SERVICE MANUAL

MODEL
COMMANDER DEST.
KV-XS29N90
RM-914 TAIWAN
KV-XS29N93
RM-914 TAIWAN
CHASSIS NO.
MODEL
SCC-P13J-A
SCC-P13H-A
TRINITRON
BG-3S
CHASSIS
COMMANDER DEST.
COLOR TV
®
CHASSIS NO.

Advertisement

Table of Contents
loading

Related Manuals for Sony TRINITRON KV-XS29N90

Summary of Contents for Sony TRINITRON KV-XS29N90

  • Page 1: Service Manual

    SERVICE MANUAL BG-3S CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KV-XS29N90 RM-914 TAIWAN SCC-P13J-A KV-XS29N93 RM-914 TAIWAN SCC-P13H-A TRINITRON COLOR TV ®...
  • Page 2 CARBON PAINTED ON THE CRT, AFTER REMOVING THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE ANODE. THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. – 2 –...

  • Page 3: Table Of Contents

    KV-XS29N90/XS29N93 RM-914 TABLE OF CONTENTS Section Title Page Section Title Page SELF DIAGNOSIS FUNCTION 5. DIAGRAMS ........ 4 5-1. Block Diagram ............45 1. GENERAL ................ 8 5-2. Frame Schematic Diagram ........49 Circuit Boards Location .......... 53 2. DISASSEMBLY 5-4.

  • Page 4: Self Diagnosis Function

    KV-XS29N90/XS29N93 RM-914 SELF DIAGNOSTIC FUNCTION The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER lamp will automatically begin to flash. The number of times the lamp flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER lamp flash indicators is listed in the instruction manual for the user’s knowledge and reference.
  • Page 5 KV-XS29N90/XS29N93 RM-914 DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT 2 times 5 times Lamp ON 0.3 sec. Lamp OFF 3 sec. Lamp OFF 0.3 sec. STANDBY/SLEEP lamp Diagnostic Item Flash Count* +B overcurrent/overvoltage 2 times Vertical deflection stopped White balance failure 5 times * One flash count is not used for self-diagnostic.
  • Page 6 KV-XS29N90/XS29N93 RM-914 SELF-DIAGNOSTIC SCREEN DISPLAY For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurances of failure for confirmation on the screen: [To Bring Up Screen Test] In standby mode, press buttons on the remote commander sequentially in rapid succession as shown below: [Screen display] / channel [5] / Sound volume [-] / Power ON...
  • Page 7 KV-XS29N90/XS29N93 RM-914 SELF-DIAGNOSTIC CIRCUIT IC301 IC001 IC003 Y/CHROMA JUNGLE SYSTEM MEMORY FROM IK-IN IO-8DAT B-DAT FROM [+B] Q604 C O-LED PROTECT IO-SDAT [V] Q509/507 [+B overcurrent ªOCPº] Occurs when an overcurrent on the +B(135) line is detected by Q604. If Q604 go to ON and the voltage to pin 18 of IC301 should go down when V.SYNC is more than seven...

  • Page 13: Set-Up Adjustments

    KV-XS29N90/XS29N93 SECTION 3 RM-914 SET-UP ADJUSTMENTS • The following adjustments should be made when a complete Perform the adjustments in the following order : realignment is required or a new picture tube is installed. 1. Beam Landing • These adjustments should be performed with rated power 2.

  • Page 14: Convergence

    KV-XS29N90/XS29N93 RM-914 3-2. CONVERGENCE Preparation : • Before starting this adjustment, adjust the focus, horizontal size and vertical size. • Minimize the brightness setting. Purity • Provide dot pattern. BMC (Hexapole) (1) Horizontal and Vertical Static Convergence Purity Center dot V.
  • Page 15 KV-XS29N90/XS29N93 RM-914 BMC (Hexapole) Magnet. Blue Neck assy Neck assy If the red, green and blue dots are not balanced or aligned, then use the BMC magnet to adjust in the manner described below. Blue VM board VM board Note 1.

  • Page 16: Focus Adjustment

    KV-XS29N90/XS29N93 RM-914 Rotate TLV-2 VOL (29”, 34”) on DY 3-3. FOCUS ADJUSTMENT Rotate TLV VOL (25”) on DY Adjust FOCUS control on the flyback transformer for the best XCV Rotate XCV Adj core on DY focus. YCH Rotate YCH VOL on DY...

