Configuration 3: One SAM1HF and two SAM2LF horizontal
NOTE: Shown without the trim panel (baffle blocks) installed on the SAM1HF.
Configuration 4: One SAM1HF and two SAM2LF vertical
NOTE: Shown without the trim panel (baffle blocks) installed on the SAM1HF.
