Viper Responder One Installation Manual

Hide thumbs Also See for Responder One:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
Enlarged version
Responder One

Remote Start

Installation Guide

NOTE:
This product is intended for installation by a profes-
sional installer only! Any attempt to install this product by any
person other than a trained professional may result in severe
damage to a vehicle's electrical system and components.
© 2008 Directed Electronics, Vista, CA
N4203V 2008-09

Advertisement

Table of Contents
loading

Related Manuals for Viper Responder One

Summary of Contents for Viper Responder One

  • Page 1: Remote Start

    Responder One Remote Start Installation Guide NOTE: This product is intended for installation by a profes- sional installer only! Any attempt to install this product by any person other than a trained professional may result in severe damage to a vehicle’s electrical system and components.
  • Page 2 Bitwriter®, Code Hopping™, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn Routine™, Nite-Lite®, Nuisance Prevention® Circuitry, Reveng- er®, Silent Mode™, Soft Chirp®, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away® are all Trademarks or Registered Trademarks of Di- rected Electronics. The Bitwriter ®...

  • Page 3: Table Of Contents

    Contents Government Regulations ..................5 Warning! Safety first ..................6 What is included....................8 Installation points to remember................9 Virtual tach ....................10 D2D......................10 Component locations and finding wires .............11 Making your wiring connections ...............11 Primary harness (H1) wiring diagram............12 4-pin satellite harness diagram ..............12 Heavy gauge relay wiring diagram ............12 Door lock harness, 3-pin connector ............13 Remote start harness (H2) wiring diagram ..........13...

  • Page 5: Government Regulations

    Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation.

  • Page 6: Warning! Safety First

    Warning! Safety first The following safety warnings must be observed at all times: performed by an authorized Directed Electronics dealer. When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never operate the system in an area that does not have adequate ventilation.
  • Page 7 After the remote start module has been installed, test the remote start module in accordance with the Safety Check outlined in this installation guide. If the vehicle starts when performing the Neutral Safety Shutdown Circuit test, the remote start unit has not been properly installed. The remote start module must be removed or properly reinstalled so that the vehicle does not start in gear.

  • Page 8: What Is Included

    What is included The control module (see diagram) Responder One transceiver (P/N 6212T) Two, 2-way remotes (P/N 7211V) A push-button programming switch A hood pinswitch A shut-down toggle switch Red 4 pin D2D/Bitwriter port © 2008 Directed Electronics. All rights reserved.

  • Page 9: Installation Points To Remember

    Installation points to remember Important: This product is designed for fuel-injected, automatic transmission vehicles only. Installing it in a standard transmission vehicle is dangerous and is con- trary to its intended use. Before beginning the installation: Please read this entire installation guide before beginning the in- stallation.

  • Page 10: Virtual Tach

    Virtual tach Virtual Tach is a new feature for Directed this year. It is the default RPM-sensing method for new remote start systems. Virtual Tach gives the installer the performance of a hardwired tach wire, with the conve- nience of voltage sensing. It is far superior to any voltage-sense feature you’ve tried before.

  • Page 11: Component Locations And Finding Wires

    Component locations and finding wires For detailed information on where to locate components, and how to find the wires you need, please refer to the Direct Tech web site at www.directechs.com. Making your wiring connections Before making your connections, plan how your wires will be routed through the vehicle.

  • Page 12: Primary Harness (H1) Wiring Diagram

    Primary harness (H1) wiring diagram LIGHT GREEN/ FACTORY ALARM DISARM H1/1 BLACK GREEN/WHITE FACTORY REARM H1/2 YELLOW (+) IGNITION OUT (TO ALARM) H1/3 WHITE/BLUE (-) ACTIVATION INPUT H1/4 ORANGE (-) GROUND WHEN LOCKED* H1/5 BROWN (-) HORN OUTPUT H1/6 RED/WHITE (-) TRUNK RELEASE OUTPUT* H1/7 BLACK...

  • Page 13: Door Lock Harness, 3-Pin Connector

    Door lock harness, 3-pin connector BLUE (-) UNLOCK OUTPUT EMPTY NOT USED GREEN (-) LOCK OUTPUT* *Ignition controlled lock only Remote start harness (H2) wiring diagram BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT H2/1 VIOLET/WHITE TACHOMETER INPUT WIRE H2/2 BROWN (+) BRAKE SWITCH SHUTDOWN WIRE H2/3 GRAY (-) HOOD PINSWITCH SHUTDOWN WIRE...