  • Page 17: G2 (Screen) And White Balance Adjustments

    KV-XS29N90/XS29N93 RM-914 2. WHITE BALANCE ADJUSTMENT 3-4. G2 (SCREEN) AND WHITE BALANCE 1) Set to Service Mode (Refer Section 4-1: ADJUSTMENTS ADJUSTMENTS WITH COMMANDER). 1. G2 (SCREEN) ADJUSTMENT 2) Input white raster signal. 1) Set the PICTURE to normal. 3) Set the PICTURE to minimum.

  • Page 18: Circuit Adjustment

    KV-XS29N90/XS29N93 SECTION 4 RM-914 CIRCUIT ADJUSTMENTS 4-1. ADJUSTMENTS WITH COMMANDER Service adjustments are made with the RM-914 that come with this unit. 1, 4 Select the adjustment item. ↓ a. ENTERING SERVICE MODE 3, 6 Raise/lower the data value. With the unit on standby ↓...

  • Page 19: Adjustment Method

    KV-XS29N90/XS29N93 RM-914 4-2. ADJUSTMENT METHOD Item Number 00 of device GEO Use the same method for all Items. Use 1 and 4 to select the This explanation uses H-Position as an example. 1. Select “GEO 00 HPS” with the 1 and 4 buttons.
  • Page 23 KV-XS29N90/XS29N93 RM-914 ITEM INFORMATION. No. OPB0 OP1 XTAL 4.43 XTAL 3.58 SECAM 2nd. Lang Item KV-XS29N90 KV-XS29N93 No. OPB1 OP2 Item Thai Bil Dis. Fav DVD Input NICAM HDEV AV Input KV-XS29N90 KV-XS29N93 AV Input 00 = no AV Input...

  • Page 24: Picture Quality Adjustments

    KV-XS29N90/XS29N93 RM-914 4-3. PICTURE QUALITY ADJUSTMENTS BELL FILTER ADJUSTMENT SUB COLOR ADJUSTMENT 1. Input SECAM color-bar signal. 2. Connect the dual-trace oscilloscope to CN303 pin 9 1. Input a PAL color-bar. (not mounted). 2. Set to the following condition: 3. Adjust SERVICE MODE, ITEMS ‘SBF’ as shown below.

  • Page 25: Picture Distortion Adjustment

    KV-XS29N90/XS29N93 RM-914 4-5. PICTURE DISTORTION ADJUSTMENT (1) PICTURE DISTORTION ADJUSTMENT (2) Item Number 00 – 0B H-TRAPEZOID (Rotate RV1801) GEO 0 HPS (H POSITION) GEO 1 HSZ (H SIZE) GEO 2 PAP (PIN AMP) GEO 3 TLT (TRAPEZIUM) GEO 4...
  • Page 26 KV-XS29N90/XS29N93 RM-914 MEMO ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 27 KV-XS29N90/XS29N93 RM-914 MEMO ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 28 KV-XS29N90/XS29N93 RM-914 MEMO ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...

  • Page 29: Diagrams

    KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 SECTION 5 RM-914 RM-914 RM-914 RM-914 DIAGRAMS 5-1. BLOCK DIAGRAM Control Panel MAIN.TUVF *DBFB(3D)(*4) *AUDIO OUT 3D SP BOX ASSY with Q6202 IC6201 * STEREO Q6206/6207 TDA7481 (KV-XS29N93 DECODER ONLY) (MSP3415) <slave: 86H> TU101 (*1) AV SW DBFB(3D) TV.V In...

  • Page 30: Frame Schematic Diagram

    KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 RM-914 RM-914 RM-914 RM-914 NECK ASSY CN2802 DVD Y 5-2. FRAME SCHEMATIC DIAGRAM :S-MICRO CN1501 DVD BY :WHT :S-MICRO CN2803 DF OUT DVD SWITCH DVD RY 1P:T AB INTELLIGENT PICTURE Q.P.- CN2801 DVD L Q.P.- CN1502...

  • Page 31: Circuit Boards Location

    KV-XS29N90/XS29N93 RM-914 5-3. CIRCUIT BOARDS LOCATION *J4 (KV-XS29N93) – 53 –...

