Creek Audio EVOLUTION 50CD Instruction Manual

Dac / cd player
Hide thumbs Also See for EVOLUTION 50CD:
Table of Contents

Advertisement

Quick Links

Download this manual
EVOLUTION 50CD
DAC / CD Player
Instruction Manual
Rev 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVOLUTION 50CD and is the answer not in the manual?

Questions and answers

Related Manuals for Creek Audio EVOLUTION 50CD

Summary of Contents for Creek Audio EVOLUTION 50CD

  • Page 1 EVOLUTION 50CD DAC / CD Player Instruction Manual Rev 1.0...

  • Page 3: Safety Information

    SAFETY INFORMATION The EVOLUTION 50CD is designed to operate on either 220-240 Volts - 50 Hz AC, or 110- 120 Volts - 60 Hz AC. The voltage selector switch is located on the bottom of the case; to select a different voltage range, use a small flat-blade screwdriver to push the switch from one position to the other.

  • Page 4: Getting Started

    Firstly, connect the mains supply using the 3-core mains cord supplied. Push the 3 pin IEC plug into the socket on the rear panel of the EVOLUTION 50CD and plug the other end into a suitable wall socket. Do not overload the socket with too many connectors. Ask your dealer for advice if in doubt.

  • Page 5: Rear Panel

    Optical TOSLINK digital input, which can connect to a CD transport, or other digital device. An optional, plug-in, Bluetooth module may be made available in future. Please check with your dealer or on the Creek Audio website for price and availability. OUTPUTS Co-ax digital output, is for passing digital signals through the EVOLUTION 50CD.

  • Page 6: Front Panel Controls

    The mains On/Off switch is a button located on the right hand side of the front panel with the engraved power symbol above it. Press this button to power the EVOLUTION 50CD on or off. Please note that the EVOLUTION 50CD does not have a Standby power function.
  • Page 7 Display features: With a disc loaded, the display will indicate the total number of tracks and total playing time when in STOP mode. During playback, the track number and track time will also be displayed. Symbols are also shown for Repeat and Random functions. If the disc contains CD text data, this will also be shown across the top of the display and will scroll when the disc is playing showing Artist, Album name and Track name.

  • Page 8: Remote Control Operation

    FILTER description below FUNCTIONS NOT YET IN USE: PROGRAM is not enabled yet. Look for future soft- ware updates from Creek to see if this little used feature has been written. VOLUME may be enabled in future. Look for future software updates from Creek to enable this function.

  • Page 9: Dac Operation

    Use a dedicated ‘digital interconnect’ for the best results. Ask your dealer for advice. The EVOLUTION 50CD can supports digital input signals from 16 to 24 Bit word lengths and sample rates from 32 kHz to 192 kHz. The incoming signal will be checked and the sample rate will automatically be displayed.

  • Page 10: Technical Specifications

    Dimensions W/H/D 430 x 60 x 280mm (16.9 x 2.36 x 11 inches) Finish Silver or black engraved front panels Creek Audio Ltd reserves the right to change or modify the specification of its products without prior warning. Page: 8...

  • Page 11: Warranty

    WARRANTY If within two years of purchase date your Creek EVOLUTION 50 proves to be defective for any reason other than accident, misuse, neglect, unauthorized modification, or fair wear and tear, Creek Audio Ltd. will, at its discretion, replace the faulty parts without charge for labour or return carriage within the United Kingdom.
  • Page 12 Creek Audio Ltd 12 Avebury Court, Mark Road, Hemel Hempstead, Hertfordshire, HP2 7TA England www.creekaudio.com - info@creekaudio.com - +44(0)1442 260146...
