- Page 1 REPAIR PARTS MANUAL MODEL NO. 164863 (96016000600) Lawn Tractor 404118 12.29.05 VB PRINTED IN U.S.A.
-
Page 2: Table Of Contents
HOW TO USE THIS MANUAL This manual is designed to provide the customer with a means to identify the parts on his/her tractor when ordering repair parts. The illustrations may or may not represent the actual assemblies; therefore, it is not recommended to use this manual as a guide to assemble or disassemble the tractor. Some hardware and parts are drawn larger in order to more readily identify them. -
Page 3: Schematic
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 SCHEMATIC 03059_197428 BATTERY STARTER FUSE AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE ATTACHMENT CLUTCH (PEDAL UP) (CLUTCH OFF) BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY GRAY REVERSE SWITCH SHORTING CONNECTOR... -
Page 4: Electrical
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 ELECTRICAL 197428... - Page 5 REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 ELECTRICAL PART DESCRIPTION 163465 Battery 74760412 Bolt Hex Hd 1/4-20 unc x 3/4 176689 Box Battery 176138 Switch Interlock 175688 Harness Asm Light W/4152j 4152J Bulb Light #1156 4799J Cable Battery 6 Ga.
-
Page 6: Chassis
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 CHASSIS Chassis-Alpha_Stlt_2... - Page 7 REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 CHASSIS PART DESCRIPTION 174619 Chassis 176554 Drawbar, Stretch 155272 Bumper, Hood/Dash 193510X010 Dash 72140608 Bolt, Carriage 3/8-16 x 1 174996 Panel Dash LH 172105X010 Panel Slkscr Dash RH 187559X574 Hood 184921 Bumper Hood...
-
Page 8: Drive
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 DRIVE drive-fender.stlt_46... - Page 9 REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - Transaxle Dana D4360-140 175410 Pulley, Engine (See Breakdown) 173937 Bolt Hex 7/16-20 x 4 Gr. 5-1.5 146682 Spring Brake Return 10040700...
-
Page 10: Steering
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 STEERING steering_pl.lt_58... - Page 11 REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 STEERING PART DESCRIPTION 186780 Wheel Steering 195673 Axle Asm 169840 Spindle Asm LH 169839 Spindle Asm RH 6266H Bearing Race Thrust Harden 121748X Washer 25/32 x 1-5/8 x 16 Ga. 19272016 Washer 27/32 x 1-1/4 x 16 Ga.
-
Page 12: Engine
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs.1cyl_49 PART PART DESCRIPTION DESCRIPTION 170551 Control Th/ch Flag 17000612 Screw Hex Wsh Thdrol 3/8-16 17720408 Screw Hex Thd Cut 1/4-20 x 1/2 19091416 Washer 9/32 x 7/8 x 16 Ga. -
Page 13: Seat
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 SEAT seat_lt.knob_13 PART PART DESCRIPTION DESCRIPTION 404042 Seat 121248X Bushing Snap Blk Nyl 140551 Bracket Seat Pivot 72050412 Bolt Rdhd Sht Nk 1/4 - 20 x 1 -1/2 71110616 Bolt Hex 3/8 - 16 x 1 134300... -
Page 14: Mower Deck
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 MOWER DECK 42_deck_man-t-path_3... - Page 15 REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 MOWER DECK PART PART DESCRIPTION DESCRIPTION 165892 Mower Deck Assembly, 42" 131494 Pulley, Idler, Flat 72140506 Bolt 73900600 Nut Lock 3/8-16 138017 Bracket Asm Fr. Sway Bar 3/42 140088 Guard, Mandrel, LH 165460...
-
Page 16: Mower Lift
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 MOWER LIFT 16 17 lift-rh.1piece_3 PART PART DESCRIPTION DESCRIPTION 159460 Wire Asm Inner/Sprg w/plunger 173288 Link Front 159471 Shaft Asm Lift RH 73350800 Nut Jam Hex 1/2-13 unc 105767X Pin Groove 1 500 Zinc 175689... -
Page 17: Decals
REPAIR PARTS TRACTOR - - MODEL NUMBER 164863 (96016000600). PRODUCT NO. 960 16 00-06 DECALS PART PART DESCRIPTION DESCRIPTION 181251 Decal, Clutch Brake 145005 Decal, Caution, Battery 404121 Decal, Replacement 193863 Decal, Oper Sdl P/L Gear Dr Eng 189455 Decal, Engine HP 160396 Decal, V-Belt Sch. - Page 18 Murray Pro Series 4 Year Warranty The Home Depot Canada is doubling the warranty period of the manufacturer’s warranty and those of the companies that manufacture engines, accessories, transmissions, batteries, transaxles and other sourced components To make claim under this warranty does not change. Return the unit or if authorized in advance, the defective part, along with your proof of purchase to The Home Depot Canada store where purchased or closest to you, or, to an authorized Service Dealer.
