JENN-AIR
COMPACTORS/COMPACTEURS
INTEGRATED
INTÉGRÉS
Use & Care Guide
For questions about features, operation/performance, parts, accessories, or service in the U.S.A., call:
1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com.
In Canada, call: 1-800-807-6777, or visit our website at www.jennair.ca.
Guide d'utilisation et d'entretien
Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777 ou visitez notre site Web www.jennair.ca.
Table of Contents/Table des matières .......................................................................................... 2
W10242571A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W10242571A and is the answer not in the manual?

Questions and answers

Summary of Contents for Jenn-Air W10242571A

  • Page 1 1-800-JENNAIR (1-800-536-6247) or visit our website at www.jennair.com. In Canada, call: 1-800-807-6777, or visit our website at www.jennair.ca. Guide d’utilisation et d’entretien Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777 ou visitez notre site Web www.jennair.ca. Table of Contents/Table des matières ... 2 W10242571A...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS COMPACTOR SAFETY ...3 INSTALLATION INSTRUCTIONS ...4 Unpacking ...4 Location Requirements ...4 Electrical Requirements ...5 Undercounter Installation...6 COMPACTOR USE...8 How Your Compactor Works...8 Loading...8 Starting Your Compactor...8 Using Compress (Locked) Cycle ...8 Using the Air Filter...9 Removing a Filled Bag ...9 Installing a New Bag ...9 COMPACTOR CARE...10 Changing the Air Filter...10...
  • Page 3: Compactor Safety

    Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”...
  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS Installer: Leave Use and Care Guide with the homeowner. Homeowner: Keep Use and Care Guide for future reference and for local electrical inspector’s use, if required. Unpacking WARNING Excessive Weight Hazard Use two or more people to move and install compactor. Failure to do so can result in back or other injury.
  • Page 5: Electrical Requirements

    Cutout dimensions 3" min. (7.6 cm) 24" min. (61 cm) 18" min. (45.7 cm) 15 " min. (38.7 cm) A. Grounded electrical outlet must be a minimum of 3" (7.6 cm) away from surrounding cabinets or nearby walls as shown. It can be placed either to the left or the right side of the product.
  • Page 6: Undercounter Installation

    NOTE: Proper installation is your responsibility. Make sure you have everything necessary for correct installation. It is the personal responsibility and obligation of the customer to contact a qualified installer to assure that electrical installation meets all national and local codes and ordinances. Tools needed: Gather the required tools and parts before starting installation.
  • Page 7 Cabinet-front mounting A. Mounting clip B. Cabinet C. Retaining bracket D. Mounting screw 7. Grasp sides of compactor drawer and place bottom of drawer into tracks. Lift at the handle so drawer will go over drawer stops. Close drawer. Check that the drawer opens freely.
  • Page 8: Compactor Use

    How Your Compactor Works The compacting ram is the part of the compactor which compresses the trash. The compacting ram does not go to the bottom of the drawer. You will not see compacting of trash the first few times you load the compactor. NOTE: The compactor drawer should be more than the compactor can begin to compress the load.
  • Page 9: Using The Air Filter

    Using the Air Filter 1. Set the Air Filter switch to ON. The fan creates air movement in the compactor for odor removal. NOTE: The charcoal Air Filter works only when the Key-Knob is in the ON position. 2. Set the Air Filter switch to OFF to turn off the fan. Removing a Filled Bag When the trash is compacted to the top of the drawer, remove the bag.
  • Page 10: Compactor Care

    Your new compactor is designed to give you many years of dependable service. However, there are a few things you are expected to do in order to properly maintain your compactor. This section will tell you how to clean and care for your compactor. Changing the Air Filter It is recommended that you use the charcoal air filter in the filter compartment.
  • Page 11: Cleaning The Ram

    4. Vacuum the inside of the cabinet. Liquid spills or wet trash should be cleaned up by hand, or by using a vacuum designed to pick up liquids. 5. Wash the inside of the cabinet with a clean sponge or soft cloth and a mild detergent in warm water.
  • Page 12 OTHER Plastics with this symbol cannot be recycled. Items with this symbol can be recycled or were made from recycled materials. A compactor makes recycling and landfill reduction efforts more effective and efficient. Recycling Guidelines Contact your community recycling program or local recycling organizations to find out which items are accepted for recycling and how they should be prepared and organized.
  • Page 13: Assistance Or Service

    “Troubleshooting” section… Call the dealer from whom your appliance was purchased, or call Jenn-Air at 1-800-807-6777 to locate an authorized service company. When calling, please know the purchase date and the complete model and serial number of your appliance. Be sure to retain proof of purchase to verify warranty status.
  • Page 14: Warranty

    Jenn-Air brand of Whirlpool Corporation or Whirlpool Canada LP (hereafter “Jenn-Air”) will pay for factory specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a Jenn-Air designated service company. This limited warranty is valid only in the United States or Canada and applies only when the major appliance is used in the country in which it was purchased.
  • Page 15: Sécurité Du Compacteur

