E-Z-GO YEAR 2006+ Service & Parts Manual page 71

Where applicable, THE USE OF NON UL PARTS WILL VOID ANY UL LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 76418-G01
2 10435-G1
3 10194-G1
4 00532-G6
5 10044-G01
6 603109
7 74207-G03
8 72618-G01
9 00560-G1
10 11098-G5
11
12 70289-G02
13 70291-G01
14 70290-G02
15 00665-G9
16 11098-G5
17
18 14158-G1
19 12262-G1
1 2 3 4 5
SHOCK ABSORBER...........................................................................................
SHOCK ABSORBER WASHER ..........................................................................
RUBBER BUSHING ............................................................................................
NUT, 3/8 - 24.......................................................................................................
VINYL CAP..........................................................................................................
LEAF SPRING, 2 LEAF.......................................................................................
LEAF SPRING, 4 LEAF.......................................................................................
'U' BOLT, 3/8 - 16 X 2" X 2 1/2" LG....................................................................
WASHER, 3/8" ....................................................................................................
LOCK NUT, 3/8 - 16 ............................................................................................
SPACER..............................................................................................................
FLANGED BUSHING (LEAF SPRING) ...............................................................
SHACKLE PLATE ...............................................................................................
BOLT, 3/8 - 16 X 3 1/2" LG (STAINLESS STEEL)..............................................
LOCK NUT, 3/8 - 16 ............................................................................................
SHOULDER BOLT, 3/8 - 16 X 3 1/4" LG ............................................................
LOCK NUT, 3/8 - 16 ............................................................................................
Service Parts Manual
REAR SUSPENSION
DESCRIPTION QTY.
2
8
8
4
4
2
2
4
8
8
4
12
4
4
4
2
2
Page L-2