  • Page 14: Primary Harness (H1), 9-Pin Connector

    Primary harness (H1), 9-pin connector H1/1 LIGHT GREEN/ FACTORY ALARM DISARM BLACK This wire sends a negative pulse every time the remote start is activated or the doors are unlocked. This can be used to pulse the disarm wire of the vehicle’s factory anti-theft device. Use a relay to send a (-) or (+) pulse to the disarm wire as shown in the following diagram Delay for Negative (-) Disarm Wire ©...
  • Page 15 Relay for Positive (+) Disarm Wire GREEN/WHITE FACTORY REARM H1/2 This wire sends a negative pulse every time the remote start shuts down or the doors are locked. This can be used to pulse the arm wire of the vehicle’s factory anti-theft device. Use a relay to send a (-) or (+) pulse to the arm wire.
  • Page 16 H1/4 WHITE/BLUE (-) ACTIVATION INPUT This input comes from the factory set to 1 activation pulse. This means that it is necessary to have 1 ground pulse on the white/blue wire for the remote start to activate or to deactivate manually. The same holds true for the remote control activation when set to a two pulse setting it is necessary to press the button twice for the remote start to activate or deactivate.
  • Page 17 BROWN (-) HORN OUTPUT H1/6 This wire supplies a (-) 200 mA output that can be used to honk the vehicle horn. It outputs a single pulse when locking the doors with the remote, and two pulses when unlocking with the remote. This wire also outputs pulses for 30 seconds when Panic Mode is activated.
  • Page 18 Note: this feature is not available with the 1 button remote. BLACK (-) chassis GROUND connection H1/8 We recommend that you do not use a factory ground. Ground all your components to the same point in the vehicle, (preferably the kick panel).
  • Page 19 Note: For parking light systems that draw 10 amps or more, the jumper must be placed to the (-) light flash output (refer to the Program- ming Jumpers section of this guide. P/N 8617 or a standard automo- tive SPDT relay must be used on the H1/2 light flash output wire. (+) Positive Light Flash Output (-) Light Flash Output ©...

  • Page 20: Heavy Gauge Relay Interface

    Heavy gauge relay interface The heavy gauge wires are used to energize high current circuits in the vehicle. It is crucial that these connections are made correctly so that they are capable of handling the current demands. For this reason, scotch locks, T-taps and other such connectors should not be used.

  • Page 21: Remote Start Harness (H2), 5-Pin Connector

    PINK/WHITE (+) PROGRAMMABLE OUTPUT FOR ACCESSORY OR IGNITION Connect this wire to the second ignition or accessory wire in the vehicle. (Selectable by using menu 2 feature 6.) Note: For vehicles that do not have a second ignition or accessory wire, this connection is not required.
  • Page 22 Figure A Figure B Important! Always use the Vehicle Safety Check section of this guide to verify that the vehicle cannot be started in ANY drive gear and that the override switch is functioning properly. VIOLET/WHITE TACHOMETER INPUT WIRE H2/2 This input provides the module with information about the engine’s revo- lutions per minute (RPMs).
  • Page 23 H2/3 BROWN (+) BRAKE SWITCH SHUTDOWN WIRE This wire MUST be connected to the vehicle’s brake light wire. This is the wire that shows (+) 12V when the brake pedal is depressed. The remote start will be disabled or shut down any time the brake pedal is depressed.

  • Page 24: Neutral Safety Switch Interface

    Neutral safety switch interface Some vehicles do not have an electrical neutral safety switch. Instead, the vehicle has a mechanical neutral safety switch that physically in- terrupts the starter wire and is used when the vehicle is in any drive gear.

  • Page 25: D2D And Programmer Interface

    eral Motors product or a Dodge Dakota pickup, please call Directed Electronics Technical Support for an alternative shut-down method. Do not return the vehicle to the customer until this feature is properly installed! D2D and programmer interface The 4-pin red port is for interfacing with an XK module through D2D, or you can use it for programming with the Bitwriter®.

  • Page 26: Programming Jumpers

    Programming jumpers Light flash (+)/(-) This jumper is used to determine the light flash output polarity. In the (+) position, the on-board relay is enabled and the unit will output (+)12V on the WHITE wire, H1/9. In the (-) position, the on-board relay is dis- abled.

  • Page 27: Plug-In Program Switch

    Plug-in program switch The Program switch plugs into the blue two-pin connector. Tach learning Virtual tach To program Virtual Tach: After the install is complete, remote start the car. If the car does not start on the first attempt, let the remote start at- tempt again.

  • Page 28: To Learn The Tach Signal

    To learn the tach signal 1. Start the vehicle with the key. DRW-96 HOLD 2. Within 5 seconds, press and the Pro- gram switch. 3. The LED will light constant when the tach signal is learned. 4. Release the Program switch. Tach threshold on/off In most cases, this jumper can be left in the OFF position.

  • Page 29: Remote Control Learn Routine

    Remote control learn routine The system comes with two transmitters that have been taught to the receiver. The receiver can store up to 4 different transmitter codes in memory. Use the following learn routine to add transmitters to the sys- tem.
  • Page 30 Function Reset Features: This resets features all of the security system to the factory default settings. Note: This feature does not delete the remotes from the security system or reset the Virtual Tach setting. Virtual Tach Reset: Deletes all previously learned values for Virtual Tach, and on Note: The “Zap”...

  • Page 31: Remote Configuration

    Learn Routine will be exited if: Ignition is turned off. Program switch is pressed too many times. More than 25 seconds elapses between programming steps. Remote Configuration Button Press Function while Function while remote start is OFF remote start is ON Pressing for less than Start the engine Unlock the doors...

