PRODUCT NAME
Hitachi 10.8 V Cordless Impact Driver
WH 10DL
Model
MARKETING OBJECTIVE
The new cordless impact driver Model WH 10DL is equipped with the newly developed 10.8-V lithium-ion
battery. Features of the Model WH 10DL include the following.
(1) Easy to handle thanks to the most compact body in its class.
(2) Thin handle comfortably fits in the palm of the operator's hand.
(3) Optimally balanced design with the center of gravity maintained at the center of the grip (palm of the
operator's hand)
(4) Highest tightening torque in its class in spite of the compact body
(5) Battery level warning lamp
With the new Model WH 10DL, we aim to expand our market share.
APPLICATIONS
Tightening/loosening of small screws, tapping screws, wood screws, Teks screws, Hex screws, etc.
Tightening/loosening of bolts, nuts, etc.
Drilling into wood and other materials (with use of the optional accessory drill chuck adapter set)
SELLING POINTS
[ NEW FEATURES ]
Lightweight and compact body (139 mm in
length and 0.9 kg in weight)
Thin handle (comfortably fits in the palm of the
operator's hand)
Optimally balanced design with the center of
gravity maintained at the center of the grip
Powerful tightening torque 105 N
Battery level warning lamp
Multiple battery protection circuits for safety
Equipped with 10.8-V lithium-ion battery
Replaceable carbon brushes
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.
•
m
LIST No. H802
Mar. 2008
International Sales Division
W
