E-Z-GO YEAR 2006+ Service & Parts Manual page 77

Where applicable, THE USE OF NON UL PARTS WILL VOID ANY UL LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
31 75308-G01
32 75305-G01
33 75292-G01
34 75309-G01
35 75342-G01
36 00518-G8
37 10387-G1
38 75307-G01
39 00566-G6
40 00533-G8
41
42 602981
43 603089
44 27205-G01
45 18434-G3
46 27205-G02
47 18434-G4
48 50209-G2
49 10387-G2
1 2 3 4 5
TOW BAR HITCH ASSEMBLY (TOWED VEHICLE)
(INCLUDES ITEMS 32 - 49)................................................................................
HITCH ...........................................................................................................
PIVOT BOLT .................................................................................................
THRUST WASHER.......................................................................................
WASHER, 3/4" ..............................................................................................
CASTELLATED NUT, 3/4 - 16 ......................................................................
COTTER PIN, 1/8" X 1 1/2" LG ....................................................................
BEARING......................................................................................................
LOCK WASHER, 3/4" ...................................................................................
NUT, 3/4 - 16.................................................................................................
TIE ROD ASSEMBLY (INCLUDES ITEMS 43 - 47) .....................................
THREADED ROD...................................................................................
TIE ROD END (LEFT HAND THREADS)...............................................
JAM NUT, M12 X 1.25-05 (LEFT HAND THREADS) .............................
TIE ROD END (RIGHT HAND THREADS) ............................................
JAM NUT, M12 X 1.25-05 (RIGHT HAND THREADS)...........................
CASTELLATED NUT, 7/16 - 20 ....................................................................
COTTER PIN, 3/32" X 1" LG ........................................................................
Service Parts Manual
TOW BAR - PERMANENT
DESCRIPTION QTY.
1
1
1
2
1
1
2
1
1
1
1
1
1
1
1
1
2
2
Page N-4