  • Page 32: Schematic Diagrams And Printed Wiring Boards

    KV-XS29N90/XS29N93 RM-914 5-4. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS Note: • All capacitors are in µF unless otherwise noted. • All electrolytic capacitors are rated at 50V unless otherwise noted. • All resistors are in ohms. kΩ = 1000Ω, MΩ = 1000kΩ...
  • Page 33 (1) Schematic Diagram of A Board (1/2) CN104 CN303 CN101 CN102 :BTOB :BTOB :TAB :BTOB TO F BOARD TO B3 BOARD TO B3 BOARD TO B3 BOARD CN106 CN1407 CN4603 CN1406 CN1405 TO B3 BOARD CN608 CN105 CN6206 CN302 TU101 :S-MICRO TO H3 BOARD CN201...

  • Page 34: Schematic Diagram Of A (1/2) Board

    (2) Schematic Diagram of A Board (2/2) CN507 :S-MICRO D631 C644 TO C BOARD ERC04-06SE 0.0022 R602 C645 0.01 C656 CN1801 R500 RECT :FPRD 250V C528 680p R501 :CHIP R502 NS ROT R603 L517 D632 T604 C500 135V 105.0 470k L516 R544 ERC04-06SE...
  • Page 35 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 RM-914 RM-914 A BOARD IC001 CXP750097-024S A BOARD WAVEFORMS PAL/SECAM NTSC CLOCK GENERATOR SPC700 CPU CORE A/D CONVERTER /SYSTEM CONTROL PA0~PA7 AN0~AN5 4.8Vp-p (V) 5.1Vp-p (V) 4.0Vp-p (V) 1.2Vp-p (H) 1.5Vp-p (H) REMOCON FIFO PB0~PB7 12K/16K/24K/32K 352/704/1536 BYTES...
  • Page 36 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 RM-914 RM-914 [SYSTEM CONTROLLER, Y/C JUNGLE, DEFLECTION, NOTE: TUVIF, FRONT AMP, POWER SUPPLY] The circuit indicated at left contains high voltage of over A BOARD 600 Vp-p. Please pay attention when inspecting or repair- PRINTED WIRING BOARD ing it to prevent an electric shock.
  • Page 37 (3) Schematic Diagram of B Board CN1400 TU1401 :S-MICRO C1461 C1460 R1411 D1415 470p AUDIO(R) CH:CHIP F:CHIP UDZSTE-179.1B R/L/Y/S/C/CV R3272 6.8k R IN :CHIP R1420 C1450 C1453 R1409 C1462 R1412 JR1409 R1474 220k F:CHIP JW1481 C1437 C1463 :CHIP R3211 L IN AUDIO(L) 6.8k R3247...

  • Page 38: Schematic Diagram Of B3 Board

    (4) Schematic Diagram of C Board BOARD MARK LIST KV-XS29N93 KV-XS29N90 KV-XS29N93 KV-XS29N90 KV-XS29N93 KV-XS29N90 C1401 330 16 C6253 R3200 1 :CHIP TO HV CAP BLOCK C1403 47 25 CN1402 R3201 1 :CHIP (NOT USED FOR THIS MODEL) B3 BOARD IC3201 NJM2187L...

  • Page 39: Schematic Diagrams Of F, H5 And J4 Boards

    :FUSE AC IN AC OUT JW4604 R4601 B-SSSBG3S-...-H5.29 AC IN AC OUT 1/2W CN4602 H5 BOARD MARK LIST TO H5 BOARD KV-XS29N93 KV-XS29N90 JW4601 CN3601 C3907 1 :PT C4601 CN4603 C3914 100 16V C4602 JW4602 250V CN3903 4P :TAB 250V...
  • Page 40 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 RM-914 RM-914 RM-914 [CISPR] [FRONT PANEL, AV, HEADPHONE] [DVD, 3D] PRINTED WIRING BOARDS – J Board – (KV-XS29N93 only) – H Board – – F Board – – – – – – –...

  • Page 41: Schematic Diagrams Of B5 And Vm Boards

    (6) Schematic Diagrams of B and VM Boards R1576 C1522 L1502 R1574 R1575 R1577 C1575 R1579 C1576 R1547 L1570 R1542 4.7k C1577 R1517 R1538 C1541 :RN-CP :CHIP :CHIP CH:CHIP :CHIP R1528 C1574 C1524 F:CHIP C1523 L1508 R1516 L1507 DVD Y Q1503 C1542 Q1572...
  • Page 42 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 RM-914 RM-914 RM-914 [DVD SWITCH, [VELOCITY MODULATION] INTELLIGENT PICTURE] PRINTED WIRING BOARDS BOARD MARK LIST KV-XS29N93 KV-XS29N90 KV-XS29N93 KV-XS29N90 C1515 47 :CHIP R1506 100 :CHIP C1517 0.47 25 :CHIP R1507 22 :CHIP C1518 R1508 10 :CHIP – B Board –...

