Ikegami IEN-200HD Specifications

IEN-200HD/IDE-200HD
The IEN-200HD and IDE-200HD are HDTV/SDTV Network Video Encoder and
Decoder and utilize H.264 Video Compression and Analog and Embedded
Audio Compression. The IEN-200HD accepts HD-SDI or SD-SDI Video which
is 1080i(50/59.94), 720p(50/59.94), 480i(59.94) or 575i(50).
Features
IEN-200HD Encoder
HD-SDI or SD-SDI can be detected automatically.
H.264 or JPEG Video Compression.
AAC-LC 64Kbps Audio Compression.
Constant Bit Rate (CBR) or Variable Bit Rate (VBR).
Image Size/Frame Rate/Bit Rate can be optimized.
Privacy Mask Function.
SD Card Access to store the Video.
AC24V/DC12V/PoE Power Requirements.
IDE-200HD Decoder
H/264 Video Compression.
AAC-LC 64Kbps Audio Compression.
AC24V/DC12V/PoE Power Requirements
HDTV/SDTV Network Video Encoder
and Decoder
Appearance
