals or connection output terminals. It is possible to choose input/output for the terminal on the input/output setting screen. For details see the Instruction Manual (Application Manual). Connect the terminals as shown in the figure.

  • Page 23: Installation Connecting To The Rs485 Or Rs-232C

    Twist pair wire RS-485 control • Operate a keyboard (PCS-35KB) etc. connected to the network decoder to operate an Ikegami I-LAN compatible device or camera platform connected to this equipment. • The product can be customized to suit user-specified RS-485-compatible equipment. In this way, a client PC may be used to control the system.

  • Page 24: Troubleshooting

    14. Troubleshooting Before asking for servicing, check the following points. Problem Check points Ref. page No power supplied * Is the power cable plugged in tightly? 6, 11-12 * Is the LAN cable tightly connected with the equipement in the case of PoE power supply? Failure to interact * Is the IP address as specified? 8-10, 15-17...

  • Page 25: Specifications

    15. Specifications (1) Video input: VBS 1.0Vp-p/75Ω unbalanced Incorporating the automatic termination loop through function Compliant with RS-170A (color) or with RS-170 (B/W) (2) Image compression format: H.264 and JPEG (3) Image setting: Setting of 3 patterns possible • Compression format: H.264/JPEG •...
  • Page 26 (19) Input/output connectors: Ethernet : RJ-45 (Auto-MDI/MDIX) VIDEO IN : BNC (automatic termination ) LOOP OUT : BNC (loop through) AUDIO IN : RCA AUDIO OUT : RCA AC24V/DC12V : 2P push-in terminal (common for AC/DC) DC12V : AC adapter jack I/O terminal : 4P push-in terminal (IN/OUT switching: 2)

  • Page 27: Appearance View

    16. Appearance view AUDIO VIDEO IN LOOP OUT OPTION RS485 DC12V AC24V ETHERNET RS-232C(DCE) 50/60Hz DC12V LINK CLASS2...

  • Page 28: Warranty And After-Sales Service

    The Guarantee for this product is attached to this manual. Read the contents carefully and fill in the required items. Keep the Guarantee in a safe place. • Please consult Ikegami Electronics (U.S.A.) Inc. or Ikegami Electronics (Europe) GmbH or your dealer for full warranty information. Your dealer will repair or replace free of charge within the warranty period according to the warranty coverage.
  • Page 30 37 Brook Avenue, Maywood, New Jersey 07607, U.S.A. Phone: (201) 368-9171, FAX 201-569-1626 Ikegami Electronics (Europe) GmbH Ikegami Strasse 1, 41460 Neuss 1, F.R. Germany TEL. 02131-123-0/FAX 02131-102820 Ikegami Electronics (Europe) GmbH U.K. Branch Unit E1 Cologne Court Brooklands Close, Windmill Road Sunbury-on-Thames Middlesex TW16 7EB, UK TEL.
