VOYAGE CD
Instruction Manual
Compact Disc Player
V1.1
WWW.CREEKAUDIO.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOYAGE CD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Creek Audio VOYAGE CD

Summary of Contents for Creek Audio VOYAGE CD

  • Page 1 VOYAGE CD Instruction Manual Compact Disc Player V1.1 WWW.CREEKAUDIO.COM...

  • Page 2: Safety Information

    SAFETY INFORMATION The Voyage CD is designed to operate correctly from a wide range of mains voltage - 90V to 265V AC, 50Hz to 60Hz. If a fault develops internally that results in the mains fuse being blown, the front panel LED display will not light. This usually indicates a serious fault, and the product should be packed in its original packaging or something suitable to avoid damage in transit and returned to the supplying dealer or a specialised service company for inspection and repair.

  • Page 3: Getting Started

    GETTING STARTED Connect the mains supply to the Voyage CD with the 3-core mains cord supplied for the country of use. Push the 3 pin IEC plug into the mains connector on the rear panel of the Voyage CD and plug the other end into a suitable mains wall socket. Preferably, the socket should have a ground connection and sufficient power to support all your audio equipment use.

  • Page 4: Power Input

    OFF. Once in STANDBY the Voyage CD will display a circular power symbol and the word STANDBY below it in the front panel display window. It can then be powered-up fully by pressing any of the six buttons on the front panel display, or by pressing the blue MUTE button on the top right of the remote handset.

  • Page 5: Digital Outputs

    RC BUS IN and OUT. This 3.5mm jack socket allows the user to either add a remote-control extender or link the Voyage CD to the amplifier to force them to share only one remote control receiver. Using the appropriate remote extender accessory from Creek allows the CD and amplifier to be in- stalled in a hidden location and operated when not in line of sight of the operator.

  • Page 6: Analogue Audio Outputs

    There are only six function buttons on the front panel, located in the display window. POWER ON and OFF To wake the Voyage CD from STANDBY mode, press any button and the CREEK logo will appear. Five seconds later the CREEK logo will disappear, and the display will show the status of the unit.
  • Page 7 Avoid using cables longer than 5 metres or the USB input may not work reliably. When first connecting to your computer running OS Windows 10 to the Voyage CD it will automatically search for the audio driver. Provided your computer or streaming device is connected to the internet, it should auto-detect the Voyage USB Audio 2.0 and install it.
  • Page 8 Go to you preferred music app, like Spotify, Tidal, Roon, Qobuz, or a network storage device on your computer and select and play music as usu- al. Direct the output to the Voyage USB Audio 2.0. The USB signal will be converted from digital PCM or DSD to analogue by the Voyage CD’s DAC.
  • Page 9 Press to sequence through five optional digital filter shapes; see a further description below: The following remote-control function buttons are not in use for the Voyage CD at the present time: TONE, DIRECT, L & R balance, MENU, PROGRAM, TIME, SPEAKERS A & B, PHASE, LEVEL, BAND, MODE and MONO.
  • Page 10 The sensor can then be placed where it can be seen by the user and the Voyage CD can be hidden away. The extender jack should be plugged into the socket on the rear panel marked RC Bus IN. An RC bus OUT socket allows the amp to be chain linked to a matching Voyage CD, so only one remote sensor will operate two products to prevent the possibility of the two products becoming un-synchronised, i.e.

  • Page 11: Technical Specifications

    5.5Kgs (12.12 lbs). Dimensions W/H/D 430 x 60 x 280mm (16.9 x 2.36 x 11 inches). Finish Silver or black engraved front panels. Creek Audio Ltd reserves the right to change or modify the specification of its products without warning.

  • Page 12: Warranty

    WARRANTY. If within two years of purchase date your Creek Voyage CD proves to be defective for any reason other than accident, misuse, neglect, unauthor- ized modification, or fair wear and tear, Creek Audio Ltd. will, at its discretion, replace the faulty parts without charge for labour or return carriage within the United Kingdom.
