INSTRUCTION MANUAL
(SETUP INSTRUCTIONS)
H.264 NETWORK DECODER
MODEL
IDE-10
H . 2 6 4 N
e t w o r k
D e c o d
P S
e r
E
S D C A R
D
OUTDOOR USE WARNING
WARNING — TO PREVENT FIRE OR
ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
Ikegami Tsushinki Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDE-10 and is the answer not in the manual?

Questions and answers

Related Manuals for Ikegami IDE-10

Summary of Contents for Ikegami IDE-10

  • Page 1 D e c o d S D C A R OUTDOOR USE WARNING WARNING — TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Ikegami Tsushinki Co., Ltd.
  • Page 2 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    Contents Page 1. Introduction ......................1 1-1. Handling precautions ................... 1 1-2. Checking the supplies .................. 2 1-3. License for third party software ..............2 1-4. Distribution of source code of free software ..........2 1-5. Limitations on Equipment Use ..............3 2.

  • Page 4: Introduction

    Accidents or breakdowns due to mistaken usage or negligence. Disassembly or repair of equipment that is not recognized by Ikegami. Improper use by a third party of the surveillance images produced by this equipment, or damages resulting from such use.

  • Page 5: Checking The Supplies

    1-2. Checking the supplies Quantity * AC adapter ..................1 * Rubber foot ..................4 * Instruction Manual (Setup Instructions) ..........1 1-3. License for third party software We are licensed to use the software made by third parties for this product. The license for each software shall be applicable to the software in question respectively and not to the whole software of this product.

  • Page 6: Limitations On Equipment Use

    1-5. Limitations on Equipment Use This equipment has its usage regulated by the VC-1 and AVC/H.264 Patent Portfolio Licenses Concerning Personal and Non-Commercial Use. This license should be observed in limiting use of this equipment to private use or uses that are non-profit. For details consult the following: Reference: Actions permitted by VC-1 and AVC/H.264 images for private and non-commercial uses.

  • Page 7: Outline

    2. Outline This equipment is a PoE-compatible network decoder (box-type) that decompresses the image and audio signals that have been compressed and delivered on the network by the H.264 network camera or the network encoder for outputting composite video signals to be displayed on conventional surveillance monitors.

  • Page 8: Names Of Parts And Their Functions

    4. Names of parts and their functions 4-1. Front panel H.264 Network Decoder SD CARD IDE-10 MODEL SD CARD ........Possible to insert an SD card. Also operates with SDHC card. LED displays P (green) ........This LED is lit when the power is ON.

  • Page 9: Rear Panel

    For details, see the Instruction Manual (Application Instructions). IO2 ....Same as IO1. RS-485 ..Communications possible with Ikegami I-LAN compatible equipments. Terminal block 2 ..Input of DC12V or AC24V (normally not in use). Do not simultaneously use the power source in item (AC adapter).

  • Page 10: Attach Rubber Feet

    5. Attach Rubber Feet In accordance with your operating environment, attach rubber feet as shown on the diagram below.

  • Page 11: Setting This Equipment

    6. Setting this equipment PC setting Before installing this equipment, change the settings on this equipment to match the network you are using. The settings on this equipment can be changed by using Internet Explorer on your PC. Before connecting this equipment with your PC, change the PC network settings. (First disconnect from existing network before setting).
  • Page 12 Click on “Network Connections”. Right-click on “Local Area Connection” and click on “Properties”. Getting the “Internet Protocol (TCP/IP)” properties displayed Click on “Internet Protocol (TCP/IP)” first and then on “Properties”.
  • Page 13 • Set the IP address at “192.168.1. ” (not 150 for the blank). • Set the subnet mask at “255.255.255.0”. For reference The initial values of the IP addresses for products operating with the Ikegami network are as follows. Network Camera 192.168.1.100 Network Encoder 192.168.1.100...

  • Page 14: Setting This Equipment

    7. Setting this equipment Turning on the power There is no power switch on this equipment. It is possible to supply power for this equipment with the following three methods: (1) AC adapter, (2) terminal block, (3) PoE. When the power is inserted, the LED display P (green) lights and operation starts after about 40 seconds.

  • Page 15: Supplying Power With Poe

    Power cable Remove about 10 mm from the end of the power cable. The thickness of cables for connection should be AWG24-12. Remove about 10 mm. • Do not use simultaneously with AC adapter. • When supplying AC24V, do not use simultaneously with PoE. •...

