Jensen VX6020 Installation Manual
Hide thumbs
Also See for VX6020:
- Owner's manual (230 pages) ,
- Owner's manual (80 pages) ,
- Operating instructions manual (140 pages)
Advertisement
What's in the Box
The following items are supplied with
the VX6020:
•
VX6020 Head Unit
•
Custom Cosmetic Trim Ring
•
Hardware Bag
•
Power/Speaker Output Harness
•
GPS Antenna Harness
•
I/O Harness
•
USB-A to Mini USB Adapter
•
Owners Manual & Warranty Card
•
Installation Guide
WARNING! Never install this unit where operation and viewing could interfere with
safe driving conditions.
VX6020
The following tools and supplies are
needed to install the VX6020:
• Torx type, flat-head and Philips
screwdrivers
• Wire cutters and strippers
• Tools to remove existing radio (screw
driver, socket wrench set or other
tools)
• Electrical tape
• Crimping tool
• Volt meter/test light
• Crimp connections
• 18 gauge wire for power connections
• 16 – 18 gauge speaker wire
Installation Guide
Tools and Supplies
Advertisement
Related Manuals for Jensen VX6020
Summary of Contents for Jensen VX6020
- Page 1 What’s in the Box Tools and Supplies The following items are supplied with The following tools and supplies are the VX6020: needed to install the VX6020: • VX6020 Head Unit • Torx type, flat-head and Philips • Custom Cosmetic Trim Ring screwdrivers •...
- Page 2 ISO-DIN Installation The VX6020 is designed to fit into a 2.0 DIN dashboard opening. The unit has threaded holes in the chassis side panels which may be used with the original factory mounting brackets of some Toyota, Nissan, Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the radio to the dashboard.
- Page 3 CAUTION! IMPORTANT: Incorrect wiring connections can damage the unit. Follow the wiring instructions carefully, or have the installation handled by an experienced technician. Need Help? For technical assistance, call the Jensen customer support line at 1-800-323-4815. BLUE + POWER ANTENNA & AMPLIFIER TURN-ON...
- Page 4 Audiovox Electronics Corporation Hauppauge, NY 11788 Technical Assistance: 1-800-323-4815 www.jensenmobile.com © 2013 Audiovox Printed in China 128-9244a...