  • Page 32: Operating Settings Learn Routine

    Operating settings learn routine The System Features Learn Routine dictates how the unit operates. The programmable operating settings of this unit can be changed when- ever necessary through the computer-based Learn Routine. The Program push-button switch, plugged into the blue port, is used together with a programmed transmitter to change the settings.
  • Page 33 Once the Program switch has been pressed and released the desired HOLD number of times, press it once more and it. After a second, the LED will flash to indicate which feature you have accessed. For output feature (Feature 8). Transmit.

  • Page 34: Features Menu

    Features menu bold The factory default settings are indicated in low. Menu 1 Fea- Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+ ture # Honk pulses 20 mS 30 mS 40 mS 50 mS Ignition con- trolled lock Ignition con- trolled unlock Doorlock pulse...

  • Page 35: Menu 2

    Menu 2 Fea- Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+ ture # Engine checking Virtual tach voltage tachometer Run time 12 min 24 min 60 min Park lights Constant Flashing Crank time 0.6 sec. 0.8 sec. 1.0 sec. 1.2 sec.

  • Page 36: Feature Descriptions

    Feature descriptions The features of the system are described below with default settings in bold. Menu 1 1 HORN HONK PULSES—ON, Turns On/Off the confirmation honks when unlocking. Use it to change the output pulse duration for vehicles that require a longer pulse for the horn to honk.
  • Page 37 5 UNLOCK OUTPUT— , 2 PULSES: This will program the unlock output to one or two pulses. When the dou- ble pulse unlock feature is turned on, the BLUE (3) wire will supply two negative pulses instead of a single pulse. This makes it possible to 6 LOCK OUTPUT—...

  • Page 38: Menu 2

    (2) Comfort closure 1 - Activates the 20 second timer after the door lock pulse. (3) Comfort Closure 2 - Activates the 20 second timer with the door lock pulse. Note : Not available with 1 button remote 10 PANIC /Off: When on, the panic feature can be activated at any time from the remote and will sound for 30 seconds.
  • Page 39 and shuts down. Programmed to the default setting the engine will run for 12 minutes. If the 24 or 60 minute run time is desired, change this feature to the two or three flash setting. CONSTANT 3 PARKING LIGHTS— /FLASHING: In the default setting, the parking lights will come on solidly for the entire run duration.
  • Page 40 to-start period of a diesel motor. When ON the accessory comes on when the wait-to-start output is activated and stays on, dropping out during crank and returning once the car has started. When OFF the accessory will activate as a normal accessory. NORMAL 8 2nd STATUS OUTPUT—...
  • Page 41 Bitwriter® The Bitwriter® has the ability to fine tune certain features of the security system. These features and the adjustments that may be programmed are de- scribed in the table below. Feature Default Optional settings setting Remote start runtime 12 minutes 1-60 minutes Diesel start delay Timed...

  • Page 42: Shutdown Diagnostics

    Shutdown diagnostics The unit has the ability to report the cause of the last shutdown of the remote start system. To enter diagnostic mode: 1. Turn the ignition off. HOLD 2. Press and the Program switch. 3. Turn the ignition on and then off. 4.

  • Page 43: Safety Check

    LED FLASHES SHUTDOWN MODE System timed out Over-rev shutdown Low or no RPM, Low battery (for voltage & virtual tach modes) Transmitter Shutdown (or optional push button) (-) hood shutdown (+) brake shutdown Neutral safety Safety check Before vehicle reassembly, the remote system must be checked to en- sure safe and trouble-free operation.
  • Page 44 Important: Make sure there is adequate clearance to the front and rear of the vehicle before attempting this test. a. Make sure the hood is closed and no other shutdown circuits are active. b. Set the emergency brake. c. Turn the ignition key to the run position but do not start the en- gine.

  • Page 45: Troubleshooting

    Troubleshooting The starter cranks for six seconds but does not start. Either the wrong ignition wire is being energized, the system’s ignition and accessory wires have been connected backwards, or the vehicle has two ignition circuits. Try activating the unit with the ignition key in the “run”...
  • Page 46 Does the vehicle have an immobilizer? Some immobilizer systems will not allow the vehicle to crank if active. Check connections. The two red heavy gauge input wires on the relay satellite should have solid connections. “T-taps”, or “scotch locks” are not recommended for any high current heavy gauge wiring.
  • Page 47 The vehicle will start and run only for about 10 seconds. Is the remote start programmed for voltage sense? Try program- ming the unit for low voltage reference. If this does not work, a tach wire should be used. Check diagnostics. ©...

  • Page 48: Wiring Quick Reference Guide

    Wiring quick reference guide BROWN (-) horn honk output RED/WHITE (-) 200mA channel 2 output (Not used) Off On © 2008 Directed Electronics. All rights reserved.

  • Page 49: Wiring Quick Reference Guide Continued

    Wiring quick reference guide continued ORANGE (-) ground when locked (Not used) VIOLET red 4 pin d2d bitwriter port © 2008 Directed Electronics. All rights reserved.