  • Page 16: Setting This Equipment

    8. Setting this equipment Connect the equipment to the PC When connecting this equipment to the PC, connect with the LAN cable. H. 26 4 Ne tw ork De co de r SD CA RD Enter this equipment ’s URL in the Internet Explorer address bar. The initial setting is “http://192.168.1.150/”.

  • Page 17: Setting This Equipment

    • Easy Setting Tool This is a handy tool for easy changing of the IP address of this equipment and other equipments operating with an Ikegami. It is also possible to change the IP address after installing the equipment. You can download the tool (software) from the below website. Before use, carefully read the...

  • Page 18: Installation Connecting The Lan Cable

    H.2 64 Ne two rk Enc ode r IP address : 192.168.1.100 SD CAR Subnet mask : 255.255.255.0 IEN-10 Example (IDE-10) H.2 64 Ne two rk De IP address : 192.168.1.150 cod er SD CAR Subnet mask : 255.255.255.0 IDE-10...

  • Page 19: Installing On Different Networks

    IP address : 192.168.1.1 Router Subnet mask : 255.255.255.0 LAN2 LAN2 side IP address : 192.168.2.1 Subnet mask : 255.255.255.0 Example (IDE-10) H.2 64 Ne two rk De cod er SD CAR IP address : 192.168.2.150 Subnet mask : 255.255.255.0 IDE-10 Gateway : 192.168.2.1...

  • Page 20: Installing In Separate Locations With Use Of Internet And Wan

    LAN2 H.2 64 Ne two rk De cod er SD CAR IDE-10 Modem, etc. Router Example (Router) Example (IDE-10) LAN2 side IP address : 192.168.1.150 IP address : 192.168.1.1 Subnet mask : 255.255.255.0 Subnet mask : 255.255.255.0 Gateway : 192.168.1.1...

  • Page 21: Installation Connecting To Video/Audio

    11. Installation Connecting to video/audio 11-1. Connecting to VIDEO OUT VIDEO OUT Monitor Coaxial cable Video Output • Use a coaxial cable. • Set the video format on the format setting screen to match the outputted images. • For details see the Instruction Manual (Application Instructions). 11-2.

  • Page 22: Installation Connecting To I/O Terminal

    12. Installation Connecting to I/O terminal IO1 and IO2 on the terminal block can be used as connection input terminals or connection output terminals. It is possible to choose input/output for the terminal on the input/output setting screen. For details see the Instruction Manual (Application Instructions). Connect the terminals as shown in the figure.

  • Page 23: Installation Connecting To The Rs485 Or Rs-232C

    Twist pair wire RS-485 control • Operate a keyboard (PCS-35KB) connected to the network encoder to operate an Ikegami I-LAN compatible equipment or camera platform connected to this equipment. • The product can be customized to suit user-specified RS-485-compatible equipment. In this way, a client PC may be used to control the system.

  • Page 24: Troubleshooting

    14. Troubleshooting Before asking for servicing, check the following points. Problem Check points Ref. page No power supplied * Is the power cable plugged in tightly? 6, 11-12 * Is the LAN cable tightly connected with the equipement in the case of PoE power supply? Failure to interact * Is the IP address as specified? 8-10, 15-17...

  • Page 25: Specifications

    15. Specifications (1) Video output: VBS 1.0Vp-p/75Ω unbalanced (2) Compatible image compression method: H.264 (3) Image setting: To be selected from the settings on the connected camera or encoder (4) Audio : Monaural bidirectional (full duplex) Line input : -10dBV/10kΩ unbalanced Line output : -10dBV/600Ω...

  • Page 26: Appearance View

    16. Appearance view IDE-10 MODEL CARD Decoder Network H.264 VIDEO OUT AUDIO RS485 DC12V ETHERNET AC24V RS-232C(DCE) 50/60Hz DC12V LINK CLASS2...

  • Page 27: Warranty And After-Sales Service

    The Guarantee for this product is attached to this manual. Read the contents carefully and fill in the required items. Keep the Guarantee in a safe place. • Please consult Ikegami Electronics (U.S.A.) Inc. or Ikegami Electronics (Europe) GmbH or your dealer for full warranty information. Your dealer will repair or replace free of charge within the warranty period according to the warranty coverage.
