JBL S2C Specifications

SYSTEMS INTEGRATION
SPECIALIST PRODUCTS

Key Features

THX certified L, C, R loudspeaker.
2" titanium compression driver – shielded.
Bi-radial horn – 80 degrees vertical, 100
degrees horizontal.
(2) 6.5" Poron-fiber-cone, cast-frame
woofers – shielded.
Vertical orientation.
Easily placed behind perforated screens.
Black ash semi-gloss finish.
Front ported enclosure for easy installation as
free standing or built-in.
Description
Synthesis 2 vertical front loudspeaker.

Frequency Response

100.0
95.0
90.0
85.0
80.0
75.0
70.0
65.0
60.0
55.0
50.0
20.0 100.0
log frequency Hz
A Harman International Company
JBL SIS Products Group: Tel 818-830-8757 Fax 818-891-6894
8500 Balboa Boulevard, Northridge, CA 91329
250 Crossways Park Drive, Woodbury, NY 11797
Quick Spec

Specifications

Frequency Response
Sensitivity
Recommended Maximum Amplifier Power
Nominal Impedance
High Frequency Transducer
Crossover Frequency
Low Frequency Transducer
Weight
Dimensions (H x W x D)
On Axis Response*
1000.0
S2C
80 Hz - 17 kHz
91 dB (1 watt @ 1 meter)
150 Watts
8 Ohms
2" Pure Titanium Compression Driver
2.8 kHz
6.5" Cone Transducer
65 lbs. /29.5 kg.
23.5" x 15" x 10.78"
597mm x 381mm x 274mm
Listening Window
(+/- 30 degrees Horizontal,
+/- 10 degrees Vertical)
Early Reflections
Total Sound Power
Directivity Index
Early Reflection Directivity Index.
10000.0