    SÉCURITÉ DU COMPACTEUR Votre sécurité et celle des autres est très importante. Nous donnons de nombreux messages de sécurité importants dans ce manuel et sur votre appareil ménager. Assurez-vous de toujours lire tous les messages de sécurité et de vous y conformer. Voici le symbole d’alerte de sécurité.
  • Page 16: Instructions D'installation

    INSTRUCTIONS D’INSTALLATION Installateur : Laissez le Guide d’utilisation et d’entretien au propriétaire. Propriétaire : Gardez le Guide d’utilisation et d’entretien pour référence ultérieure et pour l’usage de l’inspecteur local d’électricité, au besoin. Déballage AVERTISSEMENT Risque du poids excessif Utiliser deux ou plus de personnes pour déplacer et installer le compacteur.
  • Page 17: Spécifications Électriques

    Dimensions de l’encastrement 3" (7,6 cm) 24" min. (61 cm) 18" min. (45,7 cm) 15 " min. (38,7 cm) A. La prise électrique reliée à la terre qui doit être à une distance minimum de 3" (7,6 cm) des armoires voisines ou des murs latéraux tel qu'illustré.
  • Page 18 Glisser le compacteur sur le carton ou le panneau de bois dur avant de déplacer le compacteur sur le plancher, pour empêcher d’endommager le revêtement du plancher. Ne pas laisser le châssis arrière du compacteur toucher le revêtement du plancher lors du soulèvement ou du déplacement du compacteur.
  • Page 19 Montage à l’avant de l’armoire A. Agrafe de montage B. Armoire C. Bride de retenue D. Vis de montage 7. Saisir les côtés du tiroir du compacteur et placer le fond du tiroir dans les glissières. Soulever le tiroir par la poignée pour faire passer l’avant du tiroir au-dessus des butées.
  • Page 20: Utilisation Du Compacteur

    UTILISATION DU COMPACTEUR Fonctionnement du compacteur La presse de compactage est la partie du compacteur qui compresse les déchets. La presse de compactage ne descend pas jusqu’au fond du tiroir. Les premiers déchets chargés ne seront donc pas comprimés les premières fois que vous chargez le compacteur.
  • Page 21: Utilisation Du Filtre À Air

    Utilisation du filtre à air 1. Régler l'interrupteur du filtre à air sur ON (marche). Le ventilateur crée un mouvement d'air dans le compacteur pour éliminer les odeurs. REMARQUE : Le filtre à air au charbon fonctionne seulement lorsque le bouton à clé est à la position ON (marche). 2.
  • Page 22: Entretien Du Compacteur

    ENTRETIEN DU COMPACTEUR Votre nouveau compacteur est conçu pour vous donner de nombreuses années de service fiable. Toutefois vous avez quelques mesures à prendre pour bien maintenir le rendement de votre compacteur. Cette section vous expliquera comment nettoyer et prendre soin de votre compacteur. Changement du filtre à...
  • Page 23: Dépannage

    3. Saisir les côtés du tiroir et le tirer jusqu’à ce qu’il sorte complètement. Le déposer délicatement. 4. Passer l’aspirateur à l’intérieur de la caisse. Les liquides renversés ou les déchets humides doivent être nettoyés à la main ou au moyen d’un aspirateur conçu pour aspirer les liquides.
  • Page 24: Recyclage Avec Votre Compacteur

    Les bouteilles ne se brisent pas À quelle fréquence remarquez-vous cette situation? Toutes les bouteilles ne se briseront pas à chaque fois. L'épaisseur du verre d'une bouteille ainsi que la nature des déchets en dessous de celle-ci peuvent empêcher la bouteille de se briser.
  • Page 25: Assistance Ou Service

    “Dépannage”… Téléphonez au marchand qui vous a vendu l'appareil ou téléphonez à Jenn-Air en composant le 1-800-807-6777 pour localiser une compagnie de service autorisée. Lors d'un appel, veuillez connaître la date d'achat et les numéros de modèle et de série complets de votre appareil.
  • Page 26 Notes...
  • Page 27: Garantie

    5. Les défauts apparents, notamment les éraflures, les bosses, fissures ou tout autre dommage au fini du gros appareil ménager, à moins que ces dommages soient dus à des vices de matériaux ou de fabrication et soient signalés à Jenn-Air dans les 30 jours suivant la date d’achat.
  • Page 28 ® Registered Trademark/™ Trademark of Jenn-Air U.S.A. © 2010 Used under license in Canada. 2/10 All rights reserved. ® Marque déposée/™ Marque de commerce de Jenn-Air U.S.A. Printed in U.S.A. Tous droits réservés. Emploi sous licence au Canada. Imprimé aux É.-U.