  • Page 43: Schematic Diagrams Of B7 And D3 Boards

    (7) Schematic Diagrams of B and D Boards [MULTI STANDARD, COMB FILTER] [DQP, DYNAMIC FOCUS] PRINTED WIRING BOARDS – B Board – C2801 IC2801 C2806 L2803 0.047 LM358DR MULTI STANDARD 100V 100V V.PARA AMP COMB FILTER CN2802 R2807 1.8k L2800 D2800 :S-MICRO :FPRD...

  • Page 44: Semiconductors

    KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 KV-XS29N90/XS29N93 RM-914 RM-914 RM-914 5-5. SEMICONDUCTORS DIODE TRANSISTOR AK04V0 RD9.1ES-L2 SPB-26MVWF UN2111 IRF614 CXA1315M (16PIN) SE-135N RU-1P AU-01Z-V1 UN2211 CXA1315P (16PIN) MARKING SIDE D2L20U UN2213 CXA1855S (48PIN) VIEW EL1Z 2SA1162-G CXA2139S (48PIN) ERA22-08 2SC2712-YG CXP750097-024S (64PIN) GP08D 2SD2114K...

  • Page 45: Exploded Views

    KV-XS29N90/XS29N93 RM-914 SECTION 6 EXPLODED VIEWS NOTE: • • Items marked " ∗ " are not stocked since Items with no part number and no The components identified by description are not stocked because they are seldom required for routine...

  • Page 46: Chassis

    REMARK REF. NO. PART NO. DESCRIPTION REMARK * 4-066-681-04 BRACKET, MAIN * A-1372-755-A H5 BOARD MOUNTED (KV-XS29N90) * A-1343-745-A D3 BOARD MOUNTED * A-1372-756-A H5 BOARD MOUNTED (KV-XS29N93) * A-1136-055-A B3 BOARD COMPLETE (KV-XS29N90) * 4-066-683-11 HOLDER, PWB * A-1136-101-A B3 BOARD COMPLETE (KV-XS29N93)

  • Page 47: Picture Tube

    7-685-648-79 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK X-4037-744-2 BEZNET, ASSY (KV-XS29N90) 102-108, 128 * A-1331-999-A C BOARD MOUNTED X-4037-745-2 BEZNET, ASSY (KV-XS29N93) 102-108, 128 ! 1-419-519-11 COIL, DEMAGNETIC 4-036-405-11 SPRING, COMPRESSION * 4-062-970-11...

  • Page 48: Speaker

    KV-XS29N90/XS29N93 RM-914 6-4. 3D SPEAKER (KV-XS29N93) SCREW BVTP 4 × 16 p: 7-685-663-71 SCREW BVTP 4 × 12 4: 7-685-661-14 REF. NO. PART NO. DESCRIPTION REMARK 4-068-694-01 TOP COVER, 3D BOX 4-068-695-01 BOTTOM, 3D BOX 4-302-428-03 SCREW (WASHER HEAD), (+P 3X12)

