Viper 552 Series Owner's Manual

Viper 552 series remote start keyless entry system owner's guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
552 Series
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 552 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Viper 552 Series

Summary of Contents for Viper 552 Series

  • Page 1 552 Series Owner's Guide...

  • Page 3: Limited Lifetime Consumer Warranty

    Limited Lifetime Consumer Warranty Directed Electronics, Inc. ("DEI ® ") promises to the original purchaser to repair or replace with a comparable reconditioned model any DEI unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following con- ditions are met: the unit was professionally installed and serviced by an authorized...
  • Page 4 DALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DEI OR ITS SUB- SIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.

  • Page 5: Table Of Contents

    Table of Contents Limited Lifetime Consumer Warranty ....... . i What Is Included .

  • Page 6: Standard Configuration

    Standard Configuration controls the Arm function. controls the Disarm function. controls Silent Mode™and an Auxiliary Output. controls the Panic function. pressed simultaneously control Remote Start. 2000 Directed Electronics, Inc. ©...

  • Page 7: What Is Included

    What is Included The control module An XHF receiver/antenna One or two four-button transmitters The red status LED indicator light A push-button Valet ® switch Your warranty registration Failsafe Starter Kill Relay ® A shut-down toggle switch Important Information Congratulations on the purchase of your remote start keyless entry system.

  • Page 8: System Maintenance

    System Maintenance The system requires no specific maintenance. Your remote is powered by a small, lightweight 3-volt lithium battery that will last approx- imately one year under normal use. When the battery begins to weaken, operating range will be reduced and the LED on the remote will dim. Your Warranty Your warranty registration must be completely filled out and returned within 10 days of purchase.

  • Page 9: Transmitter Functions

    Transmitter Functions The receiver uses a computer-based learn routine to learn the transmitter buttons. This makes it possible to assign any specific transmitter button, or combination of buttons, to any receiver function. The transmitter initially comes programmed with the Standard Configuration, but may also be customized by an autho- rized dealer.

  • Page 10: Using Your System

    Button The panic function is controlled by pressing and holding second. Buttons The remote start function of your system is controlled by pressing these buttons simultaneously. Using Your System Warning! Safety First The following safety warnings must be observed at all times: Due to the complexity of this system, installation of this product must only be performed by an authorized DEI dealer.
  • Page 11 THE USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE STORAGE AREA MUST AT ALL TIMES REMAIN CLOSED. These precau- tions are the sole responsibility of the user.

  • Page 12: Locking/Arming

    STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AUTHORIZED DEI DEALER TO REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE.

  • Page 13: Unlocking/Disarming

    NOTE: For Passive Mode to be effective, the Failsafe must be installed. Unlocking/Disarming Pressing for one second disarms the system and unlocks the doors (if connected). The horn will honk twice (if connected) and the parking lights will flash twice to confirm disarming of the sys- tem.

  • Page 14: Valet Mode

    Valet ® Mode You can prevent your system from automatically activating the Failsafe ® Starter Kill and locking the doors by using Valet This is very useful when washing the vehicle or having it serviced. In Valet ® Mode, the starter kill cannot be activated, even with the transmitter, but all convenience functions (door locks, remote start, etc.) will continue to work normally.

  • Page 15: Remote Start

    Remote Start This feature allows you to remotely start and run your vehicle for a programmable period of time. This makes it possible to warm up the engine, as well as adjust the interior temperature of the vehi- cle with the climate control system. If interior heating or cooling is desired, the climate controls must be preset, and the fan blower must be set to the desired level prior to remote starting the vehicle.

  • Page 16: Valet Take-Over

    When you are ready to drive the vehicle: 1. Insert the ignition key and turn it to the ON (not the START) position. 2. Press the brake pedal. NOTE: If the brake pedal is pressed before the key is in the ON position, the engine will shut down.

  • Page 17: Timer Mode

    To perform Valet ® Take-Over: Before turning off the engine, press and release on the transmitter (or press and release the optional momen- tary switch). Turn the ignition key to the OFF position. (The engine will stay running.) The engine will run until the pre-programmed time elapses or a shut-down input is received.

  • Page 18: Starter Anti-Grind Circuitry

    The engine may be allowed to run for its pre-programmed time period, or it can be shut down while running during Timer Mode operation by pressing Buttons the vehicle will restart every three hours for a total of six opera- tion cycles.

  • Page 19: Disabling The Remote Start System

    Disabling the Remote Start System This feature allows your system's remote start unit to be tem- porarily disabled to prevent the vehicle from being remote started accidentally. This feature is useful if the vehicle is being serviced or stored in an enclosed area. To disable the remote start, move the shutdown toggle switch to the OFF position.

  • Page 20: Programming Options

    Programming Options Programming options control your system's normal, operational set-up. Most options do not require additional parts, but some may require additional installation labor. This system's programming options are listed below, with the factory default settings in bold: 12, 24, or 60 minute run time. Your system can be pro- grammed to allow the vehicle to run for 12, 24, or 60 min- utes when remote started or in Timer Mode.

  • Page 21: Glossary Of Terms

    Glossary of Terms Control Unit: The “brain” of your system. Usually hidden under- neath the dash area of the vehicle. It houses the microprocessor which monitors your vehicle and controls all system functions. Failsafe ® Starter Kill: An automatic switch controlled by your sys- tem which prevents the vehicle’s starter from cranking whenever the system is armed.

  • Page 22: Convenience Expansions

    Convenience Expansions Listed below are some of the many expansion options available for use with your system. Some options may require additional parts and/or labor. Please consult with your dealer for a complete list of options available for use with this system. Domelight Supervision: The domelight will illuminate for 30 seconds each time the system is disarmed using the transmitter.
  • Page 23 dows automatically when the system is armed, or roll two win- dows down by using the transmitter. The 530T will roll two win- dows both up and down. The 530T also provides one touch switch operation. Progressive Door Unlocking: For added security, your system can be configured to unlock the driver’s door only, leaving the pas- senger doors locked.
  • Page 24 Notes 2000 Directed Electronics, Inc. ©...

  • Page 25: Quick Reference Guide

    QUICK REFERENCE GUIDE: To lock/arm using your remote s To arm the system press for one second. The doors will lock (if con- nected). The LED will begin to flash. The Failsafe vent the vehicle’s starter from cranking if it has been installed. The ve- hicle’s horn (if connected) will honk and the parking lights will flash once to confirm arming of the system.
  • Page 28 The company behind this system is Directed Electronics, Inc. Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, DEI is ISO 9001 registered.
