- Page 1 Refresh Personal Hygiene System™ OWNER’S MANUAL Round EU44959 — ROUND FRONT Elongated EV77959 — ELONGATED FRONT This manual contains important safety information. Please read carefully before product installation or use. EX93000 Refresh Installation Manual 10/06...
-
Page 2: Important Safeguards
Important Safeguards CAUTION For safety reasons, please read this entire manual before installation or use. Danger - Possibility of electric shock! Use the correct voltage according to the specifications and connect to a three-prong GFCI grounded outlet. NOTE: This GFCI outlet should be installed prior to performing this installation. -
Page 3: Before Installation
Before Installation Tools Needed • Flat head screwdriver • Phillips head screwdriver NOTE: The included Universal Wrench will work for most applications. Depending on your toilet confi guration, an adjustable wrench may also be needed. Alternate Mounting Hardware Some toilets may not provide adequate access to the seat mounting holes preventing proper installation of the Standard Mounting Hardware. -
Page 4: Battery Installation
Installation 3) Install Mounting Plate (continued) c) Adjust mounting plate so length (L) between the front of the toilet bowl and the back of the mounting plate is as follows: Round (EU44959): L=18¼" (465 mm) Elongated (EV77959): L=20½"(495 mm) d) Tighten Mounting Bolts with screwdriver until the mounting plate is securely fastened to the toilet. -
Page 5: Remote Control Installation
Installation 8) Remote Control Installation a) Identify a location for the Remote Control that is visible and reachable from the toilet and that does not obstruct the IR signal. Depending on your wall type, you can install the screws directly or use anchor mounts (provided) as shown. -
Page 6: Operation
Some features of the Refresh Personal Hygiene System™ are designed to function only when the seat is occupied. REMOTE CONTROL PANEL WARM WATER WASH Posterior (Rear) Feminine (Vaginal) Cleansing LCD Panel Powersave Function Decrease Increase Water Pressure Stop Adjustment (for Wash and Dryer) Using the Refresh Remote Control Warm Water Washing Sit on the seat and press the FRONT or BACK (either HIM or HER) button to begin water... -
Page 7: Setting The Clock
Operation Setting the Clock a) Press and hold the STOP button on the remote Control for over 5 seconds until the Clock flashes. b) Use the button to set the HOUR and the button to set the MINUTES. Power Save Mode The Refresh Personal Hygiene System™... -
Page 8: Maintenance
5) Reconnect the filter to the T-Valve. 6) Turn the water supply back ON and check for leaks. For other issues or questions, contact Jacuzzi Customer Service: Contact Information Jacuzzi Whirlpool Bath Customer Service 14801 Quorum Dr., Suite 400...
