NetComm LSV40 USB VoIP Phone Quick Start Guide
Introduction:
The NetComm LSV40 USB VoIP Phone is designed for the telecommuter who would
like to make VoIP calls using a PC and an Internet connection. This user guide provides
instructions on how to install the NetComm LSV40 USB phone and start making VoIP
calls in 3 simple steps.
What's in your LSV40 VoIP USB Phone Box:
1. LSV40 USB VoIP Handset.
2. USB Connection Cable.
3. Mini Installation CD.
4. This Quick Start Guide.

Installation and Configuration

Step1: Installing the LSV40 VoIP USB Phone Software
You will need to install the NetComm V40 USB Phone application onto your
Desktop PC or Laptop in order to configure the phone. Follow these steps to
install the software:
1. Ensure your Desktop PC or Laptop is connected to an Internet Connection and
that the connection is active.
2. Test that you can access the Internet (open a website).
3. Do NOT plug your LSV40 phone into a USB port on your PC.
4. Insert the accompanying CD into your PC's CDROM drive:
[screenshot]
5. Click the 'Install NetComm LSV40 USB Phone software' button and follow
the instructions:
[screenshot]
6. You have now finished installing your software and need to complete Step 2,
Installing the LSV40 Hardware.
Step 2: Installing the LSV40 hardware.
1. Locate a free USB port on your Desktop PC or Laptop.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSV40 and is the answer not in the manual?

Questions and answers

Related Manuals for NetComm LSV40

Summary of Contents for NetComm LSV40

  • Page 1: Installation And Configuration

    The NetComm LSV40 USB VoIP Phone is designed for the telecommuter who would like to make VoIP calls using a PC and an Internet connection. This user guide provides instructions on how to install the NetComm LSV40 USB phone and start making VoIP calls in 3 simple steps.
  • Page 2 2. Attach the supplied USB Cable to the USB socket on the bottom of the LSV40 handset. You can connect either end of the cable depending upon your preferences. 3. Attach the other end of the USB cable to the USB port of your Desktop PC or Laptop.
  • Page 3 5. Check that you have successfully registered with your VSP: Refer to Appendix 1 – Troubleshooting if you are unable to see a Logged in status. 6. If you have a Logged in status, you are ready to make a phone call. Getting to Know the LSV40 USB Phone...
  • Page 4 Group 2 Button: Use the Green button on the LSV40 USB phone to accept an incoming call or to dial the outgoing number you have entered. The default setting on the phone is not to dial a number automatically.
  • Page 5 Use the Red ‘C’ button to clear any incorrect numbers you have entered via the keypad before dialling. Call in progress Interface on your PC: Once pressing the green dial button or clicking the Dial button on the LSV40 software interface, you will see the following: Click the hang-up button to release a call, or use the red phone button on the USB phone to end a call.
  • Page 6 Receiving incoming calls Your new VoIP number is displayed on the base of the LSV40 Phone and on the back of the box that it came in. The phone will ring when a VoIP call is made to your number. Simply pick up the phone and press the green phone button to accept and answer the call.

  • Page 7: Appendix 1 - Troubleshooting

    How do I collect my voice mail? Just call 121 using your LSV40 Phone. If you have any new messages, the system will let you know how many messages there are. Follow the voice prompts to listen to your messages.
  • Page 8 2. I cannot login to my VoIP service provider and I see the following window: This indicates that your SIP proxy server you entered under the Gateway Setup window is incorrect. Confirm these settings and try again. 3. I cannot login to my VoIP service provider and I see the following window: This indicates that you are able to connect to your VoIP service provider but your username and password are incorrect.

  • Page 9: Appendix 2 - Advanced Configuration

    Edit the value of EnableBuzzerRing from 1 to 0. Save the changes to this file and close. Restart the LSV40 USB Phone application for the new settings to take effect. Changing the default dial wait period. The USB phone (by default) does not automatically dial the number entered unless you either click the Dial button on the software interface or press the green telephone button on phone.

  • Page 10: Appendix 3: Registering Your Netcomm Product

    (please refer to packaging). To be eligible for the extended warranty you must supply the requested warranty information to NetComm within 30 days of the original purchase by registering on-line via the NetComm web site www.netcomm.com.au...
  • Page 11 Do not use this power supply with any other product or do not use any other power supply that is not approved for use with this product by NetComm. Failure to do so may cause damage to this product, fire or result in personal injury.
  • Page 12 • Payment of the cost of having the Goods repaired. All NetComm ACN 002 490 486 products have a standard 12 months warranty from date of purchase. However some products have an extended warranty option (refer to packaging). To be eligible for the extended warranty you must supply the requested warranty information to NetComm within 30 days of the original purchase by registering on-line via the NetComm web site at www.netcomm.com.au.
