JBL SAT 10 Technical Manual

Technical Manual
SAT 10/SAT 10S/SAT 550
SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance:
• Max Amp Power:
• Frequency Response:
• Sensitivity:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Cabinet:
• Grille:
• Low Frequency
Transducer:
DC Resistance:
• High Frequency
Transducer:
DC Resistance:
• Crossover Network:
PACKAGE
MUSIC 10
NOTE: SAT 10 IS PART OF THE MUSIC 10 AND MUSIC 15 SYSTEMS.
SAT 10/10S ARE PART OF THE SCS110 AND MOVIES 10 SYSTEMS.
SAT 10S/550 ARE PART OF THE ESC550 SYSTEM.
8 ohm
80W
150 Hz – 20 kHz (±3 dB) (10/550)
100 Hz – 15 kHz (±3 dB) (10S)
88 dB SPL, 1 Watt @ 1 Meter
3.5 kHz (10/550)
SAT 10/10S/550 L,R (Not For Sale)
75131-01 BLK
75131-02 WHT
74860-05 3-1/2 in. (90mm)
Neodymium Magnet
4.7 ohm ±5%
75133-01 Titanium
Composite Dome
5.5 ohm ±10%
SAT 10 331167-001
SAT 10S 330991-001
SAT 550 332307-001
Warranty N76310
Owner's Manual 330258-003
Survey Card 331384-001
End Pad,
SAT 10
330293-001
SAT 10
Bass 10
Poly Bag
63655
End Pad, Sub
330294-001
Carton
Music 10
330295-001
JBL Consumer Products Inc., 250 Crossways Park Dr., Woodbury, New York 11797
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
(Without Stand)
SHIPPING WEIGHT:
WARRANTY INFORMATION:
• Refer to the Warranty Statement packed with each product.
WIRING DIAGRAM
SAT 10/550
Driver,
High Freq
75133-01
(See Note)
YEL
Driver,
Low Freq
74860-05
(See Note)
BLU/BLK
SCHEMATIC SAT 10/550
RED *
L1
C1
0.39 mH
200µF/
50V
INPUT
RED/BLK
R2
2.7Ω
5W
WIRING DIAGRAM SAT 10S
RED
BLK
SCHEMATIC SAT 10S
C1
4.7µF/
50V
INPUT
*
C1 PRESENT ONLY ON SAT 10
NOTE: REPLACE FOAM BAFFLE WHEN SERVICING SPEAKERS. CONE/DIAPHRAGM
KIT NOT AVAILABLE. DEFECTIVE SPEAKER SHOULD BE REPLACED.
5.0V Input, 10 Hz to 20 kHz
5.0V Input, 10 Hz to 10 kHz
3.0V Input, 1 kHz to 20 kHz
6.5 x 3.75 x 4.25 in. D
(165mm x 95mm x 108mm D)
See Package Drawing
Input
Terminal
YEL/BLK Network
SAT 10/SAT 550
SAT 10 331167-001
SAT 550 332307-001
BLU
BLU
R1
4.7Ω
5W
C2
4.7µF/
100V
BLU/BLK
YEL
C3
4.7µF/
L2
100V
0.15 mH
YEL/BLK
Network
Input
SAT 10S
Terminal
330991-001
RED
L1
0.1 mH
BLK
4-98
L.F.
H.F.
L.F.
REV A