  • Page 49: Electrical Parts List

    REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C302 1-163-005-11 CERAMIC CHIP 470PF 10.00%50V * A-1299-226-A A BOARD COMPLETE (KV-XS29N90) C303 1-126-959-11 ELECT 0.47UF 20.00%50V * A-1299-227-A A BOARD COMPLETE (KV-XS29N93) ******************** C304 1-126-967-11 ELECT 47UF 20.00%50V...
  • Page 50 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C526 1-130-495-00 MYLAR 0.1UF 5.00% 50V C620 1-163-133-00...
  • Page 51 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK CN602 * 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P...
  • Page 52 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK IC602 8-749-920-61 IC SE-135N <TRANSISTOR> IC603 8-759-701-59 IC L7809CV...
  • Page 53 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R024 1-216-063-91 RES-CHIP 3.9K 1/10W R316 1-216-053-00 RES-CHIP 1.5K...
  • Page 54 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R523 1-249-411-11 CARBON 1/4W R595 1-216-073-00 RES-CHIP 1/10W...
  • Page 55 CERAMIC CHIP 0.47UF C1449 1-126-933-11 ELECT 100UF 20.00%16V ****************************************************************** C1457 1-164-346-11 CERAMIC CHIP (KV-XS29N93) * A-1136-055-A B3 BOARD COMPLETE (KV-XS29N90) * A-1136-101-A B3 BOARD COMPLETE (KV-XS29N93) C1459 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V ********************* C1460 1-163-133-00 CERAMIC CHIP 470PF 5.00% 50V...
  • Page 56 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3216 1-117-720-11 CERAMIC CHIP 4.7UF C3269 1-164-004-11 CERAMIC CHIP 0.1UF...
  • Page 57 CN1403* 1-564-506-11 PLUG, CONNECTOR 3P <JACK> CN1405* 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P CN1406* 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P J1401 1-784-646-11 TERMINAL, S J1402 1-778-388-11 JACK BLOCK, PIN 9P (KV-XS29N90) J1402 1-778-387-11 JACK BLOCK, PIN 12P (KV-XS29N93) – 105 –...
  • Page 58 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L (KV-XS29N93) R1444 1-216-089-91 RES-CHIP 1/10W (KV-XS29N93) Q3201 8-729-224-62 TRANSISTOR 2SK246GR-TPE2 R1445 1-216-025-91 RES-CHIP 1/10W Q3202 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L (KV-XS29N90) R1446 1-216-105-91 RES-CHIP 220K 1/10W Q3203 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L (KV-XS29N90) R1447 1-216-025-91 RES-CHIP 1/10W Q3204 8-729-224-62 TRANSISTOR 2SK246GR-TPE2...
  • Page 59 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R1459 1-216-025-91 RES-CHIP 1/10W R3202 1-216-097-91 RES-CHIP 100K...
  • Page 60 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3243 1-216-073-00 RES-CHIP 1/10W R3285 1-216-073-00 RES-CHIP 1/10W...
  • Page 61 20.00%16V C5820 1-164-004-11 CERAMIC CHIP 0.1UF 10.00%25V ****************************************************************** <CONNECTOR> * A-1131-506-A B5 BOARD MOUNTED (KV-XS29N90) * A-1131-532-A B5 BOARD MOUNTED (KV-XS29N93) CN1501* 1-564-511-11 PLUG, CONNECTOR 8P (KV-XS29N93) ******************** CN1502* 1-564-507-11 PLUG, CONNECTOR 4P (KV-XS29N93) CN1503 1-764-811-11 CONNECTOR, BOARD TO BOARD 10P...
  • Page 62 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK L1509 1-414-857-11 INDUCTOR 100UH (KV-XS29N93) <RESISTOR> L1510 1-414-187-11...
  • Page 63 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R1560 1-216-041-00 RES-CHIP 1/10W R5818 1-216-081-00 RES-CHIP 1/10W...
  • Page 64 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <FERRITE BEAD> <CONNECTOR> FB2300 1-410-397-21 FERRITE 1.1UH CN700...
  • Page 65 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R705 1-249-418-11 CARBON 1.2K 1/4W C2803 1-129-723-00 FILM 0.056UF...
  • Page 66 Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R2813 1-216-059-00 RES-CHIP 2.7K 1/10W * A-1372-755-A H5 BOARD MOUNTED (KV-XS29N90) R2814 1-216-121-91 RES-CHIP 1/10W * A-1372-756-A H5 BOARD MOUNTED (KV-XS29N93) R2815 1-216-085-00 RES-CHIP 1/10W ******************** R2816...
  • Page 67 KV-XS29N90/XS29N93 RM-914 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. 4 (KV-XS29N93) REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <COIL> C2412 1-126-967-11 ELECT 47UF 20.00%50V...
  • Page 68 REMOTE COMMANDER (RM-914) R5915 1-249-429-11 CARBON 1/4W 9-933-895-01 BATTERY COVER, REMOTE COMMANDER R5916 1-249-419-11 CARBON 1.5K 1/4W Sony Corporation English 2000BM70025-1 Sony Technology Malaysia Sdn. Bhd. Printed in Malaysia  9-965-799-01 TV Business of General Area 2000. 2 – 116 –...
