Trane 32- 5027- 13 User's Information Manual

▲ ▲
WARNING
!
If the information in this manual is not followed exactly,
a fire or explosion may result causing property
damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier,
call the fire department.
— DO NOT RELY ON SMELL ALONE TO DETECT
LEAKS. DUE TO VARIOUS FACTORS, YOU MAY
NOT BE ABLE TO SMELL FUEL GASES.
• U.L. recognized fuel gas and CO detectors are
recommended in all applications, and their
installation should be in accordance with the
manufacturer's recommendations and/or local
laws, rules, regulations, or customs.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
▲
WARNING
!
SAFETY HAZARD
DO NOT USE THIS UNIT IF ANY PART HAS BEEN UNDER
WATER. IMMEDIATELY CALL A QUALIFIED SERVICE
TECHNICIAN TO INSPECT THE FURNACE AND TO RE-
PLACE ANY PART OF THE CONTROL SYSTEM AND ANY
GAS CONTROL WHICH HAS BEEN UNDER WATER.
FAILURE TO FOLLOW THIS WARNING MAY RESULT IN
PERSONAL INJURY, PROPERTY DAMAGE, OR DEATH.
User's Information Guide
Gas Furnaces — Non-Condensing
Fan Assisted Combustion System
Upfl ow / Horizontal and Downfl ow / Horizontal
Available in French Canadian (FC)
Contents
Dangers, Warnings & Cautions
General Information
To Start the Furnace
Proper Maintenance
The Problem Solver
Regular Dealer Maintenance
Warranty
GENERAL INFORMATION
Understand the signal words WARNING and CAUTION.
These words are safety alert words. WARNING indicates
hazards which could result in personal injury or death.
CAUTION is used to indicate unsafe practices which could
result in minor injury or property damage.
IMPORTANT FACTS
The fl ow of combustion and ventilating air must not be ob-
structed from reaching the furnace. Air openings provided
in the casing of the furnace must be kept free of obstruc-
tions which would restrict airfl ow, thereby affecting effi -
ciency and safe operation of your furnace.
Also, air openings provided to the area in which the furnace
is installed and the space around the furnace shall not be
blocked or obstructed. Keep this in mind should you choose
to remodel the area which contains your furnace. If addi-
tional insulation is added after the furnace is installed, the
area around the furnace must be inspected to ensure it is
free and clear of insulation. If this furnace is installed in an
attic or other insulated space it must be kept free and clear
of all insulating materials as some insulating materials are
combustible.
Furnaces must have air for proper performance. There
must be a free fl ow of fresh air suffi cient for effi cient com-
bustion and safe ventilation of your furnace.
The combustion air for your furnace must be fresh uncon-
taminated air. Paints, varnishes, laundry bleaches, de-
tergents, many household cleaners, water softening salts,
adhesives, and all such products release fumes containing
compounds which could lead to early heat exchanger and
vent system deterioration. Do not store these types of prod-
ucts near your furnace.
32- 5027- 13
