- Page 1 USERS GUIDE ASP-FIBRS2 HDMI Fiber Extender with Serial Manual Number: 140516...
-
Page 2: Safety Instructions
Power outlet: To prevent electric shock, be sure the electrical plug used on the product power cord matches the electrical outlet used to supply power to the Aurora product. Use only the power adapter and power connection cables designed for this unit. -
Page 3: Table Of Contents
User Guide TABLE OF CONTENTS PACKAGE CONTENTS ......................1 INTRODUCTION ........................2 About ..............................2 Features ..............................2 INSTALLATION ......................... 3 Setup ..............................3 Connection Diagram ..........................4 Fiber Usage ............................5 CONNECTOR PIN DEFINITION ....................6 HDMI ..............................6 RS-232 .............................. -
Page 4: Package Contents
User Guide PACKAGE CONTENTS Please make sure the following items are included within your package. Contact your dealer if any items are missing or damaged. ASP-FIBRS2-TX (Transmitter) ASP-FIBRS2-RX (Receiver) 5V DC Power Wall Adapter x 2 ... -
Page 5: Introduction
INTRODUCTION About The ASP-FIBRS2 HDMI Fiber Extender offers an easy way to extend full HD HDMI with serial 300 meters away over a single core multi-mode fiber. The conveyed video is uncompressed to ensure the best video and audio quality. The ASP-FIBRS2 also supports RS-232 which can transmit and receive serial data between a controller and display (ex. -
Page 6: Installation
INSTALLATION Setup 1. Connect your HDMI source to the HDMI input connector on ASP-FIBRS2-TX side. 2. Connect your HDMI display to the HDMI output connector on ASP-FIBRS2-RX side. 3. Plug the fiber to both TX and RX SC Duplex fiber connectors. -
Page 7: Connection Diagram
User Guide Connection Diagram Duplex connectors must be crossed connection:... -
Page 8: Fiber Usage
User Guide Fiber Usage 1. 300m transmission distance is tested and guaranteed with bundled fiber which is made of Corning OM3 level multi-mode fiber. 2. The fiber is designed to be deployed without damaging existed home or office decoration. It is fragile and not suitable to be deployed in the pipeline inside the building. 3. -
Page 9: Connector Pin Definition
User Guide CONNECTOR PIN DEFINITION HDMI Pin 1 TMDS Data2+ Pin 8 TMDS Data0 Shield Pin 15 Pin 2 TMDS Data2 Shield Pin 9 TMDS Data0– Pin 16 Pin 3 TMDS Data2– Pin 10 TMDS Clock+ Pin 17 DDC/CEC Ground Pin 4 TMDS Data1+ Pin 11 TMDS Clock Shield... -
Page 10: Appendix 1
User Guide APPENDIX 1 Troubleshooting Problem Solution a. Check that the power plug is properly inserted into a functioning power outlet. 1. No Video Signal. b. Make certain fiber cable is correct specification c. Make certain fiber is nulled a. Check the baud rate 2. -
Page 11: Appendix 2
Operation temperature -10~50C Storage temperature -20~75C Relative humidity 10~85% RH [no condensation] Regulatory Approvals FCC Class B, CE Class B, RoHS 1x ASP-FIBRS2 [TX & RX] Package Contents 1x 5V power adapter 1x User Manual Specifications subject to change without notice. -
Page 12: Appendix 4 Warranty
Limited 3 Year Warranty Aurora Multimedia Corp. (“Manufacturer”) warrants that this product is free of defects in both materials and workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty covers products purchased in the year of 2009 and after. - Page 13 User Guide This product warranty extends to the original purchaser only and will be null and void upon any assignment or Aurora Multimedia Corp. 205 Commercial Court Morganville, NJ 07751 Phone: 732-591-5800 Fax: 732-591-6801...
